Products Description


For automotive and general purpose use

High sealing and easy installation

Have a strong fastener force

Stainless steel / Galvanized Ideal for any
exhaust system Saddle-type clamp for added strength

Thread size on clamps is 8mm-1.25
Choose from 1-1/2", 1-5/8", 1-3/4", 1-7/8", 2", 2-1/8", 2-1/4", and 2-1/2" pipe diameter



*Brand
TheOne
*Style
U bolt hose clamp
*Material Type
W1 series (all the parts are carbon steel )
W4 series (all the parts are SS200 or 300 )
W5 series (all the parts are SS316 )
*Size
25mm-200mm normally
*Package
plastic bags+ cartons
*Dimension information
All dimension can be customized
*Original place
Tianjin, China











Size List


size
(mm)
bolt size
(mm)
pcs/Ctn
Ctn size
(cm)
G.W./Ctn
(kg)
25
M8
250
38*27*29
21.30
28
M8
250
38*27*29
22.50
32
M8
200
38*27*29
19.80
35
M8
200
38*27*29
20.40
38
M8
150
38*27*29
15.80
45
M8
150
38*27*29
15.90
48
M8
150
38*27*29
16.50
51
M8
100
38*27*27
12.50
54
M8
100
38*27*27
12.80
57
M8
100
38*27*27
13.50
60
M8
100
38*27*27
14.10
64
M8
100
38*27*27
14.80
67
M8
50
38*27*24
8.30
70
M8
50
38*27*24
8.60
73
M8
50
38*27*24
8.80
76
M8
50
38*27*24
8.90
83
M10
25
38*27*20
4.60
89
M10
25
38*27*20
4.80
95
M10
25
38*27*20
5.10
102
M10
25
38*27*20
5.13


Application


U  bolt  clamp
In this case, Hex Nuts are used both above and below the hole in the beam, to help prevent any movement in the bolt. It is
possible to use these bolts to either clamp down or hang pipes in a saddle type fashion, depending on your project's needs. You
can also combine them with other types of beam clamp if needed.
U Bolts for pipes can be supplied in either hot dip galvanised or stainless steel, and normally to suit pipe diameters from
21mm,through to 630mm, however, larger bolts can also be arranged if needed..


Related Products




Company Introduction




Tianjin TheOne Metal Products Co.,Ltd which was founded in 2008 , has 150 employees, with a factory covering an area of 5,000 square meters. It is a professional manufacturer of fastener products, located in Ziya Recycled Economy Industrial Park.
We are a hose clamp factory with 17 year' production experience. Products are widely used in automotive, ship, aviation, construction, sewage pipelines, drainage pipes, machinery and other fields. There are three production lines in the factory, including a heavy duty hose clamp series, light duty hose clamp series and stamping products series. The main products are Robust Bolt Hose Clamp, Pipe ClampWith Rubber, Strut Channel Clamp, Loop hanger, U bolt Clamp , V Band Clamp , German Type Hose Clamp , American Type Hose Clamp, British Type Hose Clamp , Rubber Lined P Clips, Double Wire Hose Clamp etc.

In general, screw/band hose clamps tend not to be used for ultra high-pressure scenarios, but instead are used frequently in lower-pressure environments, as well as when a quick fix is needed, especially within the home. That said, numerous industries utilise them, including the automotive, agriculture and marine industries.





Exhibition




Why Choose Us


Professional
1).21Years Production Experience And 13 Years Export Experience .
2).More Than 30 Kinds Of Clamps To Achieve The One- Stop Purchasing
3).Make The Professional Inspection Report And Photos

Service
1).Sellers With At Least 5 Years Working Experience In “THEONE” Follow Up The Projects.
2).Better Product Quality Thanks To An Implemented Quality Management System According To ISO 9001.
3).Reply And Solve Complaint Problems Within 24 Hours.

Efficiency
1).Send Out Any Time In Stock
2).25 Days Production Time For A 20’ Container Order
3).Two Workshop Produce At The Same Time
4).5 Sets Of Fully Automated Equipment Improve 30% Production Efficiency Than Workers


FAQ


Q1: Are
you trading company or manufacturer?
A: We are factory

Q2: What’s the MOQ?
A: 500 or 1000 pcs /size,small order is welcomed

Q3: How long is your delivery time?
A: Generally it is 2-3 days if goods are in stock. Or it is 25-35 days if the goods are on producing, it is according to your
quantity

Q4: Do you provide samples? Is it free or extra?
A: Yes, we could offer the samples for free charge but do not pay the cost of freight

Q5: What is your terms of payment?
A: L/C, T/T and so on

Q6: Can you put our company’s logo on the band of the hose clamps?
A: Yes, we can put your logo if you can provides us with copyright and letter of authority, OEM order is welcomed.
