The planetary mixer is a new type of high-efficiency mixing and stirring equipment. While the agitator revolves around the axis of the kettle body, it also rotates around its own axis at a high speed at a different speed, making the materials move in the kettle body in a complex way.Subjected to intense shearing and rubbing, it is several times more efficient than an ordinary mixer.The agitators are divided by the viscosity and characteristics of the material, including paddle type, twist type, claw type, frame type etc. have good mixing, reacting, kneading, dissolving effect.
Working Principle
| Type | Cylinder volume L | Feeding volume L | Motor power kw | Revolution speed rpm | Rotation speed rpm | Lift mm |
Vacuum Mpa | Overall LxWxH mm |
| XJB-2 | 3 | 2 | 0.75x2 | 0-65 | 0-170 | 250 | -0.098 | 850x450x300 |
| XJB-5 | 8 | 5 | 1.5x2 | 0-65 | 0-170 | 300 | -0.098 | 900x650x1500 |
| XJB-10 | 14 | 10 | 1.5x2 | 0-65 | 0-170 | 350 | -0.098 | 1600x760x1500 |
| XJB-15 | 20 | 15 | 2.2x2 | 0-65 | 0-170 | 400 | -0.098 | 1600x800x1550 |
| XJB-20 | 28 | 20 | 2.2+3 | 0-65 | 0-170 | 450 | -0.098 | 1600x800x1550 |
| XJB-30 | 43 | 30 | 3+4 | 0-65 | 0-170 | 500 | -0.098 | 1600x800x1550 |
| XJB-50 | 65 | 50 | 5.5+7.5 | 0-65 | 0-170 | 500 | -0.098 | 1700x1300x2150 |
| XJB-100 | 149 | 100 | 7.5+11 | 0-30 | 0-95 | 650 | -0.098 | 2100x1000x2300 |
| XJB-200 | 287 | 200 | 11+15 | 0-95 | 0-95 | 750 | -0.098 | 2500x1200x2550 |
| XJB-300 | 368 | 300 | 15+18.5 | 0-95 | 0-95 | 900 | -0.098 | 3000x1600x3000 |
| XJB-500 | 670 | 500 | 22+30 | 0-65 | 0-65 | 1000 | -0.098 | 2900x1300x3000 |
| XJB-1000 | 1327 | 1000 | 37+45 | 0-65 | 0-65 | 1200 | -0.098 | 3000x1600x3500 |
| XJB-1500 | 1800 | 1500 | 55+75 | 0-65 | 0-65 | 1400 | -0.098 | 3000x1800x3700 |
| XJB-2000 | 2300 | 2000 | 75+90 | 0-65 | 0-65 | 1500 | -0.098 | 4000x2300x5100 |
| XJB-3000 | 3400 | 3000 | 90+110 | 0-15 | 0-22 | 1800 | -0.098 | 4000x2500x5500 |
Advantage
(1) There is scraper on the planetary frame rotating together with the planetary frame, it clings to the container and scrape the materials on the wall off continuously, and ensure without mixing dead corner and excellent mixing result.
(2) Options for explosion-proof type, closed type, heating type, with PLC intelligent control type, etc.
(3) Reliable airproof tank can mix in vacuum and decompression surroundings.
(4) Tank with jacket for heating and cooling demand by input oil or water.
(5) Changeable inner tank with precision process, easy cleaning.
(6) The shaft motion on orbital revolution and axial rotation at the same time, which can make the material mixed evenly.
![.png]()
(1) There is scraper on the planetary frame rotating together with the planetary frame, it clings to the container and scrape the materials on the wall off continuously, and ensure without mixing dead corner and excellent mixing result.
(2) Options for explosion-proof type, closed type, heating type, with PLC intelligent control type, etc.
(3) Reliable airproof tank can mix in vacuum and decompression surroundings.
(4) Tank with jacket for heating and cooling demand by input oil or water.
(5) Changeable inner tank with precision process, easy cleaning.
(6) The shaft motion on orbital revolution and axial rotation at the same time, which can make the material mixed evenly.
Application area:Adhesives,macromolecule materials,suitable for the dispersion and mixing of products and materials in coatings,putty,ink,energy,cosmetics,food and other industries.
Applicable materials:Various slurries with viscosity less than 3,000,000cps,solid content under 90% such as Thermal conductive silica gel,thermal conductive silica grease,solar energy paste,battery paste,ceramic paste,silica gel ink,sealant,structural adhesive,ointment,MS glue,etc.
Recommended Product
Packing
1.As per customer's specified requirements
2. Plastics film protection with standard sea packing
Shipping
1. Small parts: By express, TNT/ DHL/ UPS/ Fedex etc.
2. Full machine: By sea or By air
3.Choose the best suitable way as your need.
1.As per customer's specified requirements
2. Plastics film protection with standard sea packing
Shipping
1. Small parts: By express, TNT/ DHL/ UPS/ Fedex etc.
2. Full machine: By sea or By air
3.Choose the best suitable way as your need.
Our Services
Pre-Sale Service: IDA engineer team could provide you with design of complete production line. We are owning modern Nano Laboratory and could help clients do test run of your material, generate lab report and guide your actual production.
On-Sale Service: IDA factory will manufacture the good quality machine.
After-sale Service: IDA engineers will be sandby for 24 hrs to provide you with prompt solution. We could send technicians to your factory to help you install the disperser and sand mill, train your workers to operate and help with the debugging.
All wear parts of IDA disperser and sand mill is available at any time you need. Our engineer will provide you with spare parts scheme before sending the grinding mill to help you know when it is needed to change the parts so that to avoid any delay of production due to mill parts.
