Высокое качество трения перемешивания сварочный аппарат
13 521 369,00-13 639 977,50 ₽
Joinforces бренд высокого качества 40 тонн фрикционный сварочный аппарат
- Категория: >>>
- Поставщик: Zhonghe Machinery Technology(dalian) Co. Ltd.Zhonghe Ltd.
Сохранить в закладки 1600851002742:
Описание и отзывы
Характеристики
Product Overview
Worth mentioning are welding machines with single or double head stocks (1 to 500 tons) on the "Joinforces" friction welding machine platform.What is more popular with customers is the "Joinforces" brand friction welding machine under ZhongHe Machinery Technology, which can customize various loading and unloading automation systems for customers, and can also design and configure other related operating functions such as manipulators, etc., to make friction welding work more efficient.
Advandages
1. Easily joins dissimilar metals. This means the ability to use more expensive corrosion resisting materials where needed, and
less resistant but sufficiently strong materials where there is no need- on the same part.
less resistant but sufficiently strong materials where there is no need- on the same part.
2.The welding process consumes its own base material to achieve metallurgical bonding, resulting in friction welding joints with
forging-quality strength.
forging-quality strength.
3.The full surface of the cross section is made up of both metals, airtight and absent of voids.Friction welds often cost less as
there are no consumables like filler metals fluxes.
there are no consumables like filler metals fluxes.
PRODUCT SPECIFICATIONS
Product Name | Rotary Friction Welding Machine |
Max upset force | 25-1200 KN |
Welding diameter | 3-120 mm |
Clamping length of rotation fixture | 50-300 mm |
Clamping length of movement fixture | 80-450 mm or unlimited |
Max stroke of workable | 300 mm |
RPM | 500-1800 r/min depends |
Application
Aircraft/ Aerospace
1. cluster gear cross section
2. cluster gear
Aircraft/ Aerospace
3. inconel 718 tube to rotor assembly
4. low compression titanium
Aircraft/ Aerospace
5. jet engine compressor rotor as welded
Oil Field Pieces
1.Butterfly valves. Wrought stainless steel extension welded to investment
cast stainless steel butterfly valve
cast stainless steel butterfly valve
Oil Field Pieces
2.High-pressure valve body. Forged flanges welded to forged valve body
Oil Field Pieces
3.Cross-section of high-pressure valve body weld.
Oil Field Pieces
4. Geological core drill. SAE4140 end blank welded to SAE4140 tubing.
5.Sucker rod. Threaded end connector to forged sucker rod.
Oil Field Pieces
6.Oil well drill pipe. Close-up of tooljoint to drill pipe weld. Female end.
7.Oil well drill pipe. Close-up of tooljoint to drill pipe weld. Male end.
Oil Field Pieces
8.Cross-section of Inertia Welded manifold tubing used on oil well heads.
Bimetallic & Special Applications
1. Carbon steel/stainless steel marine outboard engine drive shaft
2. Bimetallic pump motor shaft. Stainless steel stub joined to carbon steel shaft
