Палубный кран с боковой сочлененной стрелой

    The Marine crane series is a crane that is fitted with a special base for an easy and fixed installation on any kind of vessel, central controls and distributor disjoint from the structure.



    Marine crane is a kind of special crane used for transportation in the Marine environment. It is mainly used for the transportation and transfer of cargo between ships, replenishment at sea, dropping and recovering of underwater operation equipment and other important tasks.





Type	Safety L oad (kN)	Max Working Rod (m)	Min Working Rod (m)	Hoisting Speed (m/min)	Slewing Speed (m/min)	Luffing Time (s)	Hoisting Hei ght (m)	Slewing Angle (° )	Permissible Heel ing (transversdongi tudinal	Motor Type	Power (kW)
YQ1	10	6~12	1.6~3. 3	15	1	60	30	360	2*/~5	YH1321-4	7.5
YQ1.5	15	8~14	2.2~3.7	15	1	60	30	360	2 /~5	YH160M-4	11
YQ2	20	5~15	1.4~4.0	15	1	60	30	360	2*/*5	YH160L-4	15
YQ3	30	8~18	2.2~4.8	15	0.9	70	30	360	2 /~5	YH180L-4	22
YQ5	50	12"20	3.3~5.3	15	0.75	80	30	360	2*/~5	YH225S-4	37
Y08	80	12~ 20	3.3~5.3	15	0.75	100	40	360	2"/~5	YH225M-4	55
Y010	100	12~20	3.3~5.3	15	0.75	110	40	360	2*/~5	YH280S-4	75
Y015	150	12~20	3.3~5.3	15	0.6	110	50	360	2 /~5	YH280M-4	90
Y020	200	15~25	4~5.6	15	0.6	120	50	360	2*/~5	YH280S-4	75*2
Y025	250	15~ 30	4~7.9	15	0.5	130	50	360	2" /~5	YH280M-4	90*2
Y030	300	15~ 30	4~7.9	15	0.4	140	60	360	2*/~'5	YH280M-4	90*2







Product Description:This series of products is a full hydraulic lifting equipment for Marine crane. The arm section of the product is made of pentagonal structure, high strength plate, telescopic arm, hydraulic winch independent lifting, with stable performance, compact appearance, beautiful and other characteristics.

Product Features:1.Safe and reliable design, beautiful appearance.

2.Small installation space, light weight, large lifting quality.

3.Integral rotary device has high transmission efficiency and high torque.

4.Planetary hoist, effectively reduce the system temperature, faster operation speed, higher reliability.

Q1: How many years of your factory?
A1: We have 20 years production and nearly 10 years External trade experience, we exported to more than 100 countries & regions.And we are a manufacturer specialized in ODM&OEM Marine deck machinery and equipment.

Q2: how can we guarantee quality?
A2: Always a pre-production sample before mass production;
Always final Inspection before shipment;

Q3:what can you buy from us?
A3:Winch,Windlass,Telescopic Crane,Steering Gear,Control Cabinet,Bridge
,Capstan Windlass.

Q4:why should you buy from us not from other suppliers?
A4:1. More than 20 years crane exporting experience
2. Enough experience on Marine deck machinery.
3. After sale service.
4. Exporting our crane to more than 100 countries.
5. Installation team.

Q5: what services can we provide?
A5:Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Western Union,Escrow;
Language Spoken:English,Chinese,Spanish,French,Russian
