GP 320FT автоматическая высокоскоростная рулонная этикетка для резки бумаги с помощью машины перемотки турбины
- Категория: >>>
- Поставщик: Wenzhou Goprinto Machinery Co. Ltd.Wenzhou Ltd.
Сохранить в закладки 1600850853058:
Описание и отзывы
Характеристики
Product Description
Specification
Slitting speed | 100m/min |
Max. Web width | 320mm |
Max. Rewinding diameter | 150mm |
Main motor | 8KW |
Voltage | 380V, 3 phase |
Air pressure | 0.8mpa |
Machine weight | About 2000kg |
Dimensions | 3800*1500*1800mm |
Standard configuration:
1. With one bowl feeder (For 25mm/40mm core).
2. With conveyor belt to feed the cores.
3. With 1 automatic finished roll pushing device.
4. With 1 brush press device for finishing roll.
5. With 3 sensors to detect the paper core.
6. With one touch screen to control the machine operation.
7. With 12pcs (4* 40mm 4*25mm, 4* 76mm) non-stop auto inflation rewinding air shafts. (bowl feeder for 76mm is optional)
8. With 2 hot melt gluing system, one for paper core gluing which used to connect the paper core with material. One for
finishing product gluing on material surface to seal the material.
9. With 1 automatic cut unit, comes with penumatic cylinders to lift up/down the cutting knife.
2. With conveyor belt to feed the cores.
3. With 1 automatic finished roll pushing device.
4. With 1 brush press device for finishing roll.
5. With 3 sensors to detect the paper core.
6. With one touch screen to control the machine operation.
7. With 12pcs (4* 40mm 4*25mm, 4* 76mm) non-stop auto inflation rewinding air shafts. (bowl feeder for 76mm is optional)
8. With 2 hot melt gluing system, one for paper core gluing which used to connect the paper core with material. One for
finishing product gluing on material surface to seal the material.
9. With 1 automatic cut unit, comes with penumatic cylinders to lift up/down the cutting knife.
Control system | Bosch Rexroth, Germany |
Servo motor | Bosch Rexroth, Germany |
Photocell | Panasonics, Japan |
Power supply equipment | Mean well, Taiwan |
Touch screen | Weinview, Taiwan |
Online encoder | Tamagawa or Omron, Japan |
Tension sensor | 0.8mpa |
Braker | Chint, China |
Solid Relay | Omron, Japan |
Small relay | Schneider, Germany |
Packing & Delivery
fumigated wooden box
Company Profile
WENZHOU GOPRINTO MACHINERY CO.,LTD is a professiona large-scale manufacturer of printing machine, and auxiliary machines related to labels and spare parts service. We have continuously tried to improve product quality, challenge with advanced innovations. Our main products include printing machine, rotary/flatbed die cutting machine, slitting machine, finishing machine, paper bag making machine ect. Our parent company was established in year 2017, and we have many years of history in the label industry. We have already exported to America, Germany, Russia and 20 other countries and regions. Our company has always focused on research, development and innovation, We regards"reasonable prices, efficient production time and good after-sales service" as our soul tenet. We hope to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us.
FAQ
1. who are we?
We are based in Zhejiang, China, start from 2021,sell to North America(30.00%),Central America(20.00%),South America(10.00%),Western Europe(5.00%),Mid East(5.00%),Southern Europe(5.00%),Eastern Europe(5.00%),South Asia(5.00%),Northern Europe(5.00%),Southeast Asia(5.00%),Eastern Asia(2.00%),Africa(2.00%),Oceania(1.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
flexo printing machine,die cutting machine,slitting machine,fan folding machine,hot lamination machine
4. why should you buy from us not from other suppliers?
For before-order stage, our professional sales team could respond your inquiry within 5-10 minutes during working hours.For after-sale stage, our service team always keep close contact with you and always stand by at your service.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,DDP,DDU,DAF；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
We are based in Zhejiang, China, start from 2021,sell to North America(30.00%),Central America(20.00%),South America(10.00%),Western Europe(5.00%),Mid East(5.00%),Southern Europe(5.00%),Eastern Europe(5.00%),South Asia(5.00%),Northern Europe(5.00%),Southeast Asia(5.00%),Eastern Asia(2.00%),Africa(2.00%),Oceania(1.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
flexo printing machine,die cutting machine,slitting machine,fan folding machine,hot lamination machine
4. why should you buy from us not from other suppliers?
For before-order stage, our professional sales team could respond your inquiry within 5-10 minutes during working hours.For after-sale stage, our service team always keep close contact with you and always stand by at your service.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,DDP,DDU,DAF；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
