Cheap price 4 color Kraft paper bag flexographic printing machine
with UV ink
4 Colors Flexographic Printing Machine
333
6 Colors Flexographic Printing Machine
Product Description
Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.
CONFIGURATION DETAILS
1. Adopts the synchronous belt drive
2. Machine running more quite, higher printing precision, good quality;
3. Machine more stability;
4. High Mechanical speed: 110m/min
5. High printing speed: 30-90m/min ( optional: speed can improve to 110m/min)
6. Automatic tension control
7. EPC,web guide
8. Single unwind & Single rewind
2. Machine running more quite, higher printing precision, good quality;
3. Machine more stability;
4. High Mechanical speed: 110m/min
5. High printing speed: 30-90m/min ( optional: speed can improve to 110m/min)
6. Automatic tension control
7. EPC,web guide
8. Single unwind & Single rewind
MATERIALS AND ELECTRICAL PARTS
Raw Material: PE, PVC, PP, Non Woven And Etc.
Electrical Parts: Siemens Motor+Schneider Electrical+Delta Inverter+Schneider Breaker+Schnieder AC Contactor
Electrical Parts: Siemens Motor+Schneider Electrical+Delta Inverter+Schneider Breaker+Schnieder AC Contactor
FEATURE
1. Easy operation, gentle starting, accurate color print.
2. The meter counter can set print quantity according the requirements, stop the machine automatically at the quantity or when the material is cut off.
3. After lifting and lowering the printing plate cylinder manually, It will automatically stir the printing in.
4. The printing in is spread by the anilox cylinder roller with evenly ink.
5. Reliable dry system, coordinate high-speed operation, engine off automatic abruption.
6. 360 degrees continuously adjustable longitudinal to register device.
7. Frequency conversion velocity modulation, adaption different pointing speed.
8. On the version roller sear and receives on material to be loaded with the spot to move and the pause button, is advantage for when the justification operates the machine.
2. The meter counter can set print quantity according the requirements, stop the machine automatically at the quantity or when the material is cut off.
3. After lifting and lowering the printing plate cylinder manually, It will automatically stir the printing in.
4. The printing in is spread by the anilox cylinder roller with evenly ink.
5. Reliable dry system, coordinate high-speed operation, engine off automatic abruption.
6. 360 degrees continuously adjustable longitudinal to register device.
7. Frequency conversion velocity modulation, adaption different pointing speed.
8. On the version roller sear and receives on material to be loaded with the spot to move and the pause button, is advantage for when the justification operates the machine.
SPECIFICATION
Remarks: The above models can be customized according to requirements (parameters are for reference only);
The max.width can be 4m.
Model | DP-FP600 | DP-FP800 | DP-FP1000 | DP-FP1200 | DP-FP1400 | DP-FP1600 | |||||
Max. print width | 560mm | 760mm | 960mm | 1160mm | 1360mm | 1560mm | |||||
Printing colors | Customized (1-8 colors) | ||||||||||
Printing length | 190 - 1060 | 190 - 1060 | 190 - 1060 | 190 - 1060 | 190 - 1060 | 190 - 1060 | |||||
Mechanical speed | 90m/min | 90m/min | 90m/min | 90m/min | 90m/min | 90m/min | |||||
Printing speed | 5-70m/min | 5-70m/min | 5-70m/min | 5-70m/min | 5-70m/min | 5-70m/min | |||||
Register precision | 0.25mm | 0.25mm | 0.25mm | 0.25mm | 0.25mm | 0.25mm | |||||
Unwind/Rewind diameter | 450mm | 450mm | 450mm | 450mm | 450mm | 450mm | |||||
Dry way | electric dry | electric dry | electric dry | electric dry | electric dry | electric dry | |||||
Weight | 1800kg | 2000kg | 2200kg | 2400kg | 2600kg | 3000kg | |||||
Machine Power | 12kw | 14kw | 16kw | 18kw | 20kw | 22kw | |||||
Machine Size | 3.6x1.8x2.3m | 3.6x2.0x2.3m | 3.6x2.2x2.3m | 3.6x2.4x2.3m | 3.6x2.6x2.3m | 3.6x2.8x2.3m | |||||
Machine Details
Normal Speed: Supr Gear, Wall thickness 50mm
Printing speed: 50m/min
Medium Speed: Helical Gear, Wall thickness 75mm
Printing speed: 70m/min
High Speed: Synchronous Pulley, Wall thickness 75mm
Printing speed: 90-120m/min
Printing Unit
Closed Scraper
Dust Cover
Oven
Automatic Tension Control (Optional)
Company Profile
Hangzhou Depai Machinery Co., Ltd has several production lines in different workshops from printing machines, bag making machine, label sticker die cutting & slitting machines, paper /PP/PLA straw machines, disposable products making machines, to different plastic&paper and packaging machines.
We have a professional after-sales service team to provide you with high quality service. Engineers who can speak English can come to your factories or workshop to help you debug your machine and provide free training by video call. Our factory also cooperated with some famous French and German companies. Every year, our production director and technical director will go to the European cooperation technology companies or large factories for technical study. By communicating and learning from each other, it ensures the high quality of each machine and our technology is always far ahead in China.
Depai Machinery Look forward to working with you!
We have a professional after-sales service team to provide you with high quality service. Engineers who can speak English can come to your factories or workshop to help you debug your machine and provide free training by video call. Our factory also cooperated with some famous French and German companies. Every year, our production director and technical director will go to the European cooperation technology companies or large factories for technical study. By communicating and learning from each other, it ensures the high quality of each machine and our technology is always far ahead in China.
Depai Machinery Look forward to working with you!
Factory Overview
FAQ
1. Q: How does your factory do regarding quality control?
A: Quality is priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.
2. Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems.The Warranty is one year and if the machine is damaged by natural not by human, we can send the new parts to you for free.
3. Q:Does the packing strong?
A:Yes,it's wrapping film + wooden case,adopts moisture-proof and shock-proof packaging.
4. Q: What is the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
A: Quality is priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.
2. Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems.The Warranty is one year and if the machine is damaged by natural not by human, we can send the new parts to you for free.
3. Q:Does the packing strong?
A:Yes,it's wrapping film + wooden case,adopts moisture-proof and shock-proof packaging.
4. Q: What is the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
