Высокоэффективная установка для обработки минералов оборудование золотодобычи вращающийся барабанный скруббер мытья золота виброэкран
552 018,00 ₽ - 1 435 246,80 ₽
Малый масштаб Золото Стиральная Центробежный концентратор машина для золота
- Категория: >>>
- Поставщик: Jiangxi Walker Machinery Co. Ltd.
Сохранить в закладки 1600907915411:
Описание и отзывы
Характеристики
Product Description
Instruction
Gold panning machine is made of glass fiber reinforced formula manufacturing washing disc, which is better coefficient of friction in water medium. The gold panning machine is available 15 μm above the natural gold particles, Enrichment ratio and strong, long used wear-resistant; has the advantages of simple structure, can be single or multi machine assembly, and grading equipment joint operation.
Principle
Motor drive inner rubber bowl rolling at high speed by belt and axis. Separation work will be strengthened in the rubber bowl by centrifugal force. Light material will be discharged with the water, and final refined gold ore will come out from the outlet after stopping work.
1. Batch operation with simple cleaning to remove concentrate
2. Relatively low rotational speed to minimize maintenance requirements
3. No added water for bed dilation
4. Simple construction
5. Low capital cost
6. Compact and lightweight
7. Bowl geometry designed for maximum gold retention
Motor drive inner rubber bowl rolling at high speed by belt and axis. Separation work will be strengthened in the rubber bowl by centrifugal force. Light material will be discharged with the water, and final refined gold ore will come out from the outlet after stopping work.
1. Batch operation with simple cleaning to remove concentrate
2. Relatively low rotational speed to minimize maintenance requirements
3. No added water for bed dilation
4. Simple construction
5. Low capital cost
6. Compact and lightweight
7. Bowl geometry designed for maximum gold retention
Specification
Model | Φ600A | Φ600B |
capacity (m3/h) | 3~7 | 3~7 |
Fluidization Water Required (m3/h) | 0.8-2 | 0.8-2 |
Feeding Density (%) | 15~25 | 15~25 |
Feeding Size (mm) | 3~0.074 | 3~0.074 |
Equipment Plate Size(mm) | Φ600 | Φ600 |
Power Requirements (Kw) | 0.75~1.1 | 0.75~1.1 |
Power Unit | Electric power | Gasoline powered |
Center of rotation（rpm） | 100~180 | 100~180 |
Equipment Weight (Kg) | 100 | 100 |
Packing & Delivery
◆ Ways of packing
1.Small parts packed in the wooden cases
2.Big parts packed by plastic membrane
3.The whole big machine is loaded in the container
3.The whole big machine is loaded in the container
◆ Shiping by sea/air freight
1. Usually our mining machines are shipped in 40'HQ or Flat Containers by sea.
2. Our mining equipments can be also shipped by air if customers request.
2. Our mining equipments can be also shipped by air if customers request.
Company Introduction
◆ Jiangxi walker Machinery Co.,Ltd
Jiangxi walker Machinery Co.,Ltd, are a professional manufacturer of complete set mining equipments, a sub-company of JXSC mine machinery factory in Jiangxi province.professional at providing complete set processing equipments for Gold ore /Tin ore /Tungsten ore /Iron ore / Diamond/ Coltan ore / Silica sand / Zircon sand/ Black sand/Chrome ore, ect. As well as complete set small lab mining machines.
1.Inquiry and consulting support.
2.Ore sample testing support.
3.View our Factory.
4.Design Flowchart.
2.Ore sample testing support.
3.View our Factory.
4.Design Flowchart.
1.Training how to instal the machine, training how to use the machine.
2. 1 year warranty .
3.Engineers available to service machinery overseas.
2. 1 year warranty .
3.Engineers available to service machinery overseas.
FAQ
1.How is the quality of your products?(mining equipment/machine)
Answer: Our products are manufactured strictly according to national and international standard, and we will do a test on every machine before delivery.
2.Guaranteed?
Answer: All of our products are guaranteed for one year. If products quality is not consistent with the description or promise we made before you place order, we promise 100% refund.
3.How about price?
Answer: For the complete same machine, we can promise our quality is the best when the price same as other competitors, and our price can be lowest when the quality at standard level.
4.Service and Payment Terms?
Answer: We can accept T/T and L/C; 30% deposit, 70% balance before factory delivery, which is international trade practice; Finished product pictures will be provided to customers before delivery.
If you are interested in our products, please don't hesitate to contact us. Could you tell me the following questions, so that I can give you a complete solution, including best Exw-works Price Quotation!
1. Which machine do you need? like gold washing machine, spiral chute, vibrating screen, Jig separator, Shaking table, etc.
2. What is your raw ore that you plan to process? like gold ore, diamond ore, tantalite or silica sand, etc.
3. What is the capacity you need? Like 10 tones per hour.
4. What is the feeding size to the machine? and what is the discharging-material size that you require?
Sincerely welcome to send your inquiry,you can get best quotation and professional service.
Answer: Our products are manufactured strictly according to national and international standard, and we will do a test on every machine before delivery.
2.Guaranteed?
Answer: All of our products are guaranteed for one year. If products quality is not consistent with the description or promise we made before you place order, we promise 100% refund.
3.How about price?
Answer: For the complete same machine, we can promise our quality is the best when the price same as other competitors, and our price can be lowest when the quality at standard level.
4.Service and Payment Terms?
Answer: We can accept T/T and L/C; 30% deposit, 70% balance before factory delivery, which is international trade practice; Finished product pictures will be provided to customers before delivery.
If you are interested in our products, please don't hesitate to contact us. Could you tell me the following questions, so that I can give you a complete solution, including best Exw-works Price Quotation!
1. Which machine do you need? like gold washing machine, spiral chute, vibrating screen, Jig separator, Shaking table, etc.
2. What is your raw ore that you plan to process? like gold ore, diamond ore, tantalite or silica sand, etc.
3. What is the capacity you need? Like 10 tones per hour.
4. What is the feeding size to the machine? and what is the discharging-material size that you require?
Sincerely welcome to send your inquiry,you can get best quotation and professional service.
