Взрывозащищенная люминесцентная лампа с длительным сроком службы 50000 часов

Описание и отзывы

Характеристики

Explosion-proof fluorescent lamps are divided into traditional fluorescent lamps and electrodeless fluorescent lamps. Traditional fluorescent lamps are low-pressure mercury lamps, which use low-pressure mercury vapor to radiate ultraviolet rays during the discharge process, so that the fluorescent powder emits visible light. Therefore, it is a low-pressure arc discharge light source. . Explosion-proof discharge lamps that mainly use ultraviolet radiation generated by discharge to excite phosphors to emit light are called explosion-proof fluorescent lamps.

The fluorescent explosion-proof lighting is suitable for use in the ship, oil production platforms, chemical industry and zone 1 or zone 2 areas of the explosive gas environment. The shell is made of good quality steel, and the lampshade is made of good quality transparent PC. The light adopts a fluorescent lamp.  It can be applicable to hang-type installation, and it is convenient to replace the light tube. The light body adopts a seal structure, it has high waterproof performance and anti-corrosion performance. It is an integral type clip with high protection grade.

   1 Key features

1. Product configuration: The light source adopts (CREE) brand LED light-emitting chip, which has ultra-high light efficiency and an average service life of up to 100,000 hours. It is driven by a first-line brand power supply and processed with wide voltage technology. The quality is guaranteed. It has constant current output and is short-circuit resistant. , overvoltage protection and other features.

2. Heat dissipation design: The light source radiator adopts one-piece die-casting molding, with a tight structure and excellent thermal conductivity and heat dissipation performance. It can effectively control the temperature rise of the lamp within a reasonable range, thus ensuring the service life of the lamp.

3. Explosion-proof performance: The products are developed and designed in strict accordance with the national explosion-proof standard GB3836 series documents and have obtained nationally certified explosion-proof certificates and test reports. The certificates are complete, precision manufacturing, and the explosion-proof performance is safe and reliable.

4. Protective lampshade: Made of high borosilicate tempered glass, which is corrosion-resistant, impact-resistant, has high light transmittance, even and soft light irradiation, and is anti-glare.



   1  Installation Instructions

Installation&Dimension

Housing: Die-casting aluminum

Exterior: Stainless steel

Globe: Tempered glass

Gasket: silicone rubber

Packaging logistics


   1  Application

Working in potentially explosive areas require explosion proof lighting solutions. We have taken advantage of these multiple technology developments to design a new range of explosion proof LED work lights providing powerful illumination, extreme durability, versatile functionality, and very long lifetime.

The explosion proof work lights are approved and certified according to the latest European ATEX directive.

Caution

-Schematic diagram

1.Before installation, it is necessary to check whether the actual operating conditions are in conformity with the parameters listed on the lamp nameplate.
2.Before installation, please test the lighting according to the parameters of the lamp nameplate to ensure that there is no quality problem before installation.
3.Before installation, it is necessary to determine the installation location and mode of the lamps according to the installation mode provided by the product, in combination with the on-site use environment and lighting requirements, so as to ensure that the installation is firm and reliable.
4.Connect the prepared cables with the input cables of lamps and lanterns according to the corresponding fire (brown), zero (blue) and ground (yellow-green) wires, so as to ensure that the connection is firm, and make good insulation and waterproof measures at the connection.
5.The input end of the cable can be connected to the power supply of the corresponding voltage to illuminate.

-Using The Matters Needing Attention

1. When transporting, the lamp should be installed in the carton equipped with foam shock absorption.
2. When using, the surface of the lamp has a certain temperature rise, which is a normal phenomenon.
3. The power supply voltage can work normally in the rated voltage. If the power supply voltage is too high, the lamp will be damaged; if the voltage is too low, the lamp will not start normally.
4. The luminaire must be reliably grounded.

-Quality Assurance

The company has passed ISO9001:2008 international quality system audit certification, this product strictly implements ISO9001 international quality management system standard production, to ensure that the product quality fully meets national standards and design requirements.
Explosion Proof Exit Light EX proof Emergency Light Explosion-Proof High Bay Light

   1  FAQ

1.Why is Explosion Proof Lighting necessary in your area?
Plenty of commercial facilities have areas where lighting fixtures can come into contact with hazardous materials. These can be flammable, combustible, or ignitable materials, gases, or vapors. These areas can be at risk of fire or even explosion if the lighting fixtures can't withstand the abnormal conditions.

2.What is hazardous location lighting?

Hazardous location lighting refers to fixtures that you can safely use in an area where it's likely that fire might start. According to the National Electrical Code, hazardous locations are those areas "where fire or explosion hazards may exist due to flammable gases or vapors, flammable liquids, combustible dust, or ignitable fibers or flyings."

3.What is explosion-proof light fixture?

Explosion proof lighting refers to lighting fixtures that are able to contain sparks that could potentially  the flammable and explosive gases in the atmosphere. Therefore, explosion proof lighting does not refer to lighting equipment that are resistant to explosions but rather, the capacity to prevent external explosions from occurring in a hazardous location.

4.What environments require hazardous location lighting?

Presence of Flammable Liquids and Gases

Wherever flammable gases and liquids are present, the location may be identified as a hazardous one because such compounds can cause an explosion or catch fire.
Gas and liquids have to achieve a critical concentration before it becomes dangerous. However, once they do, that's when a potential disaster can occur.

   1  Company Profile

Finding suitable lighting for the work site that won't falter under extreme circumstances is what makes it most reliable in any situation. Lamp suite explosion proof lighting is 100% certified with non-spark, durable, and thick materials, along with all necessary features to maintain a high level of safety at all times.

So, what makes Lamp suite different?
Our expertise in solar and technical lighting solutions allows us to give you the appropriate explosion proof lighting to suit you and your business's needs the best. As a result, you can expect outstanding LED performance, lower costs, increased productivity, and safety adherence to give you and your workers total peace of mind.

Lamp suite has a passionate team aiming to help you create a safe working or public environment where workers, pedestrians, shoppers, or anyone nearby can feel comfortable moving around.
