Product Description
Specification
Model NO. | MistPro-080 |
Control | P:Proportional control；K：Switch control；4：4 shunt control |
Water | Tap water, deionized water, demineralized water, purified water |
Water Pressure | 0.1～0.5MPa |
Water Temperature | 1～40℃ |
Ambient Temperature | 1～40℃ |
Environment Humidity | Maximum 75%RH, no condensation |
Protection level | IP21 |
Inlet Diameter | G1/2" male thread |
Drain Diameter | G1/4" internal thread |
Brand Name | Giantsteam |
Voltage | 380V AC 3 phase |
Weight | 100kg |
Dimension(L*W*H) | 950*450*880mm |
Origin | China |
Product name | MistPro |
color | black |
Material | Stainless Steel |
Humidifying type | High pressure mist |
Weight | 100KG |
Power | 0.9kw |
Control method | Automaticly |
Function | Adjust Humidity |
Humidifying Capacity | 80kg/H |
Voltage | 380V AC |
Title goes here.
GiantSteam MistPRO series adopts Italian AR plunger pump + SIEMENS motor, with high reliability, high stability and high cost performance, and is equipped with a special control system of 32-bit CPU main control chip independently developed by GiantSteam, with powerful functions and high control precision. The flow of a single machine can be 1200kg/h, and one machine can drag multiple ends.
Cool Down：The high-pressure micro-mist nozzle can generate more than 5 billion fine particles per second, and the particle diameter of the mist droplets is only between 1 and 15 μm.It is easy to carry out heat and moisture exchange in the air, resulting in the effect of humidification and cooling.
Energy Saving：It only consumes 4~6W per kilogram of humidification, which is the most energy-efficient of all our humidification products.
Safety：Safety protection devices are well equipped. There are pressure protection and pressure relief valves and other devices on the high and low pressure pipeline system. When abnormal phenomena such as pipeline damage or blockage occur, the protection device will be activated immediately, the host will be shut down, and an alarm will be given.
Health：The water system is completely closed, non-circulating, and will not breed bacteria.
"One-to-many" control：A single machine can not only control and adjust a single environment, but also independently control and adjust up to 16 environmental sites (terminals). And it can realize that each environmental site (terminal) can choose to access different types of signals (terminal or switch-type signal, or access to 0~10V/4~20mA proportional signal).
Technicals
Model | FineMist | MistPro | |||||||||||||
20 | 40 | 80 | 180 | 300 | 600 | 900 | 1200 | ||||||||
Flow（kg/h） | 20 | 40 | 80 | 180 | 300 | 600 | 900 | 1200 | |||||||
Voltage | 220VAC single phase | 380V AC 3 phase | |||||||||||||
Power（KW） | 0.15 | 0.15 | 0.9 | 1.1 | 1.5 | 2.2 | 3.0 | 5.0 | |||||||
Maximum number of No. 1 nozzles | 8 | 16 | 32 | 72 | 120 | 240 | 360 | 480 | |||||||
Maximum number of No. 2 nozzles | 4 | 8 | 16 | 36 | 60 | 120 | 180 | 240 | |||||||
Maximum number of No. 3 nozzles | / | / | / | 23 | 38 | 76 | 114 | 152 | |||||||
Work Pressure（bar） | 70 | 70 | |||||||||||||
Width（mm） | 480 | 950 | 950 | ||||||||||||
Thickness（mm） | 300 | 450 | 450 | ||||||||||||
Height（mm） | 450 | 380 | 1300 | ||||||||||||
Water Pressure | 0.1～0.5MPa | ||||||||||||||
Water Quality | Tap water, deionized water, demineralized water, purified water | ||||||||||||||
Water Temperature | 1～40℃ | ||||||||||||||
Ambient Temperature | 1～40℃ | ||||||||||||||
Environment Humidity | Maximum 75%RH, no condensation | ||||||||||||||
Protection level | IP21 | ||||||||||||||
Inlet Diameter | G1/2" male thread | ||||||||||||||
Drain Diameter | G1/4" internal thread | ||||||||||||||
