ASTM ПВХ дренажная труба большого диаметра для водоснабжения промышленная система трубопроводов

(1)PVC-O Pipe has unique net structure with rearranged material molecules through the biaxial

orientedstretching under certain temperature(highresilience state), which remarkably improves

its performance.

(2)The net-structured molecule arrangement brings significant improvement of the quality of the pipe .Its outstanding performance

on anti-stretching, anti-pressure and resistance to low temperature and impact fully guarantee the safety of water delivery.


(1)Physical Property

 Note

1. In accordance with technical requirements of ISO16422:2006, in the actual testing process, China National Test Center of Chemical Construction Material conducted the experiment in the condition of -10℃, and the result could still meet the requirements.
2.  According to the ISO16422:2006 Standard Vicat softening experiment, the test was conducted in the actual examining process, and the result turned out to be quite satisfactory.
The following chart shows the comparison of traditional PVC-U pipe and PVC-O pipe in the impact experiment:

 (2)Hygiene Property

Our PVC-O pipe adopts a hygiene formulation and no lead was involved in its production. It has already successfully passed the authoritative test of Center for Disease Prevention and control of China, Security Agency for Environment and Health Relevant Products, and Hebei Agency for Hygiene Examination. All the indicators met the demand from Security Evolution Standard for Delivery Devices and Protection Materials of Drinkable Water (GB/T17219-1998).

(3)Hydraulic pressure experiment
For pipes, hydraulic pressure experiment is one of the most important performance index. The test data shows the ductile rupture of the pipe, and the extrapolated cyclic stress should be higher than 40MPa(400bar).
