Китай поставка с воздушным охлаждением смазка впускных клапанов винтовой воздушный компрессор инвертор
- Категория: >>>
- Поставщик: Quanzhou Kaifu Machinery Equipment Co. Ltd.
Сохранить в закладки 1600844412386:
Описание и отзывы
Характеристики
Product Description
Specification
BK | Model | Mpa | m3/min | KW | Output pipe diameter | KG | Dimension(mm) |
BK7.5-8G | 0.8 | 1.2 | 7.5 | G3/4 | 200 | 800*620*800 | |
BK7.5G-8 | 0.8 | 1.1 | 7.5 | G3/4 | 200 | 880*510*800 | |
BK11-8G | 0.8 | 1.7 | 11 | G1 | 280 | 1000*670*1090 | |
BK15-8G | 0.8 | 2.4 | 15 | G1 | 280 | 1000*670*1090 | |
BK15-8 | 0.8 | 2.4 | 15 | G1 | 270 | 700*670*1250 | |
BK15-10 | 1.0 | 2.2 | 15 | G1 | 270 | 700*670*1250 | |
BK15-13 | 1.3 | 1.7 | 15 | G1 | 270 | 700*670*1250 | |
BK22-8G | 0.8 | 3.45 | 22 | G1 | 390 | 1200*800*1120 | |
BK22-10G | 1.0 | 3.2 | 22 | G1 | 390 | 1200*800*1120 | |
BK22-13G | 1.3 | 2.7 | 22 | G1 | 390 | 1200*800*1120 | |
BK30-8G | 0.8 | 5 | 30 | G1 1/2 | 470 | 1340*850*1330 | |
BK30-10G | 1.0 | 4.4 | 30 | G1 1/2 | 470 | 1340*850*1330 | |
BK30-13G | 1.3 | 3.6 | 30 | G1 1/2 | 470 | 1340*850*1330 | |
BK37-8G | 0.8 | 6 | 37 | G1 1/2 | 560 | 1340*850*1330 | |
BK37-10G | 1.0 | 5.4 | 37 | G1 1/2 | 560 | 1340*850*1330 | |
BK37-13G | 1.3 | 4.6 | 37 | G1 1/2 | 560 | 1340*850*1330 | |
BK45-8G | 0.8 | 7.1 | 45 | G1 1/2 | 720 | 1480*1030*1340 | |
BK45-10G | 1 | 6.2 | 45 | G1 1/2 | 720 | 1480*1030*1340 | |
BK45-13G | 1.3 | 5.6 | 45 | G1 1/2 | 720 | 1480*1030*1340 | |
BK55-8G | 0.8 | 10 | 55 | G1 1/2 | 790 | 1480*1030*1340 | |
BK55-10G | 1 | 7.2 | 55 | G1 1/2 | 790 | 1480*1030*1340 | |
BK55-13G | 1.3 | 6.2 | 55 | G1 1/2 | 790 | 1480*1030*1340 | |
BK75-8 | 0.8 | 13 | 75 | G2 | 1200 | 1800*1190*1710 | |
BK90-8 | 0.8 | 16 | 90 | G2 | 1240 | 1800*1190*1710 | |
BK110T-8 | 0.8 | 21 | 110 | DN65 | 1630 | 2100*1230*1730 | |
BK110-8 | 0.8 | 21 | 110 | DN65 | 1680 | 2100*1230*1730 | |
BK132T-8 | 0.8 | 24 | 132 | DN65 | 1670 | 2100*1230*1730 | |
BK132-8 | 0.8 | 24 | 132 | DN65 | 1750 | 2100*1230*1730 | |
KS175A-8F | 0.8 | 24 | 132 | DN65 | 1470 | 1800*1230*1670 | |
KA150-8-ll | 0.8 | 22 | 110 | DN65 | 1950 | 2100*1230*1730 | |
KA175-8-ll | 0.8 | 25 | 132 | DN65 | 1990 | 2100*1230*1730 |
Supporting parameters of
BK75-8G air-cooled screw machine
BK75-8G air-cooled screw machine
Name | Model | Brand |
host | SKKE135-C1-7 | SKK |
electric machinery | 75KW-YKQ225M1-2(Y)B35-IP23 | Shanxi Electric Machinery |
intake valve | KVPB08501 | The Red Star |
Temperature control valve | KTVG1-083AL | Yigete |
Minimum pressure valve | KPVB0500450 | The Red Star |
Solenoid valve | The intake valve comes with it | |
coupling | PSEC0653-060-055 | Kaishan Customization |
Cooling fan | 800FZL-C7P33LS6D29 | Fulihua |
Safety valve | DN25-A28X-16T-0.88 | Fuyu |
Air filter | 56 020 300 440T | Kaishan Customization |
Oil filter | 66 135 302EF | Kaishan Customization |
Oil gas separation core | 55220 273360 | Kaishan Customization |
Controller | Contactor | Schneider |
PLC controller | Kaishan Customization |
Screw group | 5: 6-tooth rotor |
Compression method | Continuous, single stage |
Compressed air outlet pressure | 0.8Mpa |
Cooling method | Air-cooled |
Compressed air outlet temperature | 10 ℃~15 ℃ higher than ambient temperature |
Lubricant quantity | 30L |
motor speed | 2960r/min |
Rated power | 75kw |
Exhaust volume | 13 m3/min |
Working weight | Approximately 1200kg |
Upper limit of air temperature | 45℃ |
Lower limit of air temperature | 0℃ |
Fuel consumption | Exhaust oil content less than 3PPM |
Noise | 81dB(A) |
External dimensions (length × wide × Height (mm) | 1800×1190×1710 |
Company Profile
Certifications
Product packaging
FAQ
Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.
Q2: What the exactly address of your factory?
A2: Our company is located in JNo.9 Kaixuan Ave West,Economic Zone Quzhou, Zhejiang, China
Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: What about the voltage of products??Can they be customized?
A5: Yes, of course. The voltage can be customized according to your equirement.
Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.
Q7: How long will you take to arrange production?
A7: 380V 50HZ we can delivery the goods within 7-15 days. Other electricity or other color we will delivery within 25-30 days.
Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.
Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, CPT, etc.
A1: We are factory. And we have ourselves trading company.
Q2: What the exactly address of your factory?
A2: Our company is located in JNo.9 Kaixuan Ave West,Economic Zone Quzhou, Zhejiang, China
Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: What about the voltage of products??Can they be customized?
A5: Yes, of course. The voltage can be customized according to your equirement.
Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.
Q7: How long will you take to arrange production?
A7: 380V 50HZ we can delivery the goods within 7-15 days. Other electricity or other color we will delivery within 25-30 days.
Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.
Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, CPT, etc.
