Высококачественная батарея топливных элементов 50 ~ 80 В компактный реформер метанола водородный топливный элемент для автономной сети
- Категория: >>>
- Поставщик: WOBO Industrial Group Corp.WOBO Corp.
Сохранить в закладки 1600904460695:
Описание и отзывы
Характеристики
Safe and Reliable Methanol Reformer Hydrogen Fuel Cells
Best Quality Fuel Cell Stack Dc+50~80V Compact Size Methanol Reformer Hydrogen Fuel Cell For Off-Grid
Product Description
Product Parameters
Fuel Cell Type | High-temperature Proton Exchange Membrane Fuel Cell | Hydrogen Source | Methanol Reforming for Hydrogen Production, Atmospheric Pressure, On-Demand | |||
Rated Power | 5kW | Power Range | 0~5.4kW | |||
Rated Voltage | 72V | Rated Current | 70A | |||
Output Voltage Range | DC+50~80V | Output Current Range | 0~80A | |||
Size | 850x450x200mm | Weight | 65KG | |||
Normal Startup Time | ≤15min | Cold Start Time | <30min | |||
Operating Temperature | -40℃~+50℃ | -40°℃Startup | Feasible with the addition of insulation and other components for maintaining temperature. | |||
Standby Power Consumption | <100W | Tailpipe Emissions | CO2+water vapor，no NOx or SOx emissions | |||
Volume | 76.5L | Fuel Consumption | ≤1L/kWh | |||
Methanol-Water Ratio | 54% methanol: 46% water | Cooling System | Air-cooled | |||
Fuel Cell Stack Efficiency | ≥46% | Overall System Efficiency | >62.45% | |||
Combined Heat and Power Efficiency | ≥85% | Operating Mode | Can be operated individually, in a network, or controlled remotely. | |||
Service Life | >5000H | Noise Limit | ≤70dB | |||
Altitude | ≤4000M | Maintenance Components | Equipped with air filters and methanol-water filter elements. | |||
Fuel Tank Capacity | 40L/80L/120L/… | Integrated Lithium Battery Pack | 5kWh/10kWh/… | |||
For more information, please contact us. | ||||||
Technical Principle
The Methanol Reformer Hydrogen Fuel Cell operates by utilizing methanol-water as fuel to produce hydrogen on-site. To achieve this, the fuel cell stack's membrane electrode reactions are conducted at an elevated temperature. This process leads to the generation of hydrogen gas with a concentration of 75%. The generated hydrogen gas is used directly for power generation within the fuel cell, eliminating the need for purification or storage. This approach ensures safety, reliability, and efficient power generation, enhancing the kinetics and performance of the fuel cell's electrochemical reactions.
Detailed Photos
Main Solutions
In situations without access to the power grid, as long as there is sufficient supply of methanol fuel, the methanol micro power plant will continue to provide power to the load equipment theoretically for an unlimited 24/7 period.
Applicable scenarios:
* Base stations or sites without access to grid power
* Base stations or sites temporarily without grid power due to factors such as construction, disputes, or relocation
* Places like islands, border outposts, civil air defense facilities, etc., lacking grid power supply
* Base stations or sites without access to grid power
* Base stations or sites temporarily without grid power due to factors such as construction, disputes, or relocation
* Places like islands, border outposts, civil air defense facilities, etc., lacking grid power supply
During normal grid power supply, the methanol micro power plant remains in standby mode, providing power to the load via a DC rectifier. In the event of a power outage, the methanol micro power plant automatically starts up, delivering reliable and stable power to equipment at base stations or substations. With methanol supply available, the methanol micro power plant will continue to power the load equipment theoretically indefinitely until grid power is restored. Once grid power is restored, the methanol micro power plant automatically shuts down and returns to standby mode.
Applicable scenarios:
* Base stations or sites in areas prone to frequent power outages, with limited transportation access, or located in remote mountainous regions
* Critical base stations or sites such as VIP or nodal stations requiring uninterrupted power supply
* Base stations or sites in urban or sensitive areas where noise and vibration levels must be minimized
* Tourist attractions or sites with special power supply requirements
* Base stations or sites in areas prone to frequent power outages, with limited transportation access, or located in remote mountainous regions
* Critical base stations or sites such as VIP or nodal stations requiring uninterrupted power supply
* Base stations or sites in urban or sensitive areas where noise and vibration levels must be minimized
* Tourist attractions or sites with special power supply requirements
