Современные алюминиевые двери и окна черные двухстворчатые раздвижные дизайн

Сохранить в закладки 1600978743463:


Цена:8 873,10 ₽ - 9 982,37 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики




We have 21 years of manufacturing experience.


We are a professional aluminum alloy doors & windows custom factory.



Product Description












Thermal Insulation Aluminum Energy Saving System Doors and Windows





















































TypeModel 113 thermal break Sliding Window
Opening StyleSliding
Opening PatternHorizontal
Frame MaterialAluminum
Glass ThicknessDouble insulating glass 5mm+20Argon+5mm
Glass PerformanceTempered glass/Low-E glass/frosted glass, etc., can be customized
SizeCustomized
FunctionBroken bridge (thermal brake)/non-broken bridge (non-thermal brake); heat insulation, acoustic noise reduction, waterproof, anti-insect, corrosion-resistant
Profile

1. Aluminum alloy, T5-6063 virgin aluminum;


2. Wall thickness sliding down 2.0, the rest 1.8 / sliding down 3.0 / the rest 2.0 / sliding down 1.8, the rest 1.3 / sliding down 1.8, the rest 1.4 (according to the width of the profile, can be customized);
3. Surface treatment: powder coating, electrophoresis, anodic oxidation, and color can be customized.


Packing

1. Protective film for border and glass/EPE foam/thermoplastic packing/kraft paper/wooden case;


2. Delivery time: 15-45 days depending on quantity and model;


 Product Briefing

1. Installing the bouncing wheel and windmill wheel on the guide groove, solving the safety hidden dangers such as window jumping and falling off.


2. Embedded design is adopted as the combination of frame and sash, which hides the sash in the frame, provides more sealing, and greatly improves the impact resistance and aesthetics of the sliding window.


3. Drainage system adopts a hidden drainage design, using the equal pressure chamber of the window and the outdoor pressure, effectively preventing rainwater backflow. Drainage holes are hidden inside the window, which is both aesthetically pleasing and effective in avoiding the accumulation of dust blocking the drainage holes.


4. All four corners are made of aviation-grade virgin aluminum corner rods, and the 45-degree corner design will make the joints more tightly fixed, which greatly increases the service life and aesthetics.


Contact us

Style, specification, color, glass, etc. can be changed and customized, please contact us for professional customized service.








Support casement form+fixed form combination customization


Sliding window style personalized selection assembly is your choice


We support the selection of single or multiple-door leaves combined with fixed combinations




Personalized Style Glass Options


Based on the different needs of users for glass, we have introduced a variety of personalized glasses for you to choose from. In addition, there are Low-E glass and argon multi-layer glass for you to choose from.




Surface treatment: Powder-coated, Electrophoresis, PVDF, Anodizing, or wood color. Use this guide to assist your color selection and specification process.


Tips: If you need other colors, please contact us to customize them for you!


.jpg


For window and door design services, PLEASE CONTACT OUR SALES!!! THANK YOU VERY MUCH! LOVELY!!





Product Materials




Build High-Quality Doors And Windows For Your Home


Acoustic System - Waterproof System -  Heat Protection System


Wind Protection - Sealing System - Security System




The aluminum alloy corners and connectors of the door and window are integrally welded at 45,


which is durable and firm, and completely eliminates the hidden danger of water seepage in the gaps.




Hardware: BORN cooperates with many powerful hardware brands to provide excellent strength and durability without losing the beauty of personalized matching.




Effectively reduce the loss of air conditioning And Effectively reduce noise decibels




Hollow tempered glass, automotive grade glass, through 3C certification.




18 years of experience in the integration of production and sales of door and window products has made our products and services mature and perfect.


There is no doubt that traditional glass is cheaper than tempered glass, but tempered glass is far ahead of traditional glass in terms of thickness, toughness, and safety.


The quality of traditional glass is poor. After being broken, not only the environment is very embarrassing. but also may endanger personal safety.








Process Flow




Drawing Design → Arranging Production → Material composite →Profile Cutting →Splicing Assembly → Waterproof Seal→ Inspection Test→ Packing Frame → Packing Glass → Packaging Products → Overall Packaging → Wooden Packaging





Company Information




As a manufacturer, Sichuan Bowen Doors and Windows Co., Ltd. has its own exclusive factory (covering an area of 30,000 square meters). We are committed to the production, installation, and sales of plastic steel doors and windows, broken bridge aluminum doors and windows, high-grade wood aluminum doors and windows, building curtain wall engineering, steel structure engineering, etc. We have accumulated nearly 21 years of rich experience in door and window manufacturing-related fields.


We can produce 400000 square meters per year. We have various honorary certificates such as China's green building materials identification certificate and AAA enterprise certificate of quality service. We also hold three certificates, respectively ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018.


Sichuan Bowen Doors and Windows Co., Ltd. has been adhering to the development strategy of honest management, quality first, and service priority for many years. It has senior design engineers, continuous innovation, and the courage to develop. The high-end door and window products produced by the company have reached the international advanced level, and personalized production services can be carried out according to the different needs of customers. And successfully carried out major projects throughout China. The policy of "survival by quality and development by reputation" has established a brand of quality reputation in the door and window industry. Bowen is your trustworthy and loyal partner !!!





Packaging & Shipping








.jpg







The main mode of transport
Products are verified by inspectors


Clear instructions are built in to save installation time


Front and back, up and down will not install reversely


Large size, low cost, convenient waterwayRailway Transportation





Client Feedback









FAQ


Q1: How do you choose a model?


According to your needs, we recommend the most suitable products. For example, for sliding windows, we will consult your window size, color, usage scenarios, glass requirements, and so on.





Q2: Does the color support customization?


The standard colors of our windows and doors are usually black, white, and grey. If you have other color requirements, we will customize them for you.





Q3: Can you tell me about the glass material? Does the glass fog up if it rains? Is the glass easy to break?


A6:We offer toughened glass, lowe glass, coated glass, laminated glass, frosted glass, and long rainbow glass. We will recommend it according to your preference. For example, do you want soundproofing or thermal insulation? Whether you need to protect privacy or climate, etc. to recommend.





Q4:What is the ordering process?


The process of placing an order in our factory: firstly, you need to tell us the requirements such as the style, size, and quantity of the products you want, as well as the mode of transport and the port of destination you need, and then we will send you a quotation, and after you accept our quotation, we will send you a PI or a contract, and then you will sign it back to us, and then remit the down payment to us, and when we receive the down payment, the order will take effect, and we will then Arrange for you to start producing the order accordingly.





Q5: How can I get a sample?


Before we receive your first order, please provide us with a PDF or AI for production and pay for the sample fee and courier fee. If you are satisfied with the sample and place your first order, we will refund your sample fee.





Q6: How long does the whole production cycle take?


For standard configurations, from the drawing approval stage, our usual lead time is approximately 3 weeks, for non-standard colors, stained glass, and other special upgrades, our lead time is approximately one month. Dates are extended for holidays.
