Литий-ионная аккумуляторная батарея Lifepo4 12 В 100 Ач литий-ионные батареи для домашней солнечной
198,00 $ - 249,00 $
Гибридная солнечная энергетическая система электроинструменты все в одном небольшом поставщике солнечной
- Категория: Renewable Energy >>>
- Поставщик: CEEG (Jiangsu) Tech Co. Ltd
Сохранить в закладки 1600825734888:
Описание и отзывы
Характеристики
Product Description
Specification
Model | CHCI-3.6K-5.12kWh | CHCI-3.6K-10.24kWh | CHCI-5.0K-5.12kWh | CHCI-5.0K-10.24kWh | CHCI-6.0K-5.12kWh | CHCI-6.0K-10.24kWh | ||||||
PV Input | ||||||||||||
Absolute max Voltage (V) | 600 | |||||||||||
MPPT Voltage Range (V) | 100-550 | |||||||||||
Max. DC Input Power (W) | 4800 | 6650 | 8000 | |||||||||
Start-up Voltage (V) | 90 | |||||||||||
Rated Operating Voltage (V | 360 | |||||||||||
Max. Input Current (A) | 12.5/12.5 | |||||||||||
Isc PV (A) | 18/18 | |||||||||||
NO. of MPP Trackers | 2 | |||||||||||
NO. of Strings per MPP Tracker | ||||||||||||
Battery | ||||||||||||
Battery Capacity | LiFeP04 5.12kWh/10.24kWh | |||||||||||
Nominal Battery Voltage (V) | 204.8/409.6 | |||||||||||
Battery Voltage Range (V) | 160...227.2/320...454.4 | |||||||||||
Max. Charge/Discharge Current (A) | 25/25 | |||||||||||
AC Input/Output | ||||||||||||
Max. Apparent Power to Grid (VA) | 3600 | 5000 | 6000 | |||||||||
Rated Power (W) | 3600 | 5000 | 6000 | |||||||||
Max. Apparent Power from Grid (VA) | 7200 | 10000 | 12000 | |||||||||
Rated Voltage (V) | 220/230/240 | |||||||||||
Rated Frequency (Hz) | 50/60 | |||||||||||
Rated AC Current to Grid (A) | 15.6 | 21.7 | 26.1 | |||||||||
Rated AC Current from Grid (A) | 31.2 | 43.4 | 52.2 | |||||||||
Rated AC Current from Grid (A) | 31.2 | 43.4 | 52.2 | |||||||||
Displacement Power Factor | 1（-0.8…+0.8 adjustable) | |||||||||||
THDi | ＜3% | |||||||||||
EPS Output (With Battery) | ||||||||||||
Max. Output Power (W) | 3600 | 5000 | 6000 | |||||||||
Rated Apparent Power (VA) | 4320 | 6000 | 7200 | |||||||||
Rated Voltage (V) | 230(±2%） | |||||||||||
Norminal Frequency (Hz) | 50/60(±0.2%） | |||||||||||
Rated Output Current (a.c.A) | 18.8 | 26.1 | 31.3 | |||||||||
Switch time (ms) | ＜10 | |||||||||||
THDv @Linear Load (%) | ＜2 | |||||||||||
Efficiency | ||||||||||||
PV Max Eficiency (%) | 97.6 | |||||||||||
PV Europe Efficiency (%) | 97 | |||||||||||
PV Max. MPPT Efficiency (%) | 99.9 | |||||||||||
Battery Discharge Efficiency (%) | 96.7 | |||||||||||
What is the all-in-one solar energy storage system
An all-in-one solar energy storage system, also known as a photovoltaic (PV) energy storage system, is a new and innovative technology that combines solar panels and energy storage into a single unit. This system is designed to generate electricity from sunlight and store any excess energy for later use.
The system works by using solar panels, which are made up of photovoltaic cells that convert sunlight into direct current (DC) electricity. This electricity is then sent to an inverter, which converts it into alternating current (AC) electricity that can be used to power homes or businesses.
Excess energy that is generated but not immediately used can be stored in a battery bank for later use. This allows homeowners to use renewable energy sources to power their homes even when there is no sunlight, such as during the night or on cloudy days.
The system works by using solar panels, which are made up of photovoltaic cells that convert sunlight into direct current (DC) electricity. This electricity is then sent to an inverter, which converts it into alternating current (AC) electricity that can be used to power homes or businesses.
Excess energy that is generated but not immediately used can be stored in a battery bank for later use. This allows homeowners to use renewable energy sources to power their homes even when there is no sunlight, such as during the night or on cloudy days.
One of the primary benefits of an all-in-one solar energy storage system is its ability to reduce dependence on traditional power sources. By generating and storing their own energy, homeowners can reduce their carbon footprint and lower their electricity bills. Additionally, the system can provide backup power during power outages or emergencies, ensuring that critical appliances such as refrigerators or medical equipment remain functional.
Company Profile
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2017,sell to Northern Europe(59.00%),Africa(18.00%),South America(8.00%),Mid East(7.80%),South Asia(2.00%),North America(2.00%),Southeast Asia(1.90%),Central America(0.20%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
solar energy storage,solar energy panel,solar power inverter,solar hybrid inverter,solar battery
4. why should you buy from us not from other suppliers?
CEEG is a world-leading supplier of solar cells, modules and system solutions.
CEEG led Chinese PV companies to implement a feature project-"Whole Set of Key Technology Research and Demonstration Production
Line for the Industrialization of Low-Cost
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Jiangsu, China, start from 2017,sell to Northern Europe(59.00%),Africa(18.00%),South America(8.00%),Mid East(7.80%),South Asia(2.00%),North America(2.00%),Southeast Asia(1.90%),Central America(0.20%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
solar energy storage,solar energy panel,solar power inverter,solar hybrid inverter,solar battery
4. why should you buy from us not from other suppliers?
CEEG is a world-leading supplier of solar cells, modules and system solutions.
CEEG led Chinese PV companies to implement a feature project-"Whole Set of Key Technology Research and Demonstration Production
Line for the Industrialization of Low-Cost
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
