Высококачественный продукт, реальная эффективность, ветряная турбина 300 кВт, 500 кВт, 800 кВт с контроллером MPPT, автономный инвертор
31 249 794,00 ₽ - 33 113 816,80 ₽
Оптом 5kw Осевой поток с низким об/мин постоянный магнит без сердечника генератор для ветровой турбины
- Категория: >>>
- Поставщик: Wuxi Dingyue New Energy Technology Co. Ltd.
Сохранить в закладки 1601097184546:
Описание и отзывы
Характеристики
Specification
Model | X-5kw |
Started wind speed | 2m/s |
Cut-in wind speed | 3m/s |
Rated Wind speed | 10m/s |
Rated voltage(AC) | 48V-220V |
Rated power(W) | 5kw |
Max power(W) | 5.5Kw |
Rotor Diameter of Blades(m) | 2.8m |
Assembly weight | <230KG |
Blades colors | White |
Blades height | 2.8m |
Safe wind speed | ≤65m/s |
Blades quantity | 3 |
Blade material | Glass Fiber |
Generator | Three phase permanent magnet suspension motor |
Control System | Electromagnet |
Mount Height(m) | 2~12m |
Generator protection grade | IP54 |
Vork environment temperature | -25~+45° |
Work environment humidity | ≤90% |
Altitude | ≤4500m |
Overspeed protection | Electromagnetic brake |
Overload protection | Electromagnetic brake and the unloading unit |
Products Description
Application Display
Company Profile
Wuxi Dingyue New Energy Technology Co., Ltd focus on wind and solar hybrid system for more than 15 years in China Domestic Market.
Our products have CE and Rosh certificate. Our General Manager of Mr.Jason has full experience on wind and solar hybrid system.
Upon more than 15 years experience in this field, Wuxi Dingyue New Energy Technology Co., Ltd starts to go aboard and open Foreign Market in different countries on recent years. In order to provide the Right & Best Machines for our customers in different countries, Wuxi Dingyue New Energy Technology Co., Ltd try our best to learn from customer and study national conditions from customers markets.
Our mission is to provide a More Cost Efficient Solution for our customers. Suitable is the Best Way, Best for customers, for local market and even for our future. We treat it as our responsibility in every business.
Our goal is to get Trust from every customer who contacted with us. To show us sincerely in communication and our professional skills in business, and even to provide the most suitable machines for them to satisfy with their special need. We hope we can get the comments like: Best Machines, Best Service and Best Person which we met, after customers received our machines in their local side.
Our culture is to be Family and progress together. We treat every staff as a family member, we learned, we shared and We worked together to reach our goals. We will be better and better as long as we ALL progress together every minutes. A little change every day makes a big difference someday.
Wuxi Dindyue New Energy Technology Co., Ltd will be your Best Choice for business cooperation of ALL kinds of wind turbine system in China. Contact Us Now!
Our products have CE and Rosh certificate. Our General Manager of Mr.Jason has full experience on wind and solar hybrid system.
Upon more than 15 years experience in this field, Wuxi Dingyue New Energy Technology Co., Ltd starts to go aboard and open Foreign Market in different countries on recent years. In order to provide the Right & Best Machines for our customers in different countries, Wuxi Dingyue New Energy Technology Co., Ltd try our best to learn from customer and study national conditions from customers markets.
Our mission is to provide a More Cost Efficient Solution for our customers. Suitable is the Best Way, Best for customers, for local market and even for our future. We treat it as our responsibility in every business.
Our goal is to get Trust from every customer who contacted with us. To show us sincerely in communication and our professional skills in business, and even to provide the most suitable machines for them to satisfy with their special need. We hope we can get the comments like: Best Machines, Best Service and Best Person which we met, after customers received our machines in their local side.
Our culture is to be Family and progress together. We treat every staff as a family member, we learned, we shared and We worked together to reach our goals. We will be better and better as long as we ALL progress together every minutes. A little change every day makes a big difference someday.
Wuxi Dindyue New Energy Technology Co., Ltd will be your Best Choice for business cooperation of ALL kinds of wind turbine system in China. Contact Us Now!
Factory Tour
Events And Exhibitions
Packaging And Payment
FAQ
Q1:Is installation easy?
A:Yes, very easy.Every customer can do it by themselves. We supply you all the components and the isntallation mamual.
Q2:Is our wind enough for a wind generator?
A:Our wind generator can start running at low wind speed 1.5m/s, so if your average annual wind speed is more than 5mls, it can works wel.
Q3:Which model should I choose?
A:If you are not sure to choose the model, please contact our sales with the following points:
1. What appliance do you want to run by the system?How much watts are they?How long do they work?
2.Your average annual wind speed.
3.What kind of system do you want? On-grid or off grid?
Q4:Can I only buy parts of the whole system?
A:Yes, you can only buy wind turbine, controller, inverter etc.
Q5:Does the price include or exclude controller, inverter?
A:The Price is only for wind turbine, if you need whole system which includes controllerand inverter, batteries and pole, pls contact our sales for a detail quotation.
Q6:How can i fix wind turbine on the pole ?
A:For small horizontal axis wind turbine with pole connection, we have flange and hoopfor choice. The later one is easier to fix on the pole. Pls let the sales know your choice.
Q7:How to protect wind turbine during strong wind?
A:All the wind turbines are protected by controller. while the battery is full or wind speed is very fast,the controller would start a short circuit to slow down the wind turbine. Meanwhile, our model fromRC-2K to 10K wind turbines tail could fold to slow down the running speed as a protection as well.
Q8:What's the warranty ?
A:Wind turbine warranty is 1 year. lf it happens, we will send you spare parts for maintance,For distributors, we will prepare few spare parts in the package as a storage.
A:Yes, very easy.Every customer can do it by themselves. We supply you all the components and the isntallation mamual.
Q2:Is our wind enough for a wind generator?
A:Our wind generator can start running at low wind speed 1.5m/s, so if your average annual wind speed is more than 5mls, it can works wel.
Q3:Which model should I choose?
A:If you are not sure to choose the model, please contact our sales with the following points:
1. What appliance do you want to run by the system?How much watts are they?How long do they work?
2.Your average annual wind speed.
3.What kind of system do you want? On-grid or off grid?
Q4:Can I only buy parts of the whole system?
A:Yes, you can only buy wind turbine, controller, inverter etc.
Q5:Does the price include or exclude controller, inverter?
A:The Price is only for wind turbine, if you need whole system which includes controllerand inverter, batteries and pole, pls contact our sales for a detail quotation.
Q6:How can i fix wind turbine on the pole ?
A:For small horizontal axis wind turbine with pole connection, we have flange and hoopfor choice. The later one is easier to fix on the pole. Pls let the sales know your choice.
Q7:How to protect wind turbine during strong wind?
A:All the wind turbines are protected by controller. while the battery is full or wind speed is very fast,the controller would start a short circuit to slow down the wind turbine. Meanwhile, our model fromRC-2K to 10K wind turbines tail could fold to slow down the running speed as a protection as well.
Q8:What's the warranty ?
A:Wind turbine warranty is 1 year. lf it happens, we will send you spare parts for maintance,For distributors, we will prepare few spare parts in the package as a storage.
