Product Description
This rechargeable Fetal Doppler is a hand-held obstetrical unit, which can be used in a hospital, clinic, or home for daily self-check by healthcare professionals or as directed by a healthcare professional. The intended use of this product is detection of the fetal heart rate and fetal heart beat sound listening as an aid for
determining fetal viability.
determining fetal viability.
Product Name | Home use pregnancy rechargeable fetal doppler |
standard accessory | 1pc host(with build in lithium battery), 1pc probe, 1pc USB charging cable, 1pc user manual, inner plastic blister, 1pc gift box |
Optional add accessories | Optional add accessories |
Function | uses the principle of ultrasound Doppler to obtain fetal heart movement information from the pregnant woman's abdomen, amplifies the signal and outputs it from the horn, and calculates the fetal heart rate value. |
Material | ABS plastic |
Suitable user | for pregency women more then 12 weeks to monitoring fetus heartbeat rate |
working modes | Real-time FHR Display |
Battery | rechargeable build-in 600mAh 3.7V lithium battery |
Battery using type | every full charging can use about 120 minutes |
Charging type | USB charging |
Waterproof level | host IPX0, probe IPX1 |
Operating Frequency | 3.0MHz |
Probe sensitivity | At the 200mm distance from the probe surface,The compr ehensive sensitivity should not be less than90dB |
Fetal dopppler size | host: 130*65*30mm; probe: 108*28mm |
Bluetooth | Optional add, price is different, please inquiry the supplier |
Product Features
This rechargeable fetal doppler device is a non-invasive handhold Doppler with an internal speaker. This device has the following special features:
* 9 Volume levels can be adjust: 0-8 gear
* Sound output: through the build-in loud speaker, no headphone socket
* Battery indicator: the battery indicator Icon do not display while devcie is with enough battery power; the battery Icon only display when it is low power that need to be charging; the battery Icon flash when low power, and when it is charging, the battery Icon is flashing in orange color; after full charging, the battery Icon stop flash, and turn into green.
* Fetal heart rate signal induction intensity: 3 levels
* Suitable user: 12weeks-40 weeks pregnant women
* Bluetooth: Optional add(price different)
* Sound output: through the build-in loud speaker, no headphone socket
* Battery indicator: the battery indicator Icon do not display while devcie is with enough battery power; the battery Icon only display when it is low power that need to be charging; the battery Icon flash when low power, and when it is charging, the battery Icon is flashing in orange color; after full charging, the battery Icon stop flash, and turn into green.
* Fetal heart rate signal induction intensity: 3 levels
* Suitable user: 12weeks-40 weeks pregnant women
* Bluetooth: Optional add(price different)
The volume can be adjusted by press “+” or “-” button ，There are 9 leverl, from 0-8，0 means no mute.8 is the highest leverl. each press“+”or“-”key, the volume can be increase or decrease one level. When the fetal heart monitor is turned off, the current volume setting will be automatically saved. The next time it is turned on, the fetal heart monitor will automatically adjust to the volume level before turning off.
The quality of fetal heart rate signals is divided into three levels: poor, average, and good, as shown in above photo (a), (b), and (c), respectively. When the quality of the fetal heart rate signal is poor, the user should adjust the position of the probe to find the position where the fetal heart rate sound is loudest and clearest, and then fix the position of the probe. At this time, the signal quality will improve.
Details Images
How to use
Using steps:
① Power on by pressing the Power button.
② Find the position of fetus.
At first, please feel the position of the fetus by hand .Find out the best direction for inspecting the fetal heart. Apply a
liberal amount of gel to the faceplate of probe; place the faceplate of probe at the best position for detecting fetal heart. Adjust the probe to obtain an optimum audio signal ideally by angling the probe around. Adjust the volume according to requirements.
③ FHR Calculation:
The FHR result will be showed on LCD screen.
④ Turn off the machine
Keep pressing the power button 3 seconds to turn off.
② Find the position of fetus.
At first, please feel the position of the fetus by hand .Find out the best direction for inspecting the fetal heart. Apply a
liberal amount of gel to the faceplate of probe; place the faceplate of probe at the best position for detecting fetal heart. Adjust the probe to obtain an optimum audio signal ideally by angling the probe around. Adjust the volume according to requirements.
③ FHR Calculation:
The FHR result will be showed on LCD screen.
④ Turn off the machine
Keep pressing the power button 3 seconds to turn off.
