20 тонн мобильный автокран ZTC201V551 с лучшим обслуживанием

Сохранить в закладки 1601034037503:


Цена:3 719 375,60 ₽ - 3 828 769,00 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики


20 Ton Mobile Truck Crane ZTC201V551 with Better Service


Safety and reliability
Back up sonar and operation buzzer are installed to notify the driver and operator of the obstacles behind the cranes.
High-precision moment limiter is working for relaible real-time loading.
Multiple sensors help operation monitoring.

GCP remote control
Operation conditions and data are collected, making long-distance
troubleshooting and control possible.
This system enables online parts browsing and purchasing.






  • My wechat number : a19803840980


    company name : Tewrex

  • Suzhou subsidiary Address: Room 602, Building 2, Tiandu Building, No.211 Changjiang Road, High-tech Zone, Suzhou City

  • my what'sapp number : +86 19803840980


























































































































Item


Value


Remarks


Working performance specification


Max. rated total lifting capacity kg


20000



Max. load moment of basic boomkN.m


850



Max. load moment with max. main boom lengthkN.m


458.6



Max. lifting height of main boom m


32.60


Deformation of boom is not taken into consideration.


Max. lifting height of fly jibm


40.4


Working speed


Max. speed of single rope on main winchm/min


120


The 4th layer of drum


Derricking time of booms


60



Telescopic time of booms


70



Slewing speedr/min


0~1.8



Traveling specification


Max. traveling speedkm/h


70



Min. turning circle diameterm


20



Min. ground clearancemm


250



Oil consumption per hundred kilometersL


40



Mass specification


Deadweight of crane in traveling conditionkg


26080



Complete vehicle kerb masskg


25885



Front axle loadkg


6380



Rear axle loadkg


19700



Dimension specification


Overall dimensions (L×W×H) mm


12320*2500*3400



Base on outriggersm


4.95



Distance between outriggersm


5.6



Fly jib lengthm


8
