Product Description
Applicable to 99% of car models, can be used for car sunroof, side window glass, car rear windshield.
Self Adhesive Tint Smart Film For Car Window Smart Car Window Film
Product introduction
Electric smart film is a kind of film that add liquid crystal polymer composite material in the middle of two transparent conductive film , in the absence of an electric field, the electric smart film isin an opaque state; when the alternating current passes through, the liquid crystal molecules can achieve an orderly arrangement, and the film changes from opaque state (OFF state) to transparent state (ON state). Through the electric field, the electric smart film can quickly switch from the open state to OFF state, and from the OFF state → open state.
Working Principle
Electric smart film consists of two layers of PET-ITO conductive film and the intermediate liquid crystal film. Wherein the liquid crystal film mainly consists of liquid crystal droplets and outer layer of high polymer. When the power is off, the liquid crystal droplets are in disordered arrangement state, when parallel light passes through the polymer and irradiate to the liquid crystal material, because of refractive index of the liquid crystal droplets is lower than the other outer polymers, light in the surface of liquid crystal droplets is diffused and scattered .the whole film becomes opaque, appears frosted. When energized, two PET-ITO conductive film functions as planar electrodes, which makes the liquid crystal droplets orderly arranged perpendicular to the film surface, whereby the parallel light passes through the liquid crystal layer without being reflected and refracted , and light transmits to whole film, and smart film appears transparent.
ADVANTAGES OF PDLC FILM FOR CAR
Thermal comfort
acoustic comfort
Thermal protection against UV rays
Greater durability for furniture
Privacy
Safety
Protects the glass against scratches and graffiti
Film with durability of up to 15 years
Easy installation and zero maintenance
Aesthetic versatility
acoustic comfort
Thermal protection against UV rays
Greater durability for furniture
Privacy
Safety
Protects the glass against scratches and graffiti
Film with durability of up to 15 years
Easy installation and zero maintenance
Aesthetic versatility
Specification
item | value |
Warranty | More than 5 years |
After-sale Service | Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other, NONE |
Project Solution Capability | graphic design, total solution for projects, Cross Categories Consolidation, Others |
Application | Hotel,Villa,Apartment,Office Building,Hospital,School,Mall,Bathroom |
Design Style | Contemporary,Modern,Minimalist,French |
Place of Origin | China |
Guangdong | |
Brand Name | Simple&Reliable |
Model Number | PDF02 |
Function | Decorative |
Feature | Self-Adhesive |
Type | Furniture Films |
Surface Treatment | Embossed, Frosted / Etched |
Product Name | PDLC Smart Glass |
Min Size | 100*300 mm |
Max Size | 3000*12500mm |
Single layer film thickness | 0.12mm |
Power consumption | 10 w/square meters |
Function | Decorative, Heat Insulation, privacy protection |
Transmittance | 80%,88%,92%,94% |
Light transmission technology | PDLC,SPD |
Power | 12-24V |
Frequency | 50/60Hz |
Optical Properties | Visible Light Transmission | ON | >83% | ||
OFF | <5% | ||||
Haze | ON | <6% | |||
OFF | >90% | ||||
Parallel Light Transmittance | ON | >75% | |||
OFF | <2% | ||||
UV Blocking | ON/OFF | >99% | |||
Infrared Blocking | ON/OFF | >60% | |||
Haze | ON | 5% | |||
Electrical Properties | Operating Voltage | ON | 45V/60V | ||
Frequencies | ON | 50 to 60 Hz | |||
Current | 2mA/m2 | 2mA/m2 | |||
Response Time | ON-OFF | 20 ms | |||
ON-OFF | 200 ms | ||||
Power Consumption | ON | 5W/m2/hr | |||
Specification | Durable Temperature | -20℃ to 60℃ | |||
Life Time | >80000 hours | ||||
Visual Angle | 140° | ||||
Color | White,Grey,Yellow,Blue,Red,Green,Black,Dark Grey | ||||
Size | Thickness | 0.5 mm | |||
Length and Width | Customization to customer Requirments | ||||
Sample size | 200 mm*300 mm or others | ||||
Control Mode | Manual Switch,Voice control,remote control,remote control can be combined according to customer needs | ||||
Certifications
Recommend Products
Packing & Delivery
PACKING & DELIVERY
· Front And Bcak，Up And Down Will Not Install Reversely
· Provide Installation Guidance
· Successfully Passed The Verification Of The Inspector
· Rapid Product Positioning
· Front And Bcak，Up And Down Will Not Install Reversely
· Provide Installation Guidance
· Successfully Passed The Verification Of The Inspector
· Rapid Product Positioning
FAQ
♦1.Are you a factory?
We are a factory, we completely can provide you high quality and best price for our clients.
♦2.Will you provide sample?
We can offer samples for free.
♦3. Can you do the production as customized?
Yes, we have a professional technique team, we could produce the glass depends on your requirements.
♦4. What is your minimum order quantity?
Our MOQ is one 20 feet container (25Tons). Products of different sizes and specifications could be mixed in one container.
♦5. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
♦6. What material is the packing ?
Unique designed strong Wooden crate, carton box, plastic film, customized,solving the problems of breakage.
♦7. Payment term?
A: Payment<=1000USD, 100% in advance.
B: Payment>=1000USD, 30% T/T in advance ,balance before shippment.
We are a factory, we completely can provide you high quality and best price for our clients.
♦2.Will you provide sample?
We can offer samples for free.
♦3. Can you do the production as customized?
Yes, we have a professional technique team, we could produce the glass depends on your requirements.
♦4. What is your minimum order quantity?
Our MOQ is one 20 feet container (25Tons). Products of different sizes and specifications could be mixed in one container.
♦5. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
♦6. What material is the packing ?
Unique designed strong Wooden crate, carton box, plastic film, customized,solving the problems of breakage.
♦7. Payment term?
A: Payment<=1000USD, 100% in advance.
B: Payment>=1000USD, 30% T/T in advance ,balance before shippment.
