Product Description
China Supplier Air Compressors Mining LIUGONG 25BAR 1100CFM All In one Screw Type Air Compressor Water Well Drilling Rig
Advanced product system
We have a great amount of experience in product design and manufacturing. The Product
Research Institute was established by depending on LiuGong Global R&D Center and is one of
the major research institutes at the LiuGong Global R&D Center and has a qualification of
National Energy Efficiency Laboratory.
Research Institute was established by depending on LiuGong Global R&D Center and is one of
the major research institutes at the LiuGong Global R&D Center and has a qualification of
National Energy Efficiency Laboratory.
Details Images
LGIR two-stage compression
helical-lobe compressor
helical-lobe compressor
Two-stage compression;
The air end is equipped with a forced
oil filling pump;
oil filling pump;
Heavy-duty air end design;
Excellent performance and upgraded
energy efficiency.
energy efficiency.
Intelligent control system
Color display, IP65 protection rating,
and high-precision synchronous
control;
and high-precision synchronous
control;
One key switches between high and
low voltages, plus stepless speed
regulation, and overall fuel consump
tion 10%-15% less than other
conventional products.
low voltages, plus stepless speed
regulation, and overall fuel consump
tion 10%-15% less than other
conventional products.
Control system & air intake system in
incubator
incubator
Self-developed control system and air intake system in incubator ensure the well starting performance under
extremely cold condition
extremely cold condition
Air intake system
Integrated with traditionally open and
closed functions, the air intake system
provides a solution to start intake valves
at low temperatures and when piston
seals fail, traditionally a challenge for
conventional equipment.
closed functions, the air intake system
provides a solution to start intake valves
at low temperatures and when piston
seals fail, traditionally a challenge for
conventional equipment.
Double air filters
Double filter elements of the Donaldson Air
Filtration System ensure that the compres
sor sucks in cleaner air.
Filtration System ensure that the compres
sor sucks in cleaner air.
Optimized pipeline design
The design focuses on the air circuit and oil circuit connections of the compressor.
Imported connecting sleeves, stainless
steel connecting pipes, and silicone
connecting pipes ensure a low leakage
rate for the product.
Imported connecting sleeves, stainless
steel connecting pipes, and silicone
connecting pipes ensure a low leakage
rate for the product.
Specification
Model | CSH1100A-25D | |
Pressure(Bar) | 23/25 | |
Air capacity(M3/min) | 26/31 | |
Compressor oil (L) | 110 | |
Air end | LGIR | |
Dual transformation | Dual | |
Engine | ||
Supplier | Cummins | |
Type | L9CSIV394C | |
Power(KW) | 294KW | |
Working and ldling speed(rpm) | 1700/1300 1900/1300 | |
Unit | ||
Weight(T) | 4.8T | |
Outlet×quantity | G2×1 & G¾×1 | |
Tire size×quantity | Skid Mounted | |
Overall dimensions (mm) | 3800x1800x2050 | |
Noise[dB(A)] | 83±3 | |
Company Profile
Sichuan Bashifu Group Co., Ltd. has been committed to the professional production of water well drilling rigs and down-the-hole drilling rigs, as well as the sales and maintenance of drilling tools and air compressors for more than 20 years. We have accumulated rich experience in professional maintenance technology and thoughtful and meticulous after-sales service. A large amount of usage data has been accumulated through extensive contact with users. The company independently developed a new generation of water well drilling rigs and won a number of national patents. This series of products has the characteristics of standardized configuration, compact and reasonable structure, fast drilling speed, economy and durability, and low failure rate.Once launched, it has been recognized by the market and is widely used in mining engineering construction, civil drilling, geothermal drilling and other fields.
Packing & Delivery
We have a variety of transportation modes and cooperate with many transportation companies. We always stand in the perspective of consumers and provide you with the cheapest sea freight.
