Products Description
I. Product
1.1 Overview
The training sets include a variety of types of power electronics typical application circuit units, through the related experiments, can be familiar with thyristor electrical characteristics, to master the control principle and control mode, raises the student the corresponding knowledge and skills, suitable for higher vocational colleges, higher technical, secondary vocational school and technical school related professional teaching and skill training evaluation.
1.2 Feature
(1) Training bench with aluminum column frame structure, the power supply built-in integrated installation, safe and convenient to use, is not easy to damage.
(2) unit circuit hanging box configuration are complete, combination use, complete variety of critiquing the training content.
(3) It can be set for an experiment subjects related units hang flexible increase or decrease in the box, in order to meet different user requirements.
(4) Training platform has a good safety protection system.
II Character parameter
(1) Input power: three phase, five wire, 380V±10% 50Hz
(2) Dimension:1600mm×800mm×1800mm(stand type)
Dimension: 1600mm×400mm×950mm(frame type=desktop type)
(3) Whole capacity: ＜2.0KVA
(4) Weight: ＜100kg
(5) Work condition:
Environment temperature: -10℃～+40℃
Relative humidity: ＜85%(25℃)
1.1 Overview
The training sets include a variety of types of power electronics typical application circuit units, through the related experiments, can be familiar with thyristor electrical characteristics, to master the control principle and control mode, raises the student the corresponding knowledge and skills, suitable for higher vocational colleges, higher technical, secondary vocational school and technical school related professional teaching and skill training evaluation.
1.2 Feature
(1) Training bench with aluminum column frame structure, the power supply built-in integrated installation, safe and convenient to use, is not easy to damage.
(2) unit circuit hanging box configuration are complete, combination use, complete variety of critiquing the training content.
(3) It can be set for an experiment subjects related units hang flexible increase or decrease in the box, in order to meet different user requirements.
(4) Training platform has a good safety protection system.
II Character parameter
(1) Input power: three phase, five wire, 380V±10% 50Hz
(2) Dimension:1600mm×800mm×1800mm(stand type)
Dimension: 1600mm×400mm×950mm(frame type=desktop type)
(3) Whole capacity: ＜2.0KVA
(4) Weight: ＜100kg
(5) Work condition:
Environment temperature: -10℃～+40℃
Relative humidity: ＜85%(25℃)
Input power | Three-phase four-wire system AC380V±10% 50Hz | |
Dimensions | 1800X1760X700mm | |
Machine capacity | <1.5KVA | |
Working conditions | <120kg | |
Safety protection | Ambient temperature -10℃～+40℃ relative humidity ＜85% (25℃) | |
With leakage voltage and leakage current protection devices, safety compliance with national standards | ||
Product Details
3.1 Power control panel
The power control panel using aluminum alloy profile panel, enclosed body structure, and placed at the bottom of a connection as one.
3.2 Training workbench(only for stand type)
Training workbench use aluminum structure. There are universal 4 wheels at the bottom of workbench, there are 2 breakers on wheel. The trainer can be moved or stop convenient . The workbench panel thick is 25mm high density substrate , there is high temperature high pressure anti-fire treatment process. It equip with three guide rail type drawer, 2 push and plug cabinet. The structure is sound and reliable, outlook is beautiful.
3.3 Power box
(1)Three phases, five wires power input, it has been tested by leakage
breaker control, it has emergency stop button, you can cut off electricity
when emergency.
(2)Control panel has two point type voltage meter, one current meter, one power meter, one non power meter.
(3)It equipped with indicator, Europe power plug output, safety output sockets.
(4)Inner AC 220V current output, DC 220V wound power, DC 0-220V continuous adjustable DC armature power, with short circuit protection function.
4.The bench allows the following :
(1)The study of linear command of the speed and position in open loop and closed loop
(2)Adjusting with many correctors type (P, PI, PD, PID, …)
(3)Data acquisition (speed, position, voltage, current, …)
(4) simulation experiment of motor/generator braking system
(5) test of speed sensor and location sensor
5.The bench is composed by:
Operative part realized around a motor/generator driven dispositive (with nameplate) DC current 15W.
Brake system adapted to the motor/generator
Speed sensor and position sensor which must be visible and accessible
Power supply for the motor maneuvering and sensors powering
Display device (by graduated disc) and motor movement reading
Front face including a synoptic schema with safety socket for analogical input and output for signal acquisition of motor command
Function generator (level, ramp, sinusoid) adjustable with value indication
Power supply 230V/50Hz with protection against warming and short-circuit
The bench allows both functioning modes:
Autonomous (without PC)
With PC (in that case, interface ship and software are required)
The power control panel using aluminum alloy profile panel, enclosed body structure, and placed at the bottom of a connection as one.
3.2 Training workbench(only for stand type)
Training workbench use aluminum structure. There are universal 4 wheels at the bottom of workbench, there are 2 breakers on wheel. The trainer can be moved or stop convenient . The workbench panel thick is 25mm high density substrate , there is high temperature high pressure anti-fire treatment process. It equip with three guide rail type drawer, 2 push and plug cabinet. The structure is sound and reliable, outlook is beautiful.
3.3 Power box
(1)Three phases, five wires power input, it has been tested by leakage
breaker control, it has emergency stop button, you can cut off electricity
when emergency.
(2)Control panel has two point type voltage meter, one current meter, one power meter, one non power meter.
(3)It equipped with indicator, Europe power plug output, safety output sockets.
(4)Inner AC 220V current output, DC 220V wound power, DC 0-220V continuous adjustable DC armature power, with short circuit protection function.
4.The bench allows the following :
(1)The study of linear command of the speed and position in open loop and closed loop
(2)Adjusting with many correctors type (P, PI, PD, PID, …)
(3)Data acquisition (speed, position, voltage, current, …)
(4) simulation experiment of motor/generator braking system
(5) test of speed sensor and location sensor
5.The bench is composed by:
Operative part realized around a motor/generator driven dispositive (with nameplate) DC current 15W.
Brake system adapted to the motor/generator
Speed sensor and position sensor which must be visible and accessible
Power supply for the motor maneuvering and sensors powering
Display device (by graduated disc) and motor movement reading
Front face including a synoptic schema with safety socket for analogical input and output for signal acquisition of motor command
Function generator (level, ramp, sinusoid) adjustable with value indication
Power supply 230V/50Hz with protection against warming and short-circuit
The bench allows both functioning modes:
Autonomous (without PC)
With PC (in that case, interface ship and software are required)
