Сверхмощный 4-осевой прицеп для специального автомобиля ветряная турбина дальние лопасти транспортный адаптер
887 420,00 ₽ - 1 068 231,83 ₽
Полезный бортовой двойной прицеп полный грузовой для транспортировки угля Монголии
- Категория: >>>
- Поставщик: Jinan Fortius International Trading Co. Ltd.
Сохранить в закладки 1600822991090:
Описание и отзывы
Характеристики
Utility Flatbed Double Trailer Full Cargo Trailer Transporting Coal For Mongolia
Performance parameters
Trailer in front | ||
Dimension： | 14m x 2.6m x 1.7m | |
Manganese steel girder: | 520mm high, 18-20mm upper and lower wings, 10mm vertical plate | |
Side beam: | 18# channel steel | |
Bottom plate: | 2mm thick checkered steel | |
Axle: | Axle 16 tons, 3 axles | |
Tires: | 13 1200 steel wire tires | |
Steel ring: | 18 thick steel rings with 8.8 type and 13 pieces | |
Leaf spring: | 10 pieces of weight (thickened) 16mm thick, (widened) 12cm wide | |
Suspension: | widened type (12cm wide) 70 axles 35 pins, extra type for tie rods | |
Outriggers: | 28 tons | |
Others: | 1.8mm thick web reinforcement in the middle of the trailer girder. 2.The front block of the trailer is reinforced, a climbing ladder is installed, and a tarpaulin frame is installed. 3.Each trailer is equipped with 8 container locks. 4.The front and rear of the trailer, the middle beam is thickened with locks. 5.The saddle position at the rear of the trailer is reinforced. 6.The wire harness is thickened with high-quality copper core. 7.The whole car is equipped with LED lamps and electrical circuits. 8.A 90mm heavy-duty saddle is assembled at the rear of the trailer. | |
Middle Trailer | ||
Dimension： | 5.6m x 2.55m x 1.71m | |
Girder: | 290mm variable neck, 18-20mm upper and lower wings, double 10mm web (two-layer vertical plate) | |
Suspension: | 10mm thick and 12cm wide, 70 axis shaft. 35 pins | |
Leaf spring: | 12 heavier pieces, widened and thickened | |
Axle: | Axle 16 ton class 2 axles | |
Rims: | 8.8 thick 18 rims 8pcs | |
Tires: | 8 pcs of 1200 steel wire tires | |
Brake cylinder: | 4 large double air chambers | |
Fifth wheel: | Assemble a 90 plus saddle, (rear) | |
Others: | 1.The trailer beams and bevels are reinforced by welding steel plates. 2.The wire harness is thickened with copper wires, and the electrical circuit and lamps are fully equipped. | |
Rear Trailer | ||
Dimension: | 12.8m x 2.6m x 1.69m | |
Manganese steel girder: | 520mm high, 18-20mm upper and lower wings, 10mm vertical plate | |
Side beam: | 18# channel steel | |
Axle: | Axle 16 tons, 3 axles | |
Tires: | 13 pcs of 1200 steel wire tires | |
Steel ring: | 8.8 type 18 thick steel rings, 13 pieces | |
Outrigger: | 28 tons | |
Others: | 1.The base plate is 2mm thick checkered plate. 2.Reinforcement of the middle web of the trailer frame. 3.Reinforce the front block of the trailer, install a ladder to the upper side beam, and install a tarpaulin frame. 4.The trailer is equipped with 8 container locks. 5.Thickened square steel is used for the front, rear and middle lock beams of the trailer. 6.The wire harness is thickened with high-quality copper core. 7.The electric circuit of the LED lamps and lanterns of the whole vehicle is fully assembled. 8.Other configurations of the front and rear trailers are assembled according to the factory standard configuration. 9.The bolts and screws used in the bottom plate of the front and rear trailers are all high-strength and anti-loosening. | |
We produce FORTIUS brand 40ft flat bed semi trailer ,40ft trailer ,40ft container transport trailer ,40ft semi trailer , container trailer , container semi trailer , container delivery trailer ,three axles semi trailer , four axles trailer ,40ft tire.
1. High transport efficiency, ensuring the products will not be deteriorated in the process of transportation,
saving the packing materials to reduce the transport costs.
2. Equipped with gasification bed, intake control system, and thrusting control system to ensure the pipelines unimpeded.
3. The tanks bulbar and the horizontal sextant angle are greater than the material rest angle, ensuring the discharging speed.
4. The diesel engine, providing compressed air.
1. High transport efficiency, ensuring the products will not be deteriorated in the process of transportation,
saving the packing materials to reduce the transport costs.
2. Equipped with gasification bed, intake control system, and thrusting control system to ensure the pipelines unimpeded.
3. The tanks bulbar and the horizontal sextant angle are greater than the material rest angle, ensuring the discharging speed.
4. The diesel engine, providing compressed air.
Product Description
product details
1. Adopts high strength steel material to manufacture the flatbed trailer, it can make the flatbed trailer have a higher loading capacity and a longer service life.
2. Also the trailers floor is checker plate, this will keep the other bulk cargo more stable.
3. Durable mechanical widened spring suspension, make sure the stability and safety.
4. polyurethane paint, the vehicle is more beautiful, effective protection of the body against rust, extend the life of the vehicle.
5. High Quality container locks, make sure the stable and safety of the loads.
2. Also the trailers floor is checker plate, this will keep the other bulk cargo more stable.
3. Durable mechanical widened spring suspension, make sure the stability and safety.
4. polyurethane paint, the vehicle is more beautiful, effective protection of the body against rust, extend the life of the vehicle.
5. High Quality container locks, make sure the stable and safety of the loads.
Company Profile
JINAN FORTIUS INTERNATIONAL TRADING CO.,LTD which is located in the capital city ofShandong Province-Jinan, is a group company established by few 10-years working experiencedexperts for SINOTRUK trucks, trailers and spare parts. we are authorized by SINOTRUK, have dealtwith many projects in China and abroad, such as TANZANIA STRATEGIC CITIES PROJECT, UgandaCITIES Sewage engineering, Guinea city electric project, Brunei Port project, Fiji loggingtransportation, Philippines mining project and so on.
During many years business operation and experiences, we are extending our business as drawing afull construction vehicles and machinery plan to our customer, and take all processing from buy toafter-sales service. we have "heavy duty fans" from all over the world now, hope you may joint us, andlet start a good and pleasant business association together.
Please try to talk more to us about your working condition and details requirement. We will docustomerized design for special you!
During many years business operation and experiences, we are extending our business as drawing afull construction vehicles and machinery plan to our customer, and take all processing from buy toafter-sales service. we have "heavy duty fans" from all over the world now, hope you may joint us, andlet start a good and pleasant business association together.
Please try to talk more to us about your working condition and details requirement. We will docustomerized design for special you!
Certifications
visiting and exhibition
Packing & Delivery
FAQ
Q1,What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q2,What's your minimum quality?
1 unit
Q3,How about your delivery time?
A: Generally, it will take about 20 to 30 days after receiving your advance payment. The specific delivery time depends on the
items and the quantity of your order.
Q4,What's the warranty?
A: Engine, transmission, axle guarantee one year (Any faulty caused by incorrect operation or man-made factors is exclusive of
guarantee.)
Q5, What's your after-sale service?
A: We provide technical support for our trucks and whole life parts supply
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q2,What's your minimum quality?
1 unit
Q3,How about your delivery time?
A: Generally, it will take about 20 to 30 days after receiving your advance payment. The specific delivery time depends on the
items and the quantity of your order.
Q4,What's the warranty?
A: Engine, transmission, axle guarantee one year (Any faulty caused by incorrect operation or man-made factors is exclusive of
guarantee.)
Q5, What's your after-sale service?
A: We provide technical support for our trucks and whole life parts supply
