Однокристаллические алмазные частицы для изготовления алмазного инструментального материала

Generic

Application

Crystal Growth Process

Primary Application

Product Range

Cutting Tools&Wear Part

Single Crystal

CVD -Colourless

(Low nitrogen content)

Ultra precision machining

acrylics, copper, germanium

Generates very high surface finishes

Poly-crystalline

CVD - Opaque

(Low

nitrogen content)

Wide-ranging laser cut shape

and size for Precision machining

of MMC and CFRP materials

Wide-ranging laser cut shape and size for Precision machining

of MMC,

CFRP and woodworking materials.

Single Crystal

HPHT - Pale yellow

(Medium nitrogen

content)

Long edge length requirements

(e,g. profile tools)

Long edge length requirements

(e,g. controlled waviness tools)

Engineered cutting tools and

wear parts for super-finishing,

burnishing and wire guides

Convenient cut shapes(RECTANGLE,

TRIANGLE,ROUND)

Super-finishing and precision

machining e.g. precious metals

and MMC materials

Dressing

Single point, multipoint, blade,

roller and rotary dressing

Chisel dressing

chisel form dressing

Poly-crystalline

CVD - Opaque

(Low

nitrogen content)

Strong and more wear resistant

grade for single point and blade dressers

General purpose grade for

cutting tools and rotary dressers

Wire Drawing

HPHT Pale Yellow

(Medium

nitrogen content)

Wire drawing of ferrous, non

ferrous precious and

refractory metals

Available size

No.

Shapes

Size(mm)

Thickness(mm)

Orientation

SCD12

Near Square

1-4.5

0.3-1.7

4pt, 2pt

<100> <110> <111>

SCD22

Near Square

1-4.5

0.3-1.7

SCD13

Near Hexagon

1-8.0

0.3-1.7

SCD23

Near Square

1-8.0

0.3-1.7

SCD33

Near Square

1-8.0

1.0-1.2

SCD11

Rectangle/Triangle
Round/sex-angle ect

0.3-5.0

0.3-1.7

We have customized

1x2x3,1x1.2x4, 1.2x3x4, 1.2x4x5, 1x1x4, 1x1x5, 1x2x4, 0.5x2x4, 3.2x3.2x1.2, 1x1.5x3mm

Other size also can be customize other
