Product Formation
|
BOPP/PET Film,Aluminum Foil,Complexing Agent ,Release Agent,Glue,Release Paper of Composite/Release liner
|
Aluminum foil
|
8011 O State
|
Glue
|
Water-borne pressure sensitive adhesive/Hotmelt adhesive/Oil adhesive/Rubber
|
Total thickness of product substrate
|
Hand Used:25um-45um Machine Used:40um-55um Pure Aluminum:20um-60um High Temperature:55um-60um With Lining Paper:15um-120um Blue Tape:30um
|
Total thickness of product
|
Hand Used:55um-85um Machine Used:70um-85um Pure Aluminum:50um-100um High Temperature:85um-95um With Lining Paper:40um-170um Blue Tape:55um-60um
|
Temperature resistance
|
Water-based acrylic pressure sensitive adhesive——120℃
|
Oil Resistant High Temperature Pressure Sensitive Adhesive——160℃
|
With lining paper PET compound aluminum foil tape——120℃ to 280℃
|
Width and length of finished product: Can be customed by request.
|
Hand Used——Regular: 45mm*50m 50mm*50m Machine Used——Regular: 45mm*300m 50mm*300m Pure Aluminum——Regular: 40mm*50m 45mm*50m 50mm*50m High Temperature——Regular: 60mm*200m With Lining Paper——Regular:50mm*50m Blue Tape——Regular: 20mm*50m
|
Product adhesive force (Room temperature:23℃)
|
Hand Used:13# Machine Used:13# Pure Aluminum:12# High Temperature:18# With Lining Paper:14#
|
180° peel strength (Room temperature:23℃)
|
Hand Used:11.8N/25mm Machine Used:11.8N/25mm Pure Aluminum:11.25N/25mm High Temperature:30N/25mm With Lining Paper:11.92N/25mm
|
Product holding force (Room temperature:23℃)
|
Hand Used:≥48h/25mm Machine Used:≥48h/25mm Pure Aluminum:≥48h/25mm High Temperature:≥150h/25mm With Lining Paper:≥48h/25mm
|
Use of the product
|
Refrigerators,Freezers, Water Fountains,Washing Machines,Air Conditioners,Fireworks,Pipeline,Heat Insulation Pipelines,Incubators,Television Sets,Computers,Furniture,Electronic Appliances, Cooker Hoods,Tea Bar Machines,Vessels,Ovens,Floor Heating System,etc.
|
