51 2 В 16S BMS призматическая Солнечная инверторная батарея 100Ah 200Ah 300Ah LiFePO4 Pack 48В литий-ионная фосфатная
200,00-520,00 $
48V 100Ah 30kwH 20KWH 10KWH Lithium Battery Three Phase Solar Energy Storage Systems
- Категория: >>>
- Поставщик: ENTEN INTERNATIONAL GROUP COMPANY LIMITEDENTEN LIMITED
Сохранить в закладки 1601101034937:
Описание и отзывы
Характеристики
Product Details
1.Based on the original cabinet-type solar energy storage battery, ESS adopts the latest ESS battery system. According to market demand, this type of energy storage battery with high energy density, space saving and powerful power was developed. 2. energy storage bricks are stacked in parallel with 2units or 6UNITS batteries. In the process of power transmission, power consumption is reduced.
3.Fully retain the use of load power.
4.The battery cell uses the best safety
5.LiFePO4 battery to save costs.
This energy storage system (ESS) provides high-efficiency power regulation capabilities, and its applications include power demand management, power dispatch, and renewable energy. Residential, school, commercial and public utility applications.
3.Fully retain the use of load power.
4.The battery cell uses the best safety
5.LiFePO4 battery to save costs.
This energy storage system (ESS) provides high-efficiency power regulation capabilities, and its applications include power demand management, power dispatch, and renewable energy. Residential, school, commercial and public utility applications.
MODEL | DW-5.0LV | DW-10.0LV | DW-15.0LV | DW-20.0LV | DW-25.0LV | DW-30.0LV | ||||||
Battery Type | LiFeP04(LFP) | |||||||||||
Nominal Voltage(V) | 51.2V | |||||||||||
Nominal Capacity(KWH) | 5.42KWH | 10.85KWH | 16.28KWH | 21.7KWH | 27.13KWH | 32.56KWH | ||||||
Usable Capacity(KWH) | 4.87KWH | 9.76KWH | 14.65KWH | 19.53KWH | 24.41 KWH | 29.30KWH | ||||||
Design Life | 10+Years （25 ℃/77F) | |||||||||||
Physical | ||||||||||||
Dimension(mm) | 600*400*385 | 600*400*534 | 600*400*683 | 600*400*832 | 600*400*981 | 600*400*1130 | ||||||
Weight (kg) | 80 | 125 | 170 | 215 | 260 | 305 | ||||||
ELECTRICAL | ||||||||||||
Cycle Life | >6000. 25°C | |||||||||||
Discharge Voltage(V) | 40-48 | |||||||||||
Charge Voltage(V) | 56 -58.4 | |||||||||||
Charge/Discharge Current(A) | 83 (Recommended) 100A(Max) | |||||||||||
Internal Resistance | ≤30mΩ | |||||||||||
BMS | ||||||||||||
Power Consumption | <2W (Work) < 100mW(Sleep) | |||||||||||
Monitoring Parameters | System voltage, current, cell voltage,cell temperature, module temperature | |||||||||||
SOC | Intelligent algorithm | |||||||||||
Communication | CAN/RS-485/RS-232 | |||||||||||
OPERATION | ||||||||||||
Operating Temperature Range | -10℃-50℃ | |||||||||||
Transport or Storage Temperate Range | -20℃-45℃ | |||||||||||
Humidity | 15% - 85% (No Condensing) | |||||||||||
WARRANTY | ||||||||||||
Product Warranty | 5 Years | |||||||||||
Performance Warranty | 10 Years | |||||||||||
Projects
48V 100Ah Powerwall lithium battery pack for home
30kw residential system in Australia, saving much electricity bills
100KW PCS and 120kw sever rack battery for US cutomers
50KW mono solar panels ground installation in farmland
12V 100Ah Gel battery with solar panels installation in Vietnam House
Industrial and commercial energy storage system
