HEPA Filter Terminal Box
Product Description
HEPA Filter Terminal Box is used as a terminal filtration device for the renovation and new construction of ISO 3 to ISO 6 clean rooms,and it is the key equipment to meet the purification requirements. It is mainly composed of a static pressure box, a hepa filter, a filter casing, and a diffusion type (diffuser) orifice plate. It has the advantages of beautiful shape, simple structure and simple construction. This equipment is widely used in biological laboratories, pharmaceutical factories, hospitals, food processing, electronics factories, painting and other air purification places.
Configuration Option
①5According to material: Powder coated steel, Polish SUS 201/304/316; Mirror SUS 201/304/316
② According to air supply requirements: Side Air Supply: side flange air inlet and lower diffuser plate air supply. Top Air Supply: top flange air inlet, lower diffuser plate air supply.
③According to flange: square flange duct, round flange duct.
④ According to valve: Square manual control valve. Round manual control valve. Bottom regulating valve;
⑤According to diffuser: mesh steel plate, mesh/louver hole steel plate, gauze uniform flow film, louvers, etc.
② According to air supply requirements: Side Air Supply: side flange air inlet and lower diffuser plate air supply. Top Air Supply: top flange air inlet, lower diffuser plate air supply.
③According to flange: square flange duct, round flange duct.
④ According to valve: Square manual control valve. Round manual control valve. Bottom regulating valve;
⑤According to diffuser: mesh steel plate, mesh/louver hole steel plate, gauze uniform flow film, louvers, etc.
Product Parameters | ||||||||
Product Name | Hepa Box | |||||||
Product Model | YN-GS-01 | YN-GS-02 | YN-GS-03 | YN-GS-04 | ||||
Air Volume（m3/h) | 500 | 1000 | 1500 | 2000 | ||||
Air Diffuser Size (mm) | 415×415×16.5 | 579×579×16.5 | 705×705×16.5 | 1010×705×16.5 | ||||
Cabinet Size (mm) | 370×370×400 | 534×534×400 | 660×660×400 | 965×660×400 | ||||
Hepa Filter Size (mm) | 320×320×90 | 484×484×90 | 610×610×90 | 915×610×90 | ||||
Efficiency | 99.95%@0.3μm | 99.95%@0.3μm | 99.95%@0.3μm | 99.95%@0.3μm | ||||
Flange Size (mm) | 200×200 | 320×200 | 400×200 | 500×200 | ||||
Products Description
Success case show
Our Factory
Dongguan Yaning Purification Equipment Co.,Ltd is located in Dongguan, the advanced manufacturing center of the Guangdong-Hong Kong-Macao Greater Bay Area. It is an integrated supplier of clean technology solutions integrating technology, research and development, design, manufacturing, sales and installation. The company has more than 200 employees, a plant area of more than 30,000 square meters, and an annual output value of more than 300 million RMB.
Province,With more than ten years of independent R&D and innovation, YANING Purification has obtained more than 30 technical patents and
has become a national high-tech enterprise. It has passed the ISO9001:2015 quality management system certification and
ISO14001:2015 environmental management system certification, and won the title Guangdong "Abide by contracts and keep promises"
Enterprise, Famous Brand Enterprise in Guangdong
has become a national high-tech enterprise. It has passed the ISO9001:2015 quality management system certification and
ISO14001:2015 environmental management system certification, and won the title Guangdong "Abide by contracts and keep promises"
Enterprise, Famous Brand Enterprise in Guangdong
Packing&Delivery
Exhibition
FAQ
1. Who are we?
We are based in Guangdong, China, start from 2011,sell to Domestic Market(60.00%),Southeast Asia(15.00%),North
America(10.00%),Western Europe(5.00%),Southern Europe(5.00%),Northern Europe(5.00%). There are total about 101-200 people in our
office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Air Shower, Fast Roll Doors, FFU, Operating Room, HEPA Filter,Clean Bench,Scrub Sink.etc.
4. Why should you buy from us not from other suppliers?
YANING brand clean room equipment:air shower pass box,clean bench,FFU,softwall clean room YANING brand Air
filters:HEPA,prefilter,pocket filter,V type filter Matched ISO14001,ISO9001,TUV,ROHS.CE,UL Best price and service,each products
strict facty test.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish
We are based in Guangdong, China, start from 2011,sell to Domestic Market(60.00%),Southeast Asia(15.00%),North
America(10.00%),Western Europe(5.00%),Southern Europe(5.00%),Northern Europe(5.00%). There are total about 101-200 people in our
office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Air Shower, Fast Roll Doors, FFU, Operating Room, HEPA Filter,Clean Bench,Scrub Sink.etc.
4. Why should you buy from us not from other suppliers?
YANING brand clean room equipment:air shower pass box,clean bench,FFU,softwall clean room YANING brand Air
filters:HEPA,prefilter,pocket filter,V type filter Matched ISO14001,ISO9001,TUV,ROHS.CE,UL Best price and service,each products
strict facty test.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish
