200KWH 300KWH 500KWH IP54 BMS контейнер для наружного жидкостного охлаждения аккумуляторной батареи BESS солнечная батарея система хранения энергии
360 280,65-420 528,25 ₽
Сохранить в закладки 1600967631954:
Category | Projects | 100kW / 215kWh Systems | 250kW/645kWh Systems | 500kW / 1075kWh Systems | ||
Configuration | Rated power | 100kw | 250kw | 500kw | ||
Battery type | LFP | |||||
RACK configuration (xPxS) | 1P1S | 3P1S | 5P1S | |||
Rated battery energy (kWh) | 215 | 645 | 1075 | |||
Rated capacity (Ah) | 280 | 840 | 1400 | |||
Charge and discharge parameters | d battery voltage (V) | 768 | ||||
Maximum charge voltage (V) | 856 | |||||
Discharge cut-off voltage (V) | 672 | |||||
Rated discharge power (kW) | 100 | 250 | 500 | |||
Standard charging current (A) | 140 | 300 | 600 | |||
Standard discharge current (A) | 140 | 300 | 600 | |||
Max. discharge current (A) | 280 | 362 | 724 | |||
Discharge depth | 90% | 80% | 80% | |||
Efficiency | System efficiency | >85% | ||||
Basic parameters | Ambient temperature (°C) | -10~45℃ | ||||
Relative Humidity | 5%~95% None Condensation | |||||
Protection class | IP54 | |||||
Cooling method | Individually temperature-controlled interior air conditioning | |||||
Fire protection system | Fire suppression tubes | |||||
Communication method | Net |
