192V 50Ah | 192V 100Ah | 384V 50Ah | 384V 100Ah | 384V 280Ah | |||||
Combination Mode | 3 groups of 76.8V50Ah batteries are connected in series | 3 groups of 60V100Ah batteries are connected in series | 5 groups of 76.8V50Ah batteries are connected in series | 6 groups of 60V100Ah batteries are connected in series | 8 groups of 48V280Ah batteries are connected in series | ||||
Usable Capacity | 9600 Wh @C2, 25°C | 19200 Wh @C2, 25°C | 19200 Wh @C2, 25°C | 38400 Wh @C2, 25°C | 107.52kwh @C2, 25°C | ||||
Nominal Voltage | 192 VDC | 192 VDC | 384 VDC | 384 VDC | 384VDC | ||||
Operating Voltage Range | 150VDC – 216VDC | 150VDC – 216VDC | 300 VDC – 432VDC | 300 VDC – 432VDC | 336 VDC – 432VDC | ||||
Charging temperature range | 0°C – 55°C | 0°C – 55°C | 0°C – 55°C | 0°C – 55°C | 0°C – 55°C | ||||
Discharger temperature range | -20°C – 60°C | -20°C – 60°C | -20°C – 60°C | -20°C – 60°C | -20°C – 60°C | ||||
Dimensions (mm) | 600*600*800mm (W x L x H) | 600*600*1200mm (W x L x H) | 600*600*1200mm (W x L x H) | 600*600*1800mm (W x L x H) | 1150*800*1600mm (W x D x H) | ||||
Weight (kg) | ≈170 kg | ≈265 kg | ≈265 kg | ≈450kg | Battery:≈950kg | ||||
Operating Voltage Range Current (max.) | 50A continuous | 100A continuous | 50A continuous | 100A continuous | 200A continuous | ||||
communication protocol | If the agreement is specified, we need to send the agreement document to our company for confirmation before placing the order. If it is not specified, we will follow our default agreement | ||||||||
