Хорошая цена на сетчатую солнечную систему для коммерческого использования 50 кВт 100 200 300 400 500 полный комплект

Сохранить в закладки 1600935153289:


Цена:30,86 ₽ - 41,88 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Products Description




How it works




What's Included:


Model
LF-50KW-ON
LF-100KW-ON
LF-200KW-ON
Half Cut Mono 560W Solar Panel
96 Pieces
180 Pieces
360 Pieces
DC Isolation Switch
8Piece
15Piece
30Piece
On Grid Inverter
Solis-50K
Solis-100K-5G
Solis-100K-5G/2PCS
AC Isolation Switch
1Piece
1Piece
2Piece
DC Cable 4mm2
800 meter
1500 meter
3000 meter
MC4 Connector
20 Pairs
90 Pairs
180 Pairs
Mounting System
Customized Product Based On Installation Roof/Ground
PV Installation Tools
Wire Cable Cutter & Stripper, Disassembly Tool
Model
LF-300KW-ON
LF-400KW-ON
LF-500KW-ON
Half Cut Mono 560W Solar Panel
540 Pieces
720 Pieces
900 Pieces
DC Isolation Switch
45Piece
60Piece
75Piece
On Grid Inverter
Solis-100K-5G/3PCS
Solis-100K-5G/4PCS
Solis-100K-5G/5PCS
AC Isolation Switch
3Piece
4Piece
5Piece
DC Cable 4mm2
4500 meter
6000 meter
7500 meter
MC4 Connector
270 Pairs
360 Pairs
450 Pairs
Mounting System
Customized Product Based On Installation Roof/Ground
PV Installation Tools
Wire Cable Cutter & Stripper, Disassembly Tool



Half Cut Mono 560W Solar Panel
Peak Power Watts: 560W
Maximum Power Voltage: 42.06V Maximum Power Current: 12.84A
Open Circuit Voltage: 49.75V
Short Circuit Current: 13.63A
Dimensions:2279x1134x35mm
Weight:26.9 kg





On Grid Solar Inverter
10 MPPTs, max. efficiency 99%.High power tracking density 90MPPT/MW.
Compatible with bifacial modules.
Remote firmware upgrade with simple operation.
Overvoltage load reduction and leakage current suppression technology,
low failure rate.
Power line communication (PLC) (optional).



Monitoring System
Smart I-V curve scan, system health report, string-level fault finding.Manage multiple types of systems across residential,
commercial and utility scale plants.Enables multiple team management
across different sectors.
Connecting with multiple types of devices seamlessly, Inverters, export power managers, weather stations etc.





PV Mounting System
Mounting Rail & Rail Splice Kit: AI6005 & SUS304 Bolt.
Mid & End Clamps: 35,40,45,50mm
L Foot Asphalt Shingle Moount & Hanger Bolt Optional
Cable Clip & Tie Optional
Ground Clip & Lugs Optional





DC Cable & MC4 Connector
Cross Section: 4mm2, 6mm2 Optional
Rated Voltage:600VDC(/1000VDC(TUV)
Rated Current: 55A,70A
Colors: Black For STD, Red Optional.
Lifetime:≤25 Years






DC & AC Disconnect Switch
IP Rating: IP66
Rated Voltage: 600VDC/1000VDC
Connection Type: M20,M25,MC4
Rated Current: 16A,32A






PV Combiner Box
IP Rating: IP65
Rated Voltage: 1000VDC
Input cable terminal: 4-6mm2






PV Tools
Wire Cable Cutter & Stripper,
MC3 MC4 Crimper
MC4 Connectors Assembly
Disassembly Tool


Product Packaging






Project Case




Recommend Products




Company Profile


Henan Livefun Solar Tech Co., Ltd. was established in 1998, Located in zhenghzou City, Henan Province. Factory with 10,000 square meters,Specializes in manufacturing all types of solar module, storage batteries,solar inverter ,Providing a complete solar system solution to meet different customers' requirements,We have exported to Asia, Europe, America, Africa over 120 countries, our solar product acclaimed worldwide. We have professional R&D team, with professional production and strict quality inspection process. We have ISO, CE and TUV certificates. Also customized requirements are available.
