Лабораторный вытяжной шкаф химия обычный безопасности 1 2 м 5 8 электронный вентиляционное лабораторное оборудование
- Категория: >>>
- Поставщик: Guangzhou Max Laboratory Equipment Co. Ltd.
Сохранить в закладки 1601021220316:
Описание и отзывы
Характеристики
1.Hood body&base cabinet: 1.0mm full-thickness high-quality cold-roll steel sheet is used as a whole; the steel surface is treated, phosphating and other processes, and then electrostatic powder sprayed with epoxy resin, cured at 220°C high temperature. and the surface is smooth, with a thickness of up to 1.15mm~1.2mm.
2.Standard Work Surface: Phenolic Resin.
Optional: Epoxy Resin/PP/Stainless Steel/Ceramic/Trespa/Granite/Marble.
3.Controller: Intelligent switch with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc.
4.Glass sash: Use explosion-proof 5mm tempered glass, aluminum alloy sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels.
5.Lighting: Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX,
6. Fume hood liner liner and Baffle: Use 5mm Compact grade laminate, baffle fixed with PP material
7. Junction box: The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage.
8. Standard accessories:
1x bench-mounted single water tap
1x PP oval cupsink
4x Electrical Outlets
1x 250 or 315mmφ PP hood.
9.Optional accessories:
Remote Controlled Fixture gas&water faucet
Explosion-proof light
Distillation Grid Kit
Acid and flammable base cabinet
Ductwork
Exhaust blower
Optional: Epoxy Resin/PP/Stainless Steel/Ceramic/Trespa/Granite/Marble.
3.Controller: Intelligent switch with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc.
4.Glass sash: Use explosion-proof 5mm tempered glass, aluminum alloy sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels.
5.Lighting: Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX,
6. Fume hood liner liner and Baffle: Use 5mm Compact grade laminate, baffle fixed with PP material
7. Junction box: The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage.
8. Standard accessories:
1x bench-mounted single water tap
1x PP oval cupsink
4x Electrical Outlets
1x 250 or 315mmφ PP hood.
9.Optional accessories:
Remote Controlled Fixture gas&water faucet
Explosion-proof light
Distillation Grid Kit
Acid and flammable base cabinet
Ductwork
Exhaust blower
Model | FH-120 | FH-150 | FH-180 | ||
External Dimension (W*D*H)(mm) | 1200*850*2350 | 1500*850*2350 | 1800*850*2350 | ||
Internal Dimension (W*D*H)(mm) | 960*680*1150 | 1260*680*1150 | 1560*680*1150 | ||
Base Cabinet Dimension (W*D*H)(mm) | 1200*800*850 (Can remove) | 1500*800*850 (Can remove) | 1800*800*850 (Can remove) | ||
Exhaust air volume | 700-1300m³/h | 900-1700m³/h | 1300-2100m³/h | ||
Air Velocity | 0.3～0.8 m/s | ||||
1.0mm full-thickness high-quality cold-roll steel sheet is used as a whole; the thickness of up to 1.15mm~1.2mm. The cabinet door
is double-layered inside and outside, filled with sound insulation material.
is double-layered inside and outside, filled with sound insulation material.
Phenolic Resin with water baffle.
Optional: Epoxy Resin/PP/Stainless Steel/Ceramic/Granite/Marble.
Optional: Epoxy Resin/PP/Stainless Steel/Ceramic/Granite/Marble.
Use explosion-proof 5mm tempered glass, aluminum alloy sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels.
Baffle
Use 5mm Compact grade laminate, fixed with PP material.Three-stage design, there is no blind angle of airflow in the cabinet, and all the toxic and harmful gases of different specific gravity generated during the experiment can be discharged out of the cabinet.
Use 5mm Compact grade laminate, its structure has a pressure release effect on explosive.
Aerodynamic curve allows air to sweep the work surface maximizing containment. Reduces energy consumption by 7-10% compared to flat air foils.
By-pass airflow design with variable air volume compatibility. Compensating opening that maintains a relatively constant volume exhaust through a Fume Hood regardless of sash position and that functions to limit the maximum face velocity as the sash is lowered.
Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX.
Removable service access on both sides for easy installation and maintenance of circuits, gas circuits and other accessories.
Intelligent button or touch screen with digital display, multiple controls power on, fan, lighting, socket, sterilization, damper,
etc.
etc.
Junction box
The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage.
Crash pad
Effectively prevent impact damage and reduce noise.
Glass Sash Chute
Effectively prevent the window from shaking back and forth and protect the door frame.
Sash Weight Chute
Effectively reduce shaking during operation, reduce noise, and avoid damage during transportation.
Synchronous Belt&Pulley
PP+Fiber+Steel Wire Material, belt surface is durable, with less friction for movement and easier sliding.
Hinge
DTC buffer hinge, good corrosion resistance and long service life.
Footing
Use lab-specific adjustable feet with an adjustment range of ≥35mm, strong bearing capacity, the balance of the Fume hood can be adjusted.
Water Tap& Sink
1x Bench-mounted single water tap
1x PP oval cupsink
1x PP material anti-siphon bottle trap
Remote control system (Optional)
Interior mounted hole for gas, air, water, vacuum and other services have remote control knobs on the corner posts for use regardless of sash position. Prepared for up to two fixtures on each side (Four total). More than four fixtures are available.
Exhaust hood
Used PP material and one-piece molded and top outlet pipe diameter is Ф250/315mm
Electric Outlet
Each national standard electric outlet is available
Q: Are you a factory or trade company?
A: Direct factory. Relying on largest lab manufacturer creates competitive price, build safe, functional laboratories at the most economical cost.
Q: May I have my own design?
A: Yes, welcome. If you have your own design, please kindly send the Layout or plan to us. The designer team will make 3D drawings and Rendering drawings.
Q: Can I customize the size and color?
A: Yes, of course. Custom sizes and colors are available, customized according to customer needs.
Q: What are the payment terms?
A:T/T , Alibaba trade assurance, L/C, or by the West Union.
Q: What is the delivery time?
A: Standardized production lines, sufficient inventory of module products, complete production in the fastest time, and the
delivery time is 30% faster than that of peers.
Q: Do you have certifications for your products?
A: Yes, We have CE, ISO9001, ISO14001, OHSASI18001 and so on.
