220 В 6 кВт 6,2 кВт 6,3 кВт однофазный PV 48 В высокочастотный 6300 Вт включенный Гибридный солнечный инвертор с контроллером MPPT
22 753,83 ₽ - 25 816,85 ₽
Контроллер зарядного устройства EASUN POWER 48 В MPPT заводская цена 5 6 кВт 220/230 для домашнего использования солнечные инверторы
- Категория: >>>
- Поставщик: Shenzhen Yishang New Energy Technology Co. Ltd.
Сохранить в закладки 1600820775750:
Описание и отзывы
Характеристики
Specification
Models | ISolar-SMX-II-3.6KW | ISolar-SMX-II-5.6KW | ||
AC mode | ||||
Rated input voltage | 220/230Vac | |||
Input voltage range | (170Vac~280Vac) ±2%；(90Vac-280Vac)±2% | |||
Frequency | 50Hz/ 60Hz (Auto detection) | |||
Frequency Range | 47±0.3Hz ~ 55±0.3Hz (50Hz)/57±0.3Hz ~ 65±0.3Hz (60Hz); | |||
Overload/short circuit protection | Circuit breaker | |||
Efficiency | >95% | |||
Conversion time (bypass and inverter) | 10ms (typical) | |||
AC reverse protection | Available | |||
Inverter mode | ||||
Output voltage waveform | Pure sine wave | |||
Rated output power (VA) | 3600 | 5600 | ||
Rated output power (W) | 3600 | 5600 | ||
Power factor | 1 | 1 | ||
Rated output voltage (Vac) | 230Vac | 230Vac（200/208/220/240Vac settable） | ||
Output voltage error | ±5% | |||
Output frequency range (Hz) | 50Hz ± 0.3Hz/60Hz ± 0.3Hz | 50Hz ± 0.3Hz/60Hz ± 0.3Hz | ||
Efficiency | >92% | >90% | ||
Peak power | 6000VA | 10000VA | ||
Loaded motor capability | 2HP | 4HP | ||
Output short circuit protection | Circuit breaker | Circuit breaker | ||
Rated battery input voltage | 24V (Minimum starting voltage 22V) | 48V (minimum start voltage 44V) | ||
Battery voltage range | 20.0Vdc~33Vdc ± 0.6Vdc (Undervoltage alarm/shutdown voltage overvoltage alarm /overvoltage recovery... settable on LCD screen) | |||
Power saving mode | Load ≤50W | |||
AC charging | ||||
Battery type | Lead acid or lithium battery | |||
Charge voltage range | 20.0Vdc~33Vdc | 40~60Vdc | ||
Short circuit protection | Circuit breaker and blown fuse | Breaker and blown fuse | ||
Overcharge protection | Alarm and turn off charging after 1 minute | |||
PV charging | ||||
Maximum PV open circuit voltage | 500Vdc | 500Vdc | ||
PV operating voltage range | 120-500Vdc | 120-500Vdc | ||
MPPT voltage range | 120-450Vdc | 120-450Vdc | ||
Battery voltage range | 20-33Vdc | 40-60Vdc | ||
Maximum intput power | 4000W | 6000W | ||
PV charging current range (can be set) | 0-80A | 0-80A | ||
Charging short circuit protection | Blown fuse | Blown fuse | ||
Wiring protection | Reverse polarity protection | Inverse wiring protection | ||
Certified specifications | ||||
Certification | CE(IEC 62109-1) | |||
EMC certification level | EN61000, C2 | |||
Operating temperature range | -15°C to 55°C | |||
Storage temperature range | -25°C ~ 60°C | |||
Humidity range | 5% to 95% (Conformal coating protection) | |||
Noise | ≤60dB | |||
Heat dissipation | Forced air cooling, variable speed of fan | |||
Communication interface | USB/CAN/RS485(WiFi/GPRS)/Dry node control | |||
Size (L*W*D) | 378mm*280mm*103mm | 426mm*322mm*126mm | ||
Weight (kg) | 6.9 | 10.9 | ||
Product Description
Certifications
Packing & Delivery
Customer Photos
Company Profile
Shenzhen EASUN New Energy is a new energy factory established in 2012, Our Company Has Been Dedicated To Be A Professional High-Tech Enterprises In Solar Energy Field. We Focus On Quality, Efficiency And Stability Of The Solar Energy Products, Which Include Solar Inverters, Panels, Solar Energy Systems , Batteries And Charger Controller. we have an experienced and well-educated R&D team and our products posses more than 100 R&D patents on electronic technology,battery technology and chemical application engineering. We offer OEM,ODM and advanced customization services to meet various needs from different clients. The enterprise has passed ISO9001 quality management system certification, and our products have obtained ROHS,VDE,UL,ISO UI, CE,UN38.3, MSDS, IEC and other international certifications, At present, EASUN New Energy has reached a long-term strategic partnership with thousands of overseas customers in the new energy industry, and has established lots of logistics warehousing bases to efficiently serve customers in Asia,Africa,Europe,the Middle East,the Americas and other regions. We aim to provide the green,energy-saving and safe electrical energy safety solar storage system for global users. and continue to provide competitive products and reduce the intermediate costs for many foreign entrepreneurs,merchants and retailers in the new energy industry.
FAQ
Q1: How long is the warranty period ?
A1: Solar Inverter with 12-24 Months, if you want to extend the period, welcome to contact us .
Q2: How to install and use the solar inverter ?
A2: We have the English teaching manual and videos; All the videos about every step of machine Disassembly, assembly, operation will be sent to our customers.
Q3: What if I don't have export experience ?
A3:We have reliable forwarder agent which can ship items to you by sea/air/Express to your doorstep.Any way, we will help you choose the most suitable shipping service.
Q4. Do you have solar panel and battery ?
A4: Yes, we offer all in one, one-stop, solar system ESS programme.
Q5: How is your technical support?
A5: We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer
you video call anytime,our engineer will also go to oversea help our customers if necessary.
you video call anytime,our engineer will also go to oversea help our customers if necessary.
Q6: How can I make sure it's a secure transaction ?
A6: Alibaba can protect buyers' interest, all of our transation will go through alibaba platform.As you do the
payment, the money will go directly to Alibaba bank account.After we send your the items and you comfirm the detailed information,Alibaba will release us the money.
payment, the money will go directly to Alibaba bank account.After we send your the items and you comfirm the detailed information,Alibaba will release us the money.
Q7: Can you get the the solar inverter ODM/OEM customized for us ?
A7: Of course, brand name, machine color, designed unique patterns available for customization.
Q8:How to become your agent?
A8:Contact us through Alibaba and Sign agency agreement, we will give you the best price and service.
