Цифровой датчик давления основное устройство соединение тип KEYENCE AP C31W Original

Specifications:

•














































































































  Model				AP-C31W
  Type				Negative pressure
  Rated pressure				0 to -101.3 kPa
  Fluid type				Air or non-corrosive gases
  Type of pressure				Gauge pressure
  Display				3 1/2-digit, 2-color, 7-segment LED (Character height: 11 mm), Display cycle: 10 times/s
  Operation indicator				Red LED x 2 (corresponding to control output 1 and 2)
  Display resolution				Normal mode: 0.1 kPa, Focus mode: 0.01 kPa
  Power consumption	Normal			12 V: 720 mW (60 mA) or less, 24 V: 960 mW (40 mA) or less*1
  Display temperature characteristic				±1 % of F.S. max.
  Hysteresis				Variable (Standard: 0.5 % of F.S.)*2
  Response time (Chattering prevention function)				2.5, 5, 100, or 500 ms (selectable)
  I/O	Analogue output			1 to 5 V with load impedance of 1 k max. (or zero-shift input selectable)
  	Zero-shift input			Input time: 2 ms or more. (or analog output selectable)
  	Control output			NPN open collector 100 mA max. (at 40 V or below) with max. residual voltage of 1 V, 2 outputs (NO or NC selectable)
  Pressure port				Rc (PT) 1/8 180 ° rotation
  Rating	Power voltage			12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less
  	Power consumption	Eco mode		12 V: 480 mW (40 mA) or less, 24 V: 720 mW (30 mA) or less*1
  Environmental resistance	Pressure resistance			500 kPa
  	Ambient temperature			0 to +50 °C (No freezing)
  	Relative humidity			35 to 85 % RH (No condensation)
  	Vibration resistance			10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions
  Material				Front housing: Polysulfone, Rear housing: PBT, Front seat: Polycarbonate, Pressure port: Zinc die-casting
  Accessories				Power supply cord (2-m with connector)
  Weight				Approx. 30 g (without cable) /Approx. 85 g (with 2-m cable)




* Usually,We will ship goods out in 1 day after payment.

*All the goods will be inspected or tested before shipment.

*Packing in professional anti-static bag;And foam cushioning materials will be use.

*We use DHL,FEDEX,TNT,UPS,EMS to delivery goods less than 30Kg;By air or by sea will be use for bulk order.The most economic

*shipping way will be given to you! Pls contact us directly and we will ship as your requirement.

Contact US!

TEL/Wechat:0755-23956626.

1. All products are 100% new and original.

2.All our products have a one-year warranty.
