CPM7932 5 CPM 7932 5 CPM7932 7 7932 7 корм для древесины литьевое кольцо

CPM7932 5 CPM 7932 5 CPM7932 7 7932 7 корм для древесины литьевое кольцо

Категория: >>>
Поставщик: Liyang Hongyang Feed Machinery Co. Ltd

Цена:88 322,88 ₽ - 132 484,32 ₽*

Количество:

В избранное

Описание и отзывы

Характеристики

Products Description

Features:

1. Select high-quality refining and degassing blank outside the furnace
2. The die adopts imported gun drilling and multi-station group drilling, the die hole is formed at one time, the finish is
high, the production feed appearance is beautiful, the output is high, the discharge is smooth, and the granules are well formed
3. The die adopts the combined treatment process of the American vacuum furnace and the continuous quenching furnace, which is quenched uniformly, the surface finish is good, the hardness is high, and the service life is doubled.

Material	Hardness	Diameter	Outer diameter	Level	Certification
X46Cr13(stainless steel)	HRC52-55	0.8mm-28mm	<1800mm	1	CE/IOS
20CrMnTi(Alloy Steel)	HRC60-62	1.0mm-28mm	＜1800mm	1	CE/IOS

MODEL	Material	HRC	HOLE SIZE
CPM 2016-4	X46Cr13	52-55	1.0mm-18mm
CPM 3020-4
CPM 3020-6
CPM 3020-7
CPM 3022-6
CPM 3022-8
CPM 7722-2
CPM 7722-4
CPM 7722-6
CPM 7722-7
CPM 7726-7
CPM 7726-8
CPM 7726-9/CPM7726SW
CPM 7730-4
CPM 7730-6
CPM 7730-8
CPM 7730-10
CPM 7932-5
CPM 7932-7
CPM 7932-9
CPM 7932-11
CPM 7932-12
CPM 7936-12
CPM 7936-14

Custom Compression Ratio
Ensure uniform discharge

Pressure roller customization

Customized ring die,

all brands and models

0.8mm-20mm

Organic fertilizer bamboo particles floor sawdust rice husk pine wood

Cat litter crab feed fish feed shrimp feed ruminant feed

Rabbit feed pig feed piglets broilers duck feed

Customizable

High quality X46Cr13 material, can provide testing reports

CNC gun drilling machine

0.8-1.0mm hole size

Our ring dies are suitable for:

1. Biomass pellet machine: wood pellet machine, sawdust pellet machine, grass pellet machine, straw pellet machine, crop straw
pellet machine, alfalfa pellet machine, etc.
2. Livestock and poultry feed pellet machine: pig/cattle/sheep/chicken/duck/rabbit/snail/bird
3. Cat litter pellet
4. organic compound fertilizer
5. Aquatic feed：Fish and Shrimp

6.Activated carbon granules
