150 Вт CCD камера визуальный проектор положения Автоматическая Рулонная рамка для кормления ткани кожаная ткань одежды co2 лазерная резка машина

Сохранить в закладки 1600930462843:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики







Products Description




Products Description


Our camera sheet
1.One click copy, Fast speed, high precision, 1:1 digital input;
2.Black and white background, identify paper patterns, fabrics, models and other samples:
3.Compatible with all CAD software, international common DXF, PLT industry standard format
4. Applicable to clothing, Shoe bags, upholstered furniture, automotive interior and other industries.
Factory
Projection positioning cutting system
Projection plate positioning, Fast cutting, For clothing, leather, Trademarks, applique Embroidery and other cutting, through the projection system to cut the graphics one-to-one projection into the cutting On the table, Achieve automatic projection alignment cutting, intuitive and convenient, time-saving Material saving and other characteristics.


Board forming machine
The advantages of digital plate making compared with photo plate making: the level of computer use for personnel is not high, easy
to master. Plate making one-time molding without retouching. Low requirements for the use environment.
Automatic typesetting: Optimize the typesetting path, greatly improve the utilization of materials
Variant revision: -- key automatically changes the size, quickly completed




Details Images





Automatic rectify
deviation system





Crawler-type worktable
with auto feed






Smart RD control panel






Upper exhaust device





The power of CO2 laser
tube can be selected
according to the specific
material, thickness,
process and SO on.


Product Paramenters


Model
JX1630 (MC 1830)
Working Area
1600*3000mm (1800*3000mm)
Laser Power
80W/100W/150W/180W(RECI or EFR brand)
Laser Type
CO2 Sealed Glass Laser Tube
Drive System
Mix servo motor and driver
Laser Output Control
0-100% set by software
Min. Engraving Size
Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm
Control System
DSP offline line / USB
Auxiliary Equipment
Exhaust Fan with air pipe, Air Pump, CW5200 / CW 6000 Chiller
Power Supply
AC110V/220V+10%, 50HZ/60HZ
Working Environment
Temperature:0-45C, Humidity 5-95%(No Condensate Water)


Sample




Application


Applicable Industries
JX1625 is suitable to professional user for cutting performance in garment,car,leather,cloth toy, computerized embroidery and clipping, cutting of template,art gift, advertisement decoration,building upholster, package, printing, paper product and other industries.

Applicable Materials
Cloth, fabric, leather, paper, plastic, compound material, etc.
