Cell Type | N type Mono-crystalline | ||||||
No. of cells | 156 (2×78) | ||||||
Dimensions | 2465×1134×30mm | ||||||
Weight | 34.6kg | ||||||
Front Glass | 2.0mm,High penetration coated glass | ||||||
Back Glass | 2.0mm, Semi-tempered glass | ||||||
Frame | Anodized Aluminium Alloy | ||||||
Junction Box | IP68 Rated | ||||||
Output Cables | TUV 1×4.0mm2 (+): 400mm , (-): 200mm or Customized Length |
Module Type | JKM605N-78HL4-BDV | JKM610N-78HL4-BDV | JKM615N-78HL4-BDV | JKM620N-78HL4-BDV | JKM625N-78HL4-BDV | ||||
STC | PNG120M-375 | PNG120M-380 | PNG120M-385 | ||||||
Maximum Power (Pmax) | 605Wp | 610Wp | 615Wp | 620Wp | 625Wp | ||||
Maximum Power Voltage (Vmp) | 45.42V | 45.60V | 45.77V | 45.93V | 46.10V | ||||
Maximum Power Current (Imp) | 13.32A | 13.38A | 13.44A | 13.50A | 13.56A | ||||
Open-circuit Voltage (Voc) | 55.17V | 55.31V | 55.44V | 55.58V | 55.72V | ||||
Short-circuit Current (Isc) | 13.95A | 14.03A | 14.11A | 14.19A | 14.27A | ||||
Module Efficiency (%) | 21.64% | 21.82% | 22.00% | 22.18% | 22.36% | ||||
Operating Temperature(℃) | -40℃~+85% | ||||||||
Maximum system voltage | 1500VDC (IEC) | ||||||||
Maximum series fuse rating | 30A | ||||||||
Power tolerance | 0~+3% | ||||||||
Temperature coefficients of Pmax | -0.30%/℃ | ||||||||
Temperature coefficients of Voc | -0.25%/℃ | ||||||||
Temperature coefficients of Isc | 0.046%/℃ | ||||||||
Nominal operating cell temperature (NOCT) | 45±2℃ |
