MINLE Portable Diesel Concrete Mixer with Pump Machine/Self Loading Mobile Concrete Mixer with Pump for Construction
mobile/whatspp 86-19819535281
wechat/zzy13181817161
www.concretepumpfactory.com
Choose MINLE as partner,let us make every effort to support your custruction works!


Models | Unit | HBTS25-8-37 |
Max. Theor. Concrete Output | m³/h | 25 |
Concrete Pressure | mpa | 8 |
Theor. Max. Horizontal Delivery Distance | m | 400 |
Theor. Max. Vertical Delivery Distance | m | 130 |
Main Pump |
| Schneider,Mitsubishi,Panasonic |
Concrete Cylinder Bore × Stroke | mm | Φ140*750 |
Diesel Engine | kw | Weichai DEUTZ |
Rated Rotating Speed | r/m | 1480 |
Hopper Capacity | m³ | 0.3 |
Filling Height | mm | 1100 |
Fuel Tank Capacity | L | 200 |
Hydraulic Circuit Form |
| Opened-circuit |
Delivery Valves Style |
| S-valve |
Power | kw | 37 |
Out Dimension | mm | 4400*1450*1700 |
Total Weight | kg | 2500 |









Tain Minle Machine Manufacture Co., Ltd.
Factory with 25+ years of experience providing many types of concrete construction equipment, which has service more than 80 world-famous brands and maintained a repurchase rate of 95%.
The HBTS/JBS series concrete mixer/pump was widely used in building projects, such as water conservancy, electricity, railways, highways, tunnels, bridges and culverts, ports, mines, high-rise buildings, national defense engineering, etc. It was economical, practical, efficient, and can ensure the quality of concrete pouring, mixing or delivery, It is an ideal concrete conveying equipment.
With CE, ISO BV Certificate, past SGS CCIC Quality Test, OEM ODM and the special requirements we can also offer you the drawing and the best solution!!
Minle Factory is the professional factory of concrete pump, we focus on research and development, design, sales and after-sales service. We mainly engaged in diesel concrete pump, electric concrete pump, Concrete Mixer With Pump, truck mounted concrete pump, concrete shotcrete/spraying robot machine, mining concrete pump, concrete boom pump truck and the sludge transfer pump.
We have team of experts, our team of skilled engineers and technicians is committed to delivering exceptional customer service and support, always striving to exceed our clients' expectations, We pride ourselves on producing top-of-the-line concrete pumps with cutting-edge technology that meet the needs of our customers. Our team of experienced engineers and designers work tirelessly to ensure that every concrete pump that leaves our factory is of the highest quality and meets industry standards. From the initial concept to the final product, we take every step to ensure that our customers receive the best equipment.









Why Choose Us?
*National High-tech Enterprise
*Free spare parts, on-line trainning for free
*ISO BV CE Certificate, past SGS Quality Test
*100% on time delivery, penalty agreement for delay
*120% satisfied, offer oversea service for you promptly
*Exported to 100 countries, offered s ervice more than 1000 Customers

Contact: Zoey
mobile/whatspp 86-19819535281
wechat/zzy13181817161
www.concretepumpfactory.com
Choose MINLE as partner,let us make every effort to support your custruction works!
