Крупномасштабная линия по производству фарфорового клея новейшая технология Производство плитки завод сухих растворных смесей
975 870,76 ₽ - 2 192 858,36 ₽
Высокоэкономичная полностью автоматическая машина для смешивания сухих растворов клеящего раствора с контроллером PLC
- Категория: >>>
- Поставщик: Zhengzhou Mg Industrial Co. Ltd.
Сохранить в закладки 1600902180743:
Описание и отзывы
Характеристики
Product Despction
No. | Name | Model | Model | Specification | |
1 | Raw Material Storage System | Detachable Silo | Detachable Silo | 60T, 100T, 150T | |
2 | Conveying System | I | Screw Conveyor | Diameter 165mm,219mm,273mm | |
3 | Lifting and filling system | II | Indoor Bucket Elevator | 15-45T/H | |
4 | III | Outdoor Bucket Elevator | 15-100T/H | ||
4 | Small additives hopper &weighting system | Small additives &weighting system | Dust collector, raw material hopper, screw & weighting system, platform | ||
5 | Main material Batching & Weighing System | Batching & Weighing Hopper | Batching & Weighing Hopper | raw material silos, screw & weighting system, platform | |
5 | Mixing System | I | Twin shafts agravic mixer | 2m3, 3m3, 4m3, 6m3, 8m3, 10m3 | |
II | Premix hopper | 2m3, 3m3, 4m3, 6m3, 8m3, 10m3 | |||
III | End product hopper | 2m3, 3m3, 4m3, 6m3, 8m3, 10m3 | |||
6 | Packing System | Automatic Valve Packing machine | Automatic Robot Valve Port Packing machine | 15-50kg/bag adjustable, 5-6s/bag | |
7 | Control System | PLC Control Cabinet | PLC Control Cabinet | Touchable display or computer type | |
8 | Dust colllector | Pulse Dedust Filter | MG5, MG12, MG24,MG36,MG48. | ||
9 | Air Compressor | High Pressure Air Supply | High Pressure Air Supply | 0.25/0.36/0.6/0.9/1.1/1.6/2.4/3.5/6.2 m3/min | |
10 | Steel Structure | 2/3-Layer Steel Platform | 12#,14#,16#,18#,20# | ||
11 | Bag Belt Conveyor(Optional) | Roller type belt conveyor | B500*4000mm | ||
Main configuration:
Electric control cabinet; Cement silo, Weighing system; Feeding hopper; Impulse dust collector; Bucket elevator; Premix tank; Twin shaft agravic mixer; Finished product holding tank; Automatic packaging machine; Air compresser.
It can be equipped with grinding machine and drying machine according to requirement.
Application
This dry mortar mixing plant can produce following dry mortar:
Bonding mortar: Masonry mortar, wall and floor tile adhesive mortar, tile glue, anchorage mortar etc.
Decoration mortar: Decorative plaster, Thin set coating, inner and outer wall putty, Screed mortar, colorful decoration mortar etc.
Protection mortar: Water-proof mortar, anti-corrosion mortar, self-leveling mortar, wear resistance mortar, thermal insulation mortar, sound insulation mortar, AAC jointing mortar, dry sand mixture, repair mortar, mildewproof mortar, shielding mortar etc.
Decoration mortar: Decorative plaster, Thin set coating, inner and outer wall putty, Screed mortar, colorful decoration mortar etc.
Protection mortar: Water-proof mortar, anti-corrosion mortar, self-leveling mortar, wear resistance mortar, thermal insulation mortar, sound insulation mortar, AAC jointing mortar, dry sand mixture, repair mortar, mildewproof mortar, shielding mortar etc.
Product Configuration
Customers Visit Our Company
Certificates
Packaging & Delivery
Our Company
FAQ
1.What product can this production line make?
Our automatic dry mortar production line can make all kinds of dry mortar,such as wall putty,plaster,skim coat,ceramic tile adhesive,and so on.
2.What is the attentions we should pay when we use ceramic tile adhesive?
1).Because the adhesiveness of the tile adhesive is very large, it is necessary to pay attention to stirring evenly when using it.It is best to use an electric mixer for stirring, which can better ensure the uniformity of the tile adhesive.
2).When using tile adhesive, pay attention to protective treatment to avoid the phenomenon of tiles falling off, especially in rainy days, do not directly contact with tile adhesive to avoid reducing the adhesiveness of tiles.
3.Do you have your own factory?
We have our own factory. Located in Zhengzhou City, Henan Province, China, welcome to visit our factory.
In addition, we have long-term cooperative relationships with some excellent raw material suppliers to ensure that the prices of the products we supply are lower than other foreign trade companies.
4. What should we do if the mixer rotates hard?
2.What is the attentions we should pay when we use ceramic tile adhesive?
1).Because the adhesiveness of the tile adhesive is very large, it is necessary to pay attention to stirring evenly when using it.It is best to use an electric mixer for stirring, which can better ensure the uniformity of the tile adhesive.
2).When using tile adhesive, pay attention to protective treatment to avoid the phenomenon of tiles falling off, especially in rainy days, do not directly contact with tile adhesive to avoid reducing the adhesiveness of tiles.
3.Do you have your own factory?
We have our own factory. Located in Zhengzhou City, Henan Province, China, welcome to visit our factory.
In addition, we have long-term cooperative relationships with some excellent raw material suppliers to ensure that the prices of the products we supply are lower than other foreign trade companies.
4. What should we do if the mixer rotates hard?
The main function of the dry powder mortar mixer is to mix and stir various raw materials in the tank. If the dry powder mortar mixer is difficult to stir, there are generally two reasons. One is the lack of power. Another reason for using a small mixer or using a low-speed mixer is that the amount of water added is insufficient. Enough water must be added in accordance with the production ratio so that the machine can run normally.
5. What should we do if there is material agglomeration?
The agglomeration of materials may be the reason that too many materials are stirred and input at one time during operation. We can place the agglomerated materials statically for two or three minutes, and the materials will loosen by themselves. Another reason may be that the storage time of the production materials is too long. , or the external conditions of material storage are not up to standard, in this case we can only replace the material, and then pay attention to the storage space of the raw material in the
next production must be kept dry and ventilated.
next production must be kept dry and ventilated.
6. What should we do if the mixer doesn't mix the material average?
The reason for the uneven mixing of dry mortar may be that the operator put the material first and then add water, and the second may be that the size or power of the mixer selected by the user is not suitable. In order to ensure the good mixing effect of the machine, the user not only The materials need to be put in in
the normal order, and at the same time, the appropriate mixer should be selected according to the production needs.
If you want to know more of our dry mortar plant, please send us inquiry or leave your contact number for us.
the normal order, and at the same time, the appropriate mixer should be selected according to the production needs.
If you want to know more of our dry mortar plant, please send us inquiry or leave your contact number for us.
