Airkey----Just For Your Need
Hot Sale and Competitive Price in Cleanroom Dynamic Pass Box
Product Description
PASS BOX in CLEAN ROOM
The machine is used for tansfer from the non-clean area into the clean area, which can effectively remove dust on the surface of materials, to prevent dust from being into the clean room. The degassing flow is filtered by a high efficiency two-stage filter,and the cleanliness in the transfer window can reach 100 grades. The equipment is widely used in LCD, photoelectric products, PCB,IC manufacturing, aseptic packaging and other places that need air purification.
The machine is used for tansfer from the non-clean area into the clean area, which can effectively remove dust on the surface of materials, to prevent dust from being into the clean room. The degassing flow is filtered by a high efficiency two-stage filter,and the cleanliness in the transfer window can reach 100 grades. The equipment is widely used in LCD, photoelectric products, PCB,IC manufacturing, aseptic packaging and other places that need air purification.
Dynamic Pass Box: Dynamic pass box used between clean area and clean area, unclean area and clean area, to pass the small items and to avoid the opening time of cleanroom door. It can remove the dust and keep the clean of the cleanroom. Will equipped the DOP port and pressure gauge.
MODEL | GDPB-600 | GDPB-800 | |
External Dimension W*D*H(mm) | 860*680*1250 | 1060*880*1450 | |
Internal Dimension W*D*H(mm) | 600*600*600 | 800*800*800 | |
Construction | Stainless Steel 304 | ||
View Window | 502*502*5 | 650*650*5 | |
Cleanliness | ISO Class 5 | ||
Air Velocity(m/s) | 0.45M/S±20% | ||
Filter | HEPA:99.99%0.3μm | ||
Manometer | Dwyer0-500Pa | ||
Test Port | SUS PAO， DOP | ||
Static Pass Box
Static pass box:Pass box is an equipment mainly used for passing small objects between 2 clean areas or between clean areas and unclean areas. Pass box reduces the closing and opening times of the cleanrooms, which helps to maintain areas on able air pressure in the cleanrooms .Pass box keeps the contamination condition to the lowest.
MODEL | GPB-500-E | GPB-600-E | |
External Dimension W*D*H(mm) | 690*580*640 | 790*680*740 | |
Internal Dimension W*D*H(mm) | 500*500*500 | 600*600*600 | |
Max.Consumption | 45W | ||
Construction-External | Painted Cold Rolled Steel or SUS | ||
Internal | SUS304 | ||
Air shower pass box
Air shower pass box：The air shower pass box is mainly used for materials entering the clean area from the non-clean area, which can effectively remove the dust on the surface of the materials and prevent the dust from being carried into the clean room by the materials. Cleanliness can reach 100 levels after primary filter and HEPA filter.
MODEL | GAPB600 |
External Dimension W*L*H(mm) | 790*680*1550 |
Internal Dimension W*L*H(mm) | 600*600*600 |
Working Table H2(mm) | 830 |
Cleanliness | Class 100 |
Air Velocity(m/s) | 20-24/0.3-0.6m/s |
Number Of Nozzles | 4Pcs |
Jetting Side | TOP Jetting |
Internal | SUS304 |
Max.Consumption | 750W |
Construction | Painted Cold Rolled Steel or SUS |
Packing & Delivery
Company Profile
Established in 1995, our company adheres to state-of-the-art design concept and manufacturing technology. We are proud to have won high remarks from our clients including SONY, CANON, FOXCONN, TYCO, etc.
We are capable of providing cleanroom package solutions from purification equipment design, sheet metal processing to machine assembly and testing. We have passed ISO9001:2000 which enables us to monitor every aspect of production to ensure products' performance and security.
We are capable of providing cleanroom package solutions from purification equipment design, sheet metal processing to machine assembly and testing. We have passed ISO9001:2000 which enables us to monitor every aspect of production to ensure products' performance and security.
FAQ
1. who are we?
We are based in Guangdong Province, China, start from 2002,sell to Domestic Market(40.90%),North America(14.00%),South Asia(12.00%),South America(11.50%),Southeast Asia(11.00%),Africa(1.80%),Eastern Europe(1.50%),Mid East(1.50%),Central America(1.40%),Southern Europe(1.30%),Northern Europe(1.00%),Oceania(0.70%),Eastern Asia(0.70%),Western Europe(0.70%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Cleanroom,Modular Cleanroom,Clean Booth,Air Shower,Filter
4. why should you buy from us not from other suppliers?
1. A total of 20 years experience in clean room package solution
2. A total of 100,000 square meters clean room engineering experience
3. Several factories of our own
4. ISO9001:2008
5. Sales and engineers are available for overseas onsite service
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Guangdong Province, China, start from 2002,sell to Domestic Market(40.90%),North America(14.00%),South Asia(12.00%),South America(11.50%),Southeast Asia(11.00%),Africa(1.80%),Eastern Europe(1.50%),Mid East(1.50%),Central America(1.40%),Southern Europe(1.30%),Northern Europe(1.00%),Oceania(0.70%),Eastern Asia(0.70%),Western Europe(0.70%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Cleanroom,Modular Cleanroom,Clean Booth,Air Shower,Filter
4. why should you buy from us not from other suppliers?
1. A total of 20 years experience in clean room package solution
2. A total of 100,000 square meters clean room engineering experience
3. Several factories of our own
4. ISO9001:2008
5. Sales and engineers are available for overseas onsite service
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
All inquiries will be replied in 24 hours( 7*24 h)
