Профессиональный аудио LA3212 V2 3 сторонний линейный динамик двойной 12 дюймовый громкоговоритель для внутреннего и наружного использования Профессиональная звуковая система

Сохранить в закладки 1600966723329:


Цена:75 985,34 ₽ - 79 867,80 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product Description
















Application:



  • Main amplification of medium sound reinforcement system

  • Touring concert, live show

  • Theater/Church/ Auditorium/ Gymnasium





Features :









  • 3-way passive full range line array loudspeakers

  • 2x12”midbass + 2x3” neodymium HF driver+4x6.5 inch mid

  • The problem of energy balance ratio between LF driver and HF driver is solved by using Dumbbell Type direct alignment

  • Easy installing





Specification :





































































Specification



Model No.



LA3212-V2



Frequency response:



60-18KHz  (±3)



Sensitivity ( 1W/1m ) :



HF:108dB


LF:98dB


MID: 100dB



Nominal Impedance:



HF:16Ω


LF:16Ω



Power Rating:



HF:160W


LF:800W


MID: 480W



LF speaker driver :



2×12" Mid bass with 3 inch voice coil



HF speaker driver :



2×3" HF driver with 3 inch Voice coil



MD speaker driver



4x6.5" MID driver with 2 inch vc



Nominal coverage(HxV):



100°×10°



Max SPL:



HF:129/135 dB  LF:129/135 dB



Suspension Hardware:



Three points hanging 0° to 10° adjustable



Connectors:



2 NL4MP connector  2+2-HF,1+1-LF



Dimensions (W×D×H) :



1105×521×378(mm)



Net weight:



51 kg














Dimension :





3-way line array LA3212-V2
