Product Description
MUST PV33TLV series off grid split phase solar inverter 5000w 48v110v 220v
MUST PV33TLV series off grid split phase solar inverter 5000w 48v110v 220v
MUST PV33TLV series off grid split phase solar inverter 5000w 48v110v 220v
| FEATURES |
| * Pure sine wave output |
| * Friendly user interface;MFD (multi-function display) |
| * 3 Steps charging |
| * Overload and short-circuit protection |
| * Set charging voltage/charging current |
| * Battery low voltage shutdown point can be set to 10/10.5/11V |
| * Set utility priority/ Battery priority |
| * Set utility input wide/narrow range |
| * Inverter voltage can be set to 100/110/120;frequency can be set to 50/60Hz |
| * Set utility charging on/off switch |
| * Built-in 80A MPPT charger |
Tech Specs
5000w solar inverter 5000w solar inverter 5000w solar inverter 5000w solar inverter 5000w solar inverter
| MODEL | PV33-1012 TLV | PV33-1024 TLV | PV33-1512 TLV | PV33-1524 TLV | PV33-2012 TLV | PV33-2024 TLV | PV33-3024 TLV | PV33-3048 TLV | PV33-4024 TLV | PV33-4048 TLV | PV33-5048 TLV | PV33-6048 TLV |
| Inverter Output | ||||||||||||
| Rated power | 1KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW | |||||
| Power factor | 1 | |||||||||||
| Wave form | Pure sine wave | |||||||||||
| Output voltage RMS | 100V 110V 120VAC(200V 220V 240VAC)±10% | |||||||||||
| Output frequency | 50Hz or 60Hz (±0.3Hz) | |||||||||||
| Inverter efficiency (peak) | >85% | |||||||||||
| Overload | 100%<Load<110% (alarm 5min then stop output ) 110%<Load<125% (alarm 60s then stop output) Load > 125% (alarm 10s then stop output ) | |||||||||||
| Surge rating | 3000VA | 4500VA | 6000VA | 9000VA | 12000VA | 15000VA | 15000VA | |||||
| Capable of starting electric motor | 1P | 1P | 1.5P | 1.5P | 2P | 3P | ||||||
| Battery | ||||||||||||
| Battery voltage | 12VDC/24VDC | 24VDC/48VDC | 48VDC | |||||||||
| Minimum start voltage | 11VDC/22VDC/44VDC | |||||||||||
| Low battery voltage cut off | (Low voltage fault code04)1010.511V for 12V mode ; 202122V for 24V model ; 404244V for 48v model | |||||||||||
| Low battery voltage alarm | Add 0.5V battery:(Low battery alarm one second one time) (10 10.5 11V)+0.5VDC for 12V mode, (20 21 22V) +1Vdc for 24v model (40 42 44V) +2Vdc for 48v model | |||||||||||
| High battery voltage alarm | Add +1Vbattery: (high voltage one second one timeafter 30s fault 03) (13.8-14.5V) + 1V for 12V model, (27.6-29V) + 2V for 24v model (55.2-58) + 4V for 48v model | |||||||||||
| Save mode | Loads ≤ 40W (110V) 80W (220V) | |||||||||||
| AC Input Mode | ||||||||||||
| Input waveform | Pure sine wave | |||||||||||
| Nominal input voltage | 200Vac 220Vac 240Vac | |||||||||||
| Max input voltage | 270Vac MAX | |||||||||||
| Input frequency | 50Hz 60Hz (auto sensing) | |||||||||||
| Efficiency (AC mode) | >95% (load, full battery) | |||||||||||
| Transfer time AC to DC | 15ms(typical) | |||||||||||
| Charge Mode | ||||||||||||
| 12V | 30A | 45A | 60A | |||||||||
| 24V | 20A | 25A | 30A | 40A | 60A | |||||||
| 48V | 20A | 30A | 35A | 40A | ||||||||
| Min charge current 10A. Change by every 5A | ||||||||||||
| Dimensions | ||||||||||||
| Dimensions (W*H*D) | 277*196*466mm | 277*186*621mm | ||||||||||
| Ship Dimensions (W*H*D) | 376*306*592mm | 376*296*747mm | ||||||||||
| Warranty | One year (standard), 2 years optional (IP20) | |||||||||||
Packaging & Shipping
1. Package: Carton Box for packaging or Wooden Box advised for samples to protect in transportations.
Package designed by clients is welcomed.
2. Shipping: DHL, FEDEX, UPS, EMS, Air Way and By Sea.
3. Payment: T/T and Western Union
4. Sample order: Welcome to place your Sample Order to test first.
Company Information
MUST, More than 30 senior engineers from the world famous industrial automation and new energy enterprises with rich experience, to provide you one-stop solutions.
Main products include: uninterrupted power supply (UPS),solar inverter, Power inverter, solar charge controller and lead-acid battery.
MUST products possess certification of CE, SAA, SONCAP, SGS, TLC, etc. And have passed the standard of quality management system of ISO:9001, ISO:14000. It also get national awards such as green environmental protection promotion products, energy-saving products, etc.
MUST products exported to different parts of the world such as Spain, Italy, Russia, Australia, the Middle East, Ukraine, South Africa, Nigeria, Pakistan, etc.
Our Services
Warranty: 1 Year
Lead time:
a) Sample orders (1-2 pcs) will be delivered from our factory within 10 working days
b) Bulk orders will be delivered from our factory within 35 working days
After-sale Service: 24-Hour Hot Line for Consultancy and Technical Support
Certifications
FAQ
Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.
Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.
Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.
Q4: What is the warranty of inverter?
A4: One year warranty on Must product.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
5000w solar inverter 5000w solar inverter 5000w solar inverter 5000w solar inverter 5000w solar inverter
