Сверхмощный Мощный Ручной инструмент поворотный позиционер стол для сварки автоматический вращающийся сварочный
3 600,00-3 800,00 $
Высокопроизводительный стол для сварки вращающийся Позиционер поворотный
- Категория: >>>
- Поставщик: Wuxi Zhouxiang Complete Set Of Welding Equipment Co. Ltd.Wuxi Ltd.
Сохранить в закладки 1601115717792:
Описание и отзывы
Характеристики
Product Paramenters
China Zhouxiang Plant design and manufacture an extensive range of welding positioners and positioning equipment from 10kg to 100ton and beyond. Our welding positioners are designed to significantly improve the productiveness of your welding and fabrication process.
The perfect automated solution for tilting、rotating and lifting，workpieces of various capacities, shapes and sizes 360 degrees. They increase quality and consistency of the weld, both by hand and automation. Their easy to use operation and accessibility with integrated equipment; welding positioners also significantly enhance operator ergonomics.Our positioner range consists of Bench positioners, Adjustable Height, Elevating, Cradle, L-type and specialised designs can be built to suit large diameter components with clamps and jig tooling. High Cost Performance Table Welding Rotating Positioner Rotary Table
The perfect automated solution for tilting、rotating and lifting，workpieces of various capacities, shapes and sizes 360 degrees. They increase quality and consistency of the weld, both by hand and automation. Their easy to use operation and accessibility with integrated equipment; welding positioners also significantly enhance operator ergonomics.Our positioner range consists of Bench positioners, Adjustable Height, Elevating, Cradle, L-type and specialised designs can be built to suit large diameter components with clamps and jig tooling. High Cost Performance Table Welding Rotating Positioner Rotary Table
Model | Load Capacity | Table Speed | Table | Power | Table Diameter(ΦD) | Rotation Speed Adjust | Machine Size(mm) | ||||
Ratation | Tilt | Tilt Angle | Ratation | Tilt | |||||||
Kg | RPM | RPM | ° | Kw | mm | L*W*H | |||||
HBZ-1 | 100 | 0.35-3.5 | 1.0 | 0-90 | 0.18 | 0.18 | 400 | VFD | 740*525*480 | ||
HBZ-3 | 300 | 0.2-2 | 1.0 | 0-90 | 0.37 | 0.37 | 600 | 940*720*610 | |||
HBZ-6 | 600 | 0.09-0.9 | 1.0 | 0-90 | 0.75 | 0.75 | 1000 | 1500*1120*1000 | |||
HBZ-10 | 1000 | 0.05-0.5 | 0.8 | 0-120 | 1.1 | 1.5 | 1200 | 1850*1210*1140 | |||
HBZ-30 | 3000 | 0.05-0.5 | 0.23 | 0-120 | 1.5 | 1.5 | 1400 | 2200*1740*1355 | |||
HBZ-50 | 5000 | 0.05-0.5 | 0.16 | 0-120 | 2.2 | 3 | 1500 | 2700*1984*1510 | |||
HBZ-100 | 10000 | 0.017-0.17 | 0.1 | 0-120 | 3 | 5.5 | 2000 | 3460*2500*2024 | |||
HBZ-200 | 20000 | 0.017-0.17 | 0.1 | 0-120 | 4 | 5.5 | 2000 | 3610*2930*1974 | |||
Model | Load Capacity | Table Speed | Table | Power | Table Diameter(ΦD) | Rotation Speed Adjust | Machine Size(mm) | ||||
Ratation | Tilt | Tilt Angle | Ratation | Tilt | |||||||
lb | RPM | RPM | ° | HP | mm | L*W*H | |||||
HBZ-1 | 220 | 0.35-3.5 | 1.0 | 0-90 | 0.24 | 0.24 | 400 | VFD | 740*525*480 | ||
HBZ-3 | 660 | 0.2-2 | 1.0 | 0-90 | 0.50 | 0.50 | 600 | 940*720*610 | |||
HBZ-6 | 1320 | 0.09-0.9 | 1.0 | 0-90 | 1.00 | 1.00 | 1000 | 1500*1120*1000 | |||
HBZ-10 | 2200 | 0.05-0.5 | 0.8 | 0-120 | 1.5 | 2.0 | 1200 | 1850*1210*1140 | |||
HBZ-30 | 6600 | 0.05-0.5 | 0.23 | 0-120 | 2.0 | 2.0 | 1400 | 2200*1740*1355 | |||
HBZ-50 | 11000 | 0.05-0.5 | 0.16 | 0-120 | 3.0 | 4.0 | 1500 | 2700*1984*1510 | |||
HBZ-100 | 22000 | 0.017-0.17 | 0.1 | 0-120 | 4.0 | 7.4 | 2000 | 3460*2500*2024 | |||
HBZ-200 | 44000 | 0.017-0.17 | 0.1 | 0-120 | 5.4 | 7.4 | 2000 | 3610*2930*1974 | |||
Product Advantages
A1:The tilt and rotation welding positioner is equipped with angle dial, and the tilt angle can be clearly displayed on the dial, which is convenient for grasping the overturning angle,making the operation more accurate and reliable.The limit switch effectively protects the equipment.
High Cost Performance Table Welding Rotating Positioner Rotary Table
A2: The frame is welded by plates and profiles, and has sufficient mechanical strength to ensure long-term use without deformation. The groove is more convenient for workpiece fixing. Chucks can be configured according to customer requirements. The rotation of the worktable adopts a slewing bearing, which has a strong bearing capacity. High Cost Performance Table Welding Rotating Positioner Rotary Table
A3: Schneider AC variable frequency governor is mainly used to control and adjust the speed of three-phase AC asynchronous motors,with stable performance, rich combination functions, good dynamic
characteristics, super overload capacity and unparalleled flexibility.Electrical control system adopts IP65 protection against dust and heavy rain and remote wire / wireless control box operation. The high-standard electrical control box has neat wiring and clear grounding signs.
characteristics, super overload capacity and unparalleled flexibility.Electrical control system adopts IP65 protection against dust and heavy rain and remote wire / wireless control box operation. The high-standard electrical control box has neat wiring and clear grounding signs.
Packaging & Shipping
Main Product
Customer Cases
About Us
Wuxi Zhouxiang Complete Set of Welding Equipment Co.,Ltd,founded in 1991,located in Wuxi city, about 100km from Shanghai.We have fixed assets of 150 million yuan,cover an area of 160,000 m2, staff 500 people,including more than 100 engineering and technical personnel.Our company was certified to ISO9001 Quality System Certification firstly in the industry and many products were certified to China Compulsory Certification(CCC).Our products sell well at home and abroad,including Europe,America,Southeast Asia,Middle East and other countries.
Zhouxiang products mainly include cnc cutting machine,H beam production line,box beam production line, welding manipulator, welding rotator, welding positioner, milling machine, shot blasting machine, plate rolling machine, profile bending machine and fiber laser cutting machine etc.We have high sincerity to do business with customers all over the world and establish good friendships. High Cost Performance Table Welding Rotating Positioner Rotary Table
Zhouxiang products mainly include cnc cutting machine,H beam production line,box beam production line, welding manipulator, welding rotator, welding positioner, milling machine, shot blasting machine, plate rolling machine, profile bending machine and fiber laser cutting machine etc.We have high sincerity to do business with customers all over the world and establish good friendships. High Cost Performance Table Welding Rotating Positioner Rotary Table
Our Services
FAQ
1.Q: What is the minimum order quantity?
A: 1PCS.
High Cost Performance Table Welding Rotating Positioner Rotary Table
2.Q: What are the payment terms?
A: L/C; T/T.
High Cost Performance Table Welding Rotating Positioner Rotary Table
3.Q: How long is the delivery time?
A: 30 Days.
High Cost Performance Table Welding Rotating Positioner Rotary Table
4.Q:How long is the warranty period?
A: 1 Years.
A: 1PCS.
High Cost Performance Table Welding Rotating Positioner Rotary Table
2.Q: What are the payment terms?
A: L/C; T/T.
High Cost Performance Table Welding Rotating Positioner Rotary Table
3.Q: How long is the delivery time?
A: 30 Days.
High Cost Performance Table Welding Rotating Positioner Rotary Table
4.Q:How long is the warranty period?
A: 1 Years.
