Высокопрочный Нитинол память рыболовная проволока для продажи
20,00 $ - 39,90 $
Производство и продажа Gr1 Gr2 Gr3 Gr4 Gr5 Tc4 Ta2 Ta4 титановая проволока из чистого титана сварочная титанового
- Категория: Titanium Wire >>>
- Поставщик: Shandong Meide Import And Export Co. Ltd.
Сохранить в закладки 1600826964550:
Описание и отзывы
Характеристики
Product Introduction
Product Name: Titanium Wire for Medical
1)Grade: Gr1, Gr2, Gr3, Gr5, GR7, ERTI1, ERTI 2, ERTI 3, ERTI 4, ERTI 5, ERTI 5ELI and so on.
2)Standard: ASTM F136, ASTM F67
3)Size: Dia 0.1-6.0mm*Coil, Dia 1.0-6.0*Coil or Straight
4)Application: Medical: Titanium tooth, Titanium surgical instruments, knee joints, shoulder joints, ribs,
Active heart valves, the skull bones clip, artificial tooth root and so on.
Other Titanium Wire
1)Grade: Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9, Gr11, Gr12, Gr23, Ti6Al4V ELI, Ti15333
TA0, TA0ELI, TA1, TA1ELI, TA2, TA2ELI, TA3, TA3ELI, TA4, TA5, TA6, TA7, TA9, TA10, TC1, TC2, TC3, TC4
2)Standard: ASTM B348, , ASTM F67, ASTM F136, ASTM B863, AMS 4951, AMS 4953, AMS 4954, AMS4928, MIL4911, AMS 4956, AWS 5.16, ISO5832/2, ISO5832/3, ISO5832/11, GB/T3623-2007, GB/T13810-2007, ASME ER Ti
3)Size: Dia 0.1-6.0mm*Coil, Dia 1.0-6.0*Coil or Straight
4)Application: Medical: Titanium tooth, Titanium surgical instruments, knee joints, shoulder joints, Ribs, active heart valves, the skull bones clip, artificial tooth root and so on.
1)Grade: Gr1, Gr2, Gr3, Gr5, GR7, ERTI1, ERTI 2, ERTI 3, ERTI 4, ERTI 5, ERTI 5ELI and so on.
2)Standard: ASTM F136, ASTM F67
3)Size: Dia 0.1-6.0mm*Coil, Dia 1.0-6.0*Coil or Straight
4)Application: Medical: Titanium tooth, Titanium surgical instruments, knee joints, shoulder joints, ribs,
Active heart valves, the skull bones clip, artificial tooth root and so on.
Other Titanium Wire
1)Grade: Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9, Gr11, Gr12, Gr23, Ti6Al4V ELI, Ti15333
TA0, TA0ELI, TA1, TA1ELI, TA2, TA2ELI, TA3, TA3ELI, TA4, TA5, TA6, TA7, TA9, TA10, TC1, TC2, TC3, TC4
2)Standard: ASTM B348, , ASTM F67, ASTM F136, ASTM B863, AMS 4951, AMS 4953, AMS 4954, AMS4928, MIL4911, AMS 4956, AWS 5.16, ISO5832/2, ISO5832/3, ISO5832/11, GB/T3623-2007, GB/T13810-2007, ASME ER Ti
3)Size: Dia 0.1-6.0mm*Coil, Dia 1.0-6.0*Coil or Straight
4)Application: Medical: Titanium tooth, Titanium surgical instruments, knee joints, shoulder joints, Ribs, active heart valves, the skull bones clip, artificial tooth root and so on.
Product name | Straight / spool / coil ASTM GR5 GR2 Gr1 polished Titanium Wire |
Standard | ASTM B348, ,ASTM SB348,ASTM B863,AWSA5.16, ASTM F67, ASTM F136 |
Material | Titanium Alloy and pure titanium, Titanium Nickel Shape Memory Alloy Wires |
Color | Matal gray |
Grade | GR1, GR2, GR3, GR4, GR5, 6AL4V Eli, GR7, GR9, GR12, GR23,TB3, TB6, TC4, TC6, TC11, TC17, TC18 |
Feature | Titanium has low weight, excellent high strength, excellent corrosion resistance. |
Shape | Straight / spool / coil |
Application | Structural parts wire: mainly used for structural parts and fasteners; Welding wire:mainly used for the electrode material and welding materials Medical wire |
Diameter | 0.5-4.0 (mm) |
Condition | Annealed (M) hot state (R) cold state (Y) (annealing, ultrasonic flaw detection) |
Certificate | ISO9001-20089, AS 9001 |
Surface | Acid pickling or polishing surface |
Packaging | Ply-wooden case, carton box,As customer's requirement |
Related Titanium Products | Titanium sheet/plate,Titanium bar/rod,Titanium wire,Titanium tube/pipe,Titanium target, Titanium fastener,Titanium anode,Titanium flange,Titanium ring, Titanium disc,titanium machining parts,titanium pipe fittings |
Our Advantages | Titanium products manfacturer with 10 years experience Providing you with competitive price Quality control with IOS9001 Guarantee 100% titanium sponge melting,refuse recycle re-melting Meeting 100% of your needs on time |
Delivery time | Within 3-20 days |
Payment | T/T, L/C at sight, as your inquiry |
Grade and Chemical Composition (%) :
Grade | N | C | H | Fe | O | Al | V | Ni | Ti |
Gr1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | bal |
Gr2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | bal |
Gr3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | bal |
Gr4 | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | / | / | / | |
Gr5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5~6.75 | 3.5~4.5 | / | bal |
Gr7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | bal |
Gr9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | bal |
Gr12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.6~0.9 | bal |
Mechanical property
Grade | Tensile strength(min) | Yield Strength(min) | Elongation(%) | ||||
ksi | MPa | ksi | MPa | ||||
Gr1 | 35 | 240 | 20 | 138 | 24 | ||
Gr2 | 50 | 345 | 40 | 275 | 20 | ||
Gr3 | 65 | 450 | 55 | 380 | 18 | ||
Gr4 | 80 | 550 | 70 | 483 | 15 | ||
Gr5 | 130 | 895 | 120 | 828 | 10 | ||
Our advantages
1.Low Density and High Strength
2.Excellent Corrosion Resistance
3.Good resistance to high temperature
4.Excellent Bearing to cryogenic property
5.Good thermal properties
6.Low Modulus of Elasticity
7.Toughness, light weight
8.High property of acid and alkali resistance
2.Excellent Corrosion Resistance
3.Good resistance to high temperature
4.Excellent Bearing to cryogenic property
5.Good thermal properties
6.Low Modulus of Elasticity
7.Toughness, light weight
8.High property of acid and alkali resistance
Product specification
garde | production method | Specification | |||
Gr1,Gr2,Gr3,Gr5,BT1-00.BT1-0 | hot rolling | >4.1-60.0 | 0.3-0.5X400-600x<1500mm 0.6-0.8X400-800x<1200mm 0.9-6.0X400-1000x1000-2400mm 0.1-15X400-1200x1000-2400mm 16-60X400-1200x1000-2400mm or according to client's demand | ||
cold rolling | 0.3-4.0 | ||||
Gr5.Gr12.BT5. BT6.BT22.0T4 | hot rolling | >4.1-60 | |||
cold rolling | 0.5-4.0 | ||||
Gr3.Gr4.BT5. BT5-1. BT6 | hold rolling | 4.1-60 | |||
cold rolling | 0.8-4.0 | ||||
technology standard | ASTM B265,ASTM F136,ASTM F 67,ASME SB256,ASTM B381,etc. | ||||
features | Toughness, light weight, High property of acid and alkali resistance, Bear high & low temperature, etc. | ||||
applications | Chemical equipment, Rack, electrode, exchanger, Condensator, Evaporimeter, Medical etc | ||||
Product application
1. At present, more than 80% of titanium and titanium alloy wires are used as welding wires, such as welding of various titanium equipment, welding of welding pipes, welding of turbine disks and blades of aviation jet engine, welding of casing, etc. .
2. Because of its excellent corrosion resistance, titanium wire has been widely used in chemical, pharmaceutical and paper industry. It can be woven into Mesh as seawater filter net, purified water filter net, chemical medicine filter net and so on.
3. Titanium and titanium alloy wires are also used to make fasteners, load-bearing members, springs, etc. because of their good comprehensive properties.
4. In the medical and health sector, titanium and titanium alloy wires are used to make medical devices, crown implants, and skull fixations due to their excellent Biocompatibility.
5.Some titanium wires with shape memory functions, such as nickel titanium, are used to make satellite dishes, shoulder pads for clothing, Bras for women, frames for glasses, etc. .
6. In electroplating and water treatment, titanium and titanium alloy wires are used to make various electrodes.
2. Because of its excellent corrosion resistance, titanium wire has been widely used in chemical, pharmaceutical and paper industry. It can be woven into Mesh as seawater filter net, purified water filter net, chemical medicine filter net and so on.
3. Titanium and titanium alloy wires are also used to make fasteners, load-bearing members, springs, etc. because of their good comprehensive properties.
4. In the medical and health sector, titanium and titanium alloy wires are used to make medical devices, crown implants, and skull fixations due to their excellent Biocompatibility.
5.Some titanium wires with shape memory functions, such as nickel titanium, are used to make satellite dishes, shoulder pads for clothing, Bras for women, frames for glasses, etc. .
6. In electroplating and water treatment, titanium and titanium alloy wires are used to make various electrodes.
FAQ
1.Are you a manufacturer or a trader?
We're a manufacturer with more than years of professional production experience.
2.Can you accept OEM?
Yes, OEM is acceptable. Just pls provide us with the drawing or sample, we will production totally according to your requirements.
3.Can you provide us with the design drawing?
Yeah, of course, we will provide you with the drawing after you paid or prepaid.
4.Can your factory produce products according to our drawings?
Yes, we can. Most products can be customized, including the Logo on products.
5.What kind of your packaging?
Neutral plywood or wooden box packaging or according to customer's requirements.
6.How long is your delivery time?
Normally 30days after payment, and we promise we will deliver as soon as we can.
7.How can we get your price ?
A. We need below information to quote for you:
1). Product Name
2). Standard
3). Material Grade (Chemical Composition)
4). Dimension
5). Quantity
6). The Drawing for Special Parts
