Оригинальный HIK 3 дюймовый 4 МП ColorVu Wi Fi мини PT купольная сетевая камера DS 2DE3A400BW DE/Вт (F1)(T5) Встроенный микрофон и динамик Hik камера

Описание и отзывы

Характеристики

• Camera


• Image Sensor1/1.8" progressive scan CMOS


• Min. IlluminationColor: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light


• Shutter Speed1/1 to 1/30,000 s


• Day & Night24/7 colorful imaging


• Zoom16x digital


• Max. Resolution2560 × 1440

• Lens


• Focal Length4 mm


• FOV


  Horizontal field of view: 88.7°




  Vertical field of view: 46.5°




  Diagonal field of view: 105.0°





• ApertureF1.0

• Illuminator


• Supplement Light TypeWhite Light


• Supplement Light RangeWhite Light Distance: up to 30 m

• PTZ


• Movement Range (Pan)350°


• Movement Range (Tilt)0° to 90°


• Pan SpeedPan speed: configurable from 0.1° to 60°/s; preset speed: 60°/s


• Tilt SpeedTilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s


• Proportional PanYes


• Presets300


• Power-Off MemoryYes


• Park ActionPreset, patrol scan


• 3D PositioningYes


• Preset FreezingYes


• Scheduled TaskPreset, patrol scan, dome reboot, dome adjust, aux output

• Video


• Main Stream


  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);




  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)





• Sub-Stream


  50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);




  60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)





• Third Stream


  50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);




  60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)





• Video Compression


  Main stream: H.265+/H.265/H.264+/H.264




  Sub-stream: H.265/H.264/MJPEG




  Third stream: H.265/H.264/MJPEG





• Scalable Video Coding (SVC)H.264 and H.265 encoding


• Region Of Interest (ROI)8 fixed regions for each stream

• Audio


• Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM


• Environment Noise FilteringYes

• Network


• ClientiVMS-4200,Hik-Connect,*Wi-Fi connection with Hik-Connect directly is not possible


• Network StorageNAS (NFS, SMB/ CIFS)


• ProtocolsIPv4/IPv6, HTTP, HTTPS, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour


• APIISAPI, Hikvision SDK, Hik-Connect, Open Network Video Interface (Profile S, Profile G, Profile T), ISUP


• Simultaneous Live ViewUp to 20 channels


• User/HostUp to 32 users. 3 levels: Administrator, Operator and User


• SecurityAuthenticated username and password, MAC address binding, HTTPS encryption, IP address filter


• Web BrowserIE 10+, Chrome 57+, Firefox 52+, Safari 12+

• Wireless (Wi-Fi)


• Wi-Fi ProtocolsIEEE802.11b, 802.11g, 802.11n


• Frequency Range2.4 GHz -2.4835 GHz


• Channel Bandwidth20/40 MHz


• Modulation


  802.11b: CCK, DQPSK, DBPSK




  802.11g: OFDM/64-QAM, 16-QAM, QPSK, BPSK




  802.11n: OFDM/64-QAM, 16-QAM, QPSK, BPSK





• Encryption Mode64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS


• Transfer Rate11b: 11 Mbps, 11g: 54 Mbps, 11n: up to 150 Mbps


• Wireless RangeUp to 50 m

• Image


• Day/Night SwitchDay, night, auto, scheduled-switch


• Image EnhancementBLC, HLC, 3D DNR


• Wide Dynamic Range (WDR)120 dB WDR


• DefogDigital defog


• Regional ExposureYes


• Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser


• Image Parameters SwitchYes


• Privacy MaskUp to 24 masks (8 masks for each scene)


• SNR> 52 dB

• Interface


• Built-In Speaker1 built-in speaker


• Power Output12 VDC; < 60 mA


• Ethernet Interface1 RJ45 10 M/100 M Ethernet interface; PoE (802.3at)


• On-Board StorageBuilt-in memory card slot, support MicroSD/SDHC/SDXC, up to 512 GB


• Alarm1 input, 1 output


• Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω


• RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)


• ResetYes

• Event


• Basic EventVideo tampering alarm, motion detection, alarm input, alarm output, exception


• Smart EventLine crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, audio exception detection


• Alarm LinkagePreset, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, audible warning, white light flashing

• Deep Learning Function


• Face CaptureDetects up to 5 faces simultaneously. Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face picture


• Perimeter Protection


  Line crossing, intrusion, region entrance, region exiting




  Support alarm triggering by specified target types (human and vehicle)
