En aw 7075 5754 t6 t5 алюминиевый сплав алюминиевая листовая
- Категории: Aluminum Sheets >>>
- Поставщик: Shanghai,Hengtie,Steel,Trading,Co.,Ltd.
Сохранить в закладки:
Описание и отзывы
Характеристики
Product Description
Bozhong Aluminum Sheet Features:
Light weight Low cost
Easier and convenient to install
Environmental friendly and energy saving
Anti-dirt and self-cleaning
Corrosion resistant and moisture proof
Weathering resistance stronger than stone material and valid time longer
Excellent ductility, can be made into various shapes
Light weight Low cost
Easier and convenient to install
Environmental friendly and energy saving
Anti-dirt and self-cleaning
Corrosion resistant and moisture proof
Weathering resistance stronger than stone material and valid time longer
Excellent ductility, can be made into various shapes
Alloy Material:
1000 series:1050 1060 1070 1070A 1100 1050A 1200 1235 1085 1035
2000 series: 2014 2024 2A13 2A12 2017 2A05 2A70 2A80 2A90 2A02 2A06 2A16 2A11 2A12
3000 series: 3003 3004 3005 3103 3104 31053 A21 3A12
4000 series: 4004 4101 4343 4047 4045
5000 series: 5A02 5A03 5A05 5A06 5A12 5083 5086 5182 5251 5052 5752 5754 5454 5005 5042 5051 5063
6000 series: 6061 6063 6005A 6013 6082 6005 6M61 6M63 6Y13 6025 6A02 6082
7000 series: 7075 7072 7050 7A04 7005 7A09 7020 7A16
8000 series: 8011 8A06
2000 series: 2014 2024 2A13 2A12 2017 2A05 2A70 2A80 2A90 2A02 2A06 2A16 2A11 2A12
3000 series: 3003 3004 3005 3103 3104 31053 A21 3A12
4000 series: 4004 4101 4343 4047 4045
5000 series: 5A02 5A03 5A05 5A06 5A12 5083 5086 5182 5251 5052 5752 5754 5454 5005 5042 5051 5063
6000 series: 6061 6063 6005A 6013 6082 6005 6M61 6M63 6Y13 6025 6A02 6082
7000 series: 7075 7072 7050 7A04 7005 7A09 7020 7A16
8000 series: 8011 8A06
Physical Properties | Tensile Strength | Yield Strength | Elongation(%) | ||||
Grade | Hardness | (MPa) | (MPa) | 0.25-1.25mm | 1.26-3.0mm | ||
1100 | O | 89.6 | 34.5 | 30 | 6 | ||
H12 | 110.3 | 103.4 | 4 | 12 | |||
H14 | 124.1 | 117.2 | 3 | 10 | |||
2024 | O | 186.2 | 75.8 | 18 | 20 | ||
T3 | 482.6 | 344.7 | 16 | 18 | |||
T4 | 468.8 | 324.1 | 20 | 19 | |||
3003 | O | 110.3 | 41.4 | 30 | 33 | ||
H12 | 131 | 124.1 | 9 | 11 | |||
H14 | 151.7 | 144.8 | 3 | 7 | |||
5052 | O | 193.1 | 89.6 | 20 | 21 | ||
H32 | 227.5 | 193.1 | 7 | 10 | |||
H34 | 262 | 213.7 | 6 | 8 | |||
5083 | O | 275.8 | 144.8 | 21 | 25 | ||
H32 | 282.7 | 151.7 | 20 | 21 | |||
H34 | 330.9 | 255.1 | 11 | 14 | |||
6061 | O | 124.1 | 55.2 | 25 | 26 | ||
T4 | 241.3 | 144.8 | 22 | 24 | |||
T6 | 310.3 | 275.8 | 12 | 17 | |||
7075 | O | 227.5 | 103.4 | 16 | 18 | ||
T6 | 572.3 | 503.3 | 11 | 12 | |||
Al Sheet Surface Treatment:
Al Sheet Specification
Certificate
We are committed to furnish superior quality products at economical price with schedule consistency. It is our endeavor to follow the principles of total quality management. For our pursuance of Total Quality Management system, we have received ISO 9001 : 2008 certification.The company has developed quality objectives and work plans for quality management. We follow stringent quality control norms by reviewing and monitoring each production processes. These allow us to upgrade our quality processes to superior levels.
Company Introduction
Shanghai Bozhong Metal Group is a very famous metal company in china , the eastern China's commercial power house. We're the leading supplier of metal products in China since 2006 and we've become the listed company in 2018(Stock code 210988). We have six subsidiary corporation located in Shanghai and Hongkong, which have built great relationship with the metal facilities abroad and at home, in order to provide excellent service for our clients.We produce all kinds of steel, stainless steel, titanium alloy, aluminium alloy and nickel-based alloy and so on.
Packing&Shipping
Al Sheet Applications
Alloy | Application field | ||
1xxx | 1050 | Insulation, food industry, decoration, lamp, traffic signs etc. | |
1060 | Fan blade, Lamps and lanterns, Capacitor shell, Auto parts, Welding parts etc | ||
1070 | Capacitor, Rear panel of vehicle refrigerator, charging point, heat sink etc | ||
1100 | Cooker, building material, printing, heat exchanger, bottle cap etc | ||
2xxx | 2A12 2024 | Aircraft structures, rivets, aviation, machinery, missile components, the card wheel hub, propeller components, aerospace parts, car parts and various other structural parts. | |
3xxx | 3003 3004 | Aluminum curtain wall panel, aluminum Ceiling, Electric cooker bottom, TV LCD backboard, storage tank, curtain wall, building construction panel heat sink, billboard. | |
3005 3105 | Industrial floor, air conditioning, refrigerators radiators, Make-up board, Prefabricated house etc | ||
5xxx | 5052 | Marine and transportation material, railway carriage's inner and outer cabinet, oil and chemical industry storage device, equipment and medical device panel etc. | |
5005 | Marine applications, bodies of boats, buses, trucks and trailer. Curtain wall panel. | ||
5086 | Ship board, deck, bottom and edge panel etc. | ||
5083 | Tanker, oil storage tank, drilling platform, ship board, deck, bottom, welded parts and edge panel, railway carriage 's board, automotive and aircraft panel, cooling device and automotive molding etc. | ||
5182 | |||
5454 | |||
5754 | Tanker body, marine facilities, pressure container, transportation etc. | ||
6xxx | 6061 | Railway inside and outside parts, board and bed plate. | |
6083 | Industry molding | ||
6082 | Highly stressed applications includes Roofing construction, transportation, and marine as well as mould. | ||
6063 | Auto parts, architectural fabrication, window and door frames, aluminum furniture, electronic components as well as various consumer durable products. | ||
7xxx | 7005 | Truss, rod/bar and the container in transportation vehicles; Large-sized heat ex changers | |
7050 | Molding (bottles) mode, ultrasonic plastic welding mold, golf head, shoe mold, paper and plastic molding, foam molding, lost wax mold, templates, fixtures, machinery and equipment | ||
7075 | Aerospace industry, military industry, electronic etc | ||
