3U 16HDDs WizMind Intelligent Video Surveillance Server
> Industry embedded micro-controller
> Max 512 Mbps incoming bandwidth
> 256-channel IP video access
> Up to 48-channel AI IVS
> Up to 48-channel face recognition with normal IPC
> Up to 160-channel face recognition with face detection IPC
> Up to 48-channel video metadata
> Up to 50 face databases with 500,000 face pictures in total
> Supports RAID 0/1/5/6/10/50/60
> SAS3.0 for storage extension
> Redundant power
System | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor | Industry embedded micro-controller | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System | Embedded Linux OS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operation Interface | WEB (PCAPP), local GUI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI Applications | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI by Camera | Face detection, face recognition, video metadata, IVS (tripwire, intrusion, abandoned object, missing object, fast moving, parking detection, crowd gathering, loitering, and fence-crossing), people counting, smoking detection, call detection | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI by Device | Face detection, face recognition, video metadata, IVS (tripwire, intrusion, crowd gathering, loitering detection, parking detection), plate comparison | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS Performance (AI by Device) (Channel Number) | 48-channel 2 MP or 32-channel 4 MP with normal IP camera | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS Performance (AI by Camera) (Channel Number) | 256-channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Human Face Detection | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Human Face Properties | Supports 6 properties: Gender, age range (6 levels), glasses, expression (8 types), mouth mask, and beard | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection Performance (AI by Device)(Channel Number) | 48-channel 2 MP or 32-channel 4 MP with normal IP camera | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection Performance (AI by camera) (Channel Number) | 160-channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Human Face Recognition | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Database Capacity | 50 face databases with 500,000 face pictures in total | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Human Face Recognition Performance (AI by Device)(Channel Number) | 48-channel 2 MP or 32-channel 4 MP with normal IP camera 160-channel with face detection IP camera (Totally 160 face pictures analyzed per second) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Human Face Recognition Performance (AI by camera) (Channel Number) | 160-channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ANPR | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Plate Database Capacity | 50 plate databases with 500,000 plate numbers in total Supports allowlist and blocklist | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Plate Detection Performance by ITC Camera (Channel Number) | 64-channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Metadata | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Human Body Properties | Gender, age, sleeves length, top color, bottom type, bottom color, bag, rain coat, umbrella, hat, hairstyle, direction, hold a baby, mouth mask | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Vehicle Properties | Vehicle type, vehicle color, plate color, logo, calling, seatbelt, ornament, region | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Non-motorized Vehicle Properties | Non-motor Vehicle type, non-motor vehicle color, number of passengers, umbrella, rain coat,bag , sleeve length, top color, hat, hair style, mouth mask | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Metadata Performance (AI by Device) (Channel Number) | 48-channel 2 MP or 32-channel 4 MP with normal IP camera | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Metadata Performance (AI by camera) (Channel Number) | 64-channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Parameters | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Remote Connection | 256-channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Bandwidth | Incoming bandwidth: 512 Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 24MP/16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/CIF/QCIF | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Capability | 2-channel 24MP/3-channel 16MP/6-channel12MP (20 fps)/7-channel12MP (15 fps)/6-channel8MP (30 fps)/12-channel8MP (15 fps)/7-channel6MP (30 fps)/9-channel5MP (30 fps)/11-channel5MP (25 fps)/12-channel4MP (30 fps)/18-channel4MP (20 fps)/19-channel3MP (25 fps)/12-channel1080p (60 fps)/24-channel1080p (30 fps)/36-channel720p (30 fps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Output | 1-channel VGA output, 3-channel hdm-i output, VGA 1/hdm-i 1 outputs the same video source Supports 4K output | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-screen Display | 1st Screen: Max.64-channel 2nd Screen: Max.16-channel 3rd Screen: Max.1-channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Third-party Support | Onvif; RTSP; Sony; Panasonic; Axis; Arecont; Pelco; Canon; Samsung | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System | Embedded Linux OS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operation Interface | WEB (PCAPP), local GUI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | Smart H.265+; Smart H.264+; H.265; H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711a; G.711u; PCM; G.726 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P; iSCSI; UPnP; SNMP; IPv6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Phone | iOS, Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF (Profile S, T and G); CGI; SDK | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser | Chrome; PCAPP; IE9 or higher; Firefox | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Mode | NIC binding mode such as multiple-address mode, load balance, fault-tolerance, etc | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Playback | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multiple-channel Playback | Max. 16-channel playback | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Search | Search video detection/manual record/IO alarm/intelligent event/all record file | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Medium | Internal HDD, SAS disk array enclosure | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backup Method | HDD, peripheral USB storage device | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Playback Function | Play, pause, stop, fast forward, fast backward, reverse play, frame by frame play Full-screen, backup (clip/file), snapshot, digital zoom, audio on/off | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDD Group | 16 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAID | RAID 0/1/5/6/10/50/60 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Pool | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Alarm | Motion detect, tampering, local alarm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Anomaly Alarm | IPC offline alarm, storage error, HDD full, IP conflict, MAC conflict, login lock, AI module temperature alarm, AI module offline, fan malfunction | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligent Alarm | Human face detection, human face recognition, entries frequency, video metadata (person/vehicle/non-motor vehicle), IVS, plate recognition, people counting, smoking, call | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Linkage | Record, snapshot (full image), local external alarm output, IPC external alarm output, access & control, audio prompt, buzzer, log, preset, email
|
