                                                      TOCH-TECH

          RC2808 Co2 Laser Galvo Head Set 10.6um Input Aperture 12mm

       14mm 16mm 20mm for Co2 Laser Marking Marchine Scanning System

Description:

The galvanometer motor of our company is designed as a moving magnet structure, combined with the most advanced photoelectric transmission in the world

Sensing technology and PDM control method are developed using military-grade craftsmanship and technical level.

RC2808 galvanometer has good running stability, high positioning accuracy, fast marking speed and anti-drying

Strong interference ability, comprehensive performance indicators have reached the leading technical level of similar products at home and abroad, specific

Features are as follows:

1 It adopts photoelectric sensors imported from the United States and has independent intellectual property rights.

2 Differential photoelectric sensor accurately detects the position of the motor rotor, with good linearity, small drift, High resolution and repeat positioning accuracy.

3 Accurate load design for 20mm lens, high precision motor assembly, reasonable structure, static The friction coefficient and zero offset are small to ensure the best dynamic characteristics of the system.

4 The drive has a position and speed advanced detection function, which greatly improves the dynamics of the entire system Response performance and scanning speed.

5 The whole system adopts electromagnetic compatibility optimization design, with high signal-to-noise ratio and strong anti interference ability.

6 Solve the common problems of galvanometer motor temperature drift, signal interference and zero drift.
