Заводской дешевый сверхмощный конический роликовый подшипник Hm218238/10hm218248/hm218210 Hm220149/10 дюймовый пользовательский

Заводской дешевый сверхмощный конический роликовый подшипник Hm218238/10hm218248/hm218210 Hm220149/10 дюймовый пользовательский

Категория: Taper Roller Bearings >>>
Поставщик: Shanghai Huanbiao Imp.&Exp. Co. Ltd.

Цена:0,75 $ - 6,95 $*

Количество:

В избранное

Описание и отзывы

Характеристики

Product Description

Specification

Tapered roller bearing is a separable bearing. The inner and outer rings of the bearing have tapered raceways. This type of bearing is divided into single row, double row and four row tapered roller bearings according to the number of rows of rollers installed. Single-row tapered roller bearing can bear radial load and axial load in single direction. When the bearing bears the radial load, it will produce an axial component, so it needs another bearing that can bear the axial force in the opposite direction to balance
Tapered roller bearing refers to the radial thrust type rolling bearing whose rolling body is tapered roller. There are small cone angle and large cone angle. The small cone angle mainly bears the combined radial and axial load mainly based on radial load, which is usually used in double mode and installed in reverse direction. The inner and outer races can be installed separately, and the radial and axial clearance can be adjusted during installation and use; The large cone angle is mainly used to bear the combined axial and radial loads dominated by axial loads. Generally, it is not used to bear the pure axial loads alone, but can be used to bear the pure radial loads when it is used as a pair of configurations (opposite installation of the same end).
The ability of single-row tapered roller bearing to bear axial load depends on the contact angle, that is, the angle of outer race raceway. The greater the angle, the greater the axial load capacity. Single row tapered roller bearing is the most widely used tapered roller bearing. In the front wheel hub of the car, small size double-row tapered roller bearings are used. Four-row tapered roller bearings are used in heavy machines such as large cold and hot rolling mills.
The type code of tapered roller bearing is 30000, and the tapered roller bearing is a separable bearing. In general, especially the tapered roller bearing outer ring and inner assembly within the dimension range specified in GB/T307.1-94 Rolling Bearing Radial Bearing Tolerances can be interchangeable.
The angle of the outer ring and the diameter of the outer raceway have been standardized as the same as the overall dimensions. It is not allowed to change during design and manufacturing. So that the outer ring and inner assembly of tapered roller bearing can be interchanged worldwide.
Tapered roller bearings are mainly used to bear the combined radial and axial loads, mainly radial loads. Compared with angular contact ball bearing, it has large bearing capacity and low limit speed. Tapered roller bearing can bear axial load in one direction and limit axial displacement of shaft or shell in one direction.

item	value
Type	BALL
Structure	Tapered Roller Bearing
Applicable Industries	Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Construction works , Energy & Mining, other
Bore Size	15mm - 320mm
Model Number	32210
Precision Rating	P0 P6 P5 P4 P2
Seals Type	New sealing structure type
Number of Row	Single Row
Place of Origin	China
	Shandong
Product name	Tapered Roller Bearing
Material	Gcr15
Package	single box packing or Industrial packaging
Brand	CNR
Sample	Avaible
Certificate	ISO 9001:2000
Quality	High Qulity
Application	It is widely used in mechanical equipment, hydropower and water conservancy, engineering, railway, automobile, steel, electric power, textile, packaging, medical treatment, metallurgy, mining, petroleum, electric power, paper making, electronic computer, motor, sports equipment, office equipment, instruments and meters, automobile motors, precision instruments and other fields
Feature	Low Noise
Size	Custom

More Products

Company Profile

Exhibition

Certifications

Packing & Delivery

Packaging and transportation can be in accordance with customer requirements

FAQ

Q1. Who are we?
A: We are based in Shanghai, China, start from 2014,sell to North America(30.00%),Eastern Europe(10.00%),South Asia(10.00%),South America(10.00%),Southeast Asia(5.00%),Northern Europe(5.00%),Central America(5.00%),Western Europe(5.00%),Eastern Asia(5.00%),Mid East(5.00%),Oceania(5.00%),Africa(5.00%). There are total about null people in our office.

Q2. How can we guarantee quality?
A: Always a pre-production sample before mass production;
Always final Inspection before shipment;

Q3.What can you buy from us?
A: bearing,spark plug,chain,bicycle

Q4. why should you buy from us not from other suppliers?
A: Shanghai Huanbiao Imp. And Exp. Co.,Ltd is a manufacturer of ball bearings, and also doing domestic business and foreign trade business . At present, our company is specialized dealing in Deep Groove Ball Bearings ,Spherical Roller Bearings, Needle R.

Q5. what services can we provide?
A: Accepted Delivery Terms: FOB,CFR,CIF；
Accepted Payment Currency:USD,EUR,JPY,CAD;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese,Spanish,Japanese,German
