Профессиональный пылесос автоматический SMT всасывающий аппарат для очистки сопла

Сохранить в закладки 1600975251202:


Цена:2 476,00 $*

Количество:

  • В избранное

Описание и отзывы

Характеристики









Products Description




Machine Feature:
◆Cleaning 30 nozles at a time, with short dleaning time and high efficiency.
◆substitute for traditional manual cleaning.solve the problem of ultrasonic cleaning, Reduce the phenomenon of patchthrowing.
◆Atomized water flowsupersonic jet cdeaning, completely solve the dirt and impurities that cannot be cleaned by ultrasonic.
◆ Will not beunclean due to smallerand smaller noazle apertures.
◆The clean is more thorough,directly prolongs the life of the nozzle, and the clean rate is over 99%.
◆The operation is convenient,and the interface can be switched between Chinese and English.
◆Never use cleaning agents,only clean with environmentally triendly puriied water or delonized water.
◆ The touchscreen ontrol .interfaceisadopted,and the operaton is simple and easy toundertand.
◆ It issuitable forall kinds of mounter nozzles, and the cleaning effect ismore obvious for the cross shaped, I-shaped and speclal-shaped nozzles.


Working principle:
◆High pressure jet technology: A. Fine water mist particles, continuously pressurized to break the water, the water mist of3-10μm particles is generated so that it can clean the dirt on the inner wall of the small nozzle aperture.
◆ Impulse power: B.It forms a powerful pulse power jet to the suction nozzle at the speed of sound (v=360m/s),the pulse frequency can reach 30 times per second, forming a continuous impact force above the nozzle to be cleaned, crushing the dirt on the surface and inside, and achieving the purpose of cleaning.


Product Name
Automatic Nozzle Cleaning Machine
Equipment size
L440×W500×H530(mm)
Equipment weight
35KG
Cleaning fluid
Industrial pure water
Consumption≤400CC/H


Using fluids
Air source: compressed air
Operating pressure range 0.5-0.65Mpa (when cleaning)
Injection pressure< 0.4Mpa
Air consumption below 500NL/min
Power supply
Voltage AC220V 50HZ
Maximum rated power consumption 100W
Nozzle tray
30 bits




Product Details




Application




Main Products




Company Profile






Packaging & Shipping




FAQ




Q: Do you accept customization?
A: Yes! We can provide customized packaging, logo and size.

Q: What's the MOQ?
A: 1 set, One-on-one service, meeting different product requirements.

Q: What' s the delivery time of your products?
A: Delivery time depending on your purchasing quantity and production season.
Available in stock for 1-5 days, customized for 15-20 days.

Q: How does your factory do regarding quality control?
A: Quality is priority. we will do 100% quality inspection before shipment.

Q: What is your terms of payment?
A: We Accept T/T.
For mass production: 30% deposit before mass production,70% before shipment.

Q: Can we use our own logo and design?
A: Yes, you can. We'll according to your request to put you logo or design.
For logo file must AI file.

Q: When can l get the price?
A: We usually quote within 24 hours after we get your inquiry.
If you are very urgent to get the price, please call us or contact through Trade Manager to get prompt response. please call us or
tell us in your email so that we will regard your inquiry priority.
