Product Description
16 In 16 Out DSP Audio Processor AFC,AEC, ANC,AUTOMIX, RS 232 and Camera
Control Dante 16 Channel
The DSP-1616N2/DSP-1616ND2/DSP-1616ND3 audio processor combines Auto Mixer, Matrix Mixer, and Feedback suppressor in one purpose-built DSP processor. At the same time, it has independent FIR/AFC/ AEC/ ANS/ AGC gain sharing automatic mixing, threshold automatic mixing and other processing modules. The /DSP-1616ND2/DSP- 1616ND3 includes 16 mic/line analog inputs, 16 analog outputs to meet the needs of a wide range of audio processing applications such as boardroom, medium/large conference rooms, courtrooms, auditoriums and multi-purpose halls.
Features:
* 16-channel analog input and 16-channel analog output, Microphone or Line in switch
* +48V Phantom power per input channel
* AFC in each input
* AUTO-MIX and MATRIX-MIX
* 15 PEQS per input and 10 PEQS per output
* USB free driver connect, RS232/485 connector for center control
Ordering Code:
DSP-1616N2: 16 In 16 out DSP audio processor AFC,AEC, ANC,AUTOMIX, RS 232 and camera control DSP-1616ND2: 16 In 16 out DSP audio processor AFC,AEC, ANC,AUTOMIX, RS 232 and camera control Dante Ultimo 4 Channel
DSP-1616ND3: 16 In 16 out DSP audio processor AFC,AEC, ANC,AUTOMIX, RS 232 and camera control Dante 16 Channel
Details Images
Specification
Input Channels | 16 balanced. Mic/line level |
Connectors | 3.81 mm Euro block |
Input Impedance | 11.5KΩ |
Maximum Input Level | 14dBu/Line, -7dBu/Mic |
Phantom Power | +48VDC, 10mA, selectable per input |
Output Channels | 16 balanced, line level |
Output Impedance | 150Ω |
Frequency Response | 20Hz-20kHz(+-0.5dB)/Line 20Hz-20kHz(+-1.5dB)/Mic |
THD+N | LINE: 0.003% MIC: 0.005% |
SNR | 105dB(@12dBu,1kHz,A-wt)/Line 95dB(@-7dBu,1kHz,A-wt)/Mic |
USB | Micro-B type, free driver |
RS232 | Serial port communication |
TCPIP | RJ-45, Optional |
LED Status Indicators | Power, Link, +48V, Input and Output Audio signal |
Mains Voltage | AC100V---240V 50/60 Hz |
Dimensions | 44mmx483mmx210mm |
Net Weight | 2.8kg |
Operating Temperature | -20℃-60℃ |
Cooling System | Active, Fan inside |
Signal Processor | 32-bit fixed/floating-point DSP 300MHz |
Audio Latency | < 1ms |
A/D and D/A Converters | 24-bit |
Sample Rate | 48KHz |
