Инвертор 24 В 220 5000 Вт чистая Синусоидальная волна 48 24vdc в 220vac инвертор Лучший инверторный Аккумулятор для дома
- Категория: >>>
- Поставщик: Guangzhou Felicity Solar Technology Co. Ltd.
Сохранить в закладки 1601117693623:
Описание и отзывы
Характеристики
Features
·Pure sine wave inverter.
·Built-in MPPT solar charge controller.
·Configurable input voltage range for home appliances and personal computers via LCD setting.
·Configurable battery charging current based on applications via LCD setting.
·Configurable AC/Solar Charger priority via LCD setting
·Compatible to mains voltage or generator power.
·Auto restart while AC is recovering.
.Inverter running without battery.
·Lithium battery activation function.
·Cold start function.
·Built-in MPPT solar charge controller.
·Configurable input voltage range for home appliances and personal computers via LCD setting.
·Configurable battery charging current based on applications via LCD setting.
·Configurable AC/Solar Charger priority via LCD setting
·Compatible to mains voltage or generator power.
·Auto restart while AC is recovering.
.Inverter running without battery.
·Lithium battery activation function.
·Cold start function.
Model | IVEM3024 | IVEM5048 | ||
Rated Output Power(VA) | 3000VA | 5000VA | ||
Rated Output Power(W) | 3000W | 5000W | ||
Nominal DC Input Voltage | 24V | 48V | ||
Nominal Input Voltage | 230Vac | |||
Max AC Input Voltage | 280Vac | |||
Nominal Input Frequency | 50Hz/60Hz(Auto detection) | |||
Efficiency (Line Mode) | >95%(Rated R load,battery full charged) | |||
Pass Through Without Battery | Yes | |||
Utility Charge Mode Specifications | ||||
Input Voltage Range | 90-280Vac | |||
Over Charge Protection | Yes | |||
Solar Charging & Utility Charging | ||||
Max.PV Open Circuit Voltage | 500V | |||
PV Voltage Working Range | 120V-500V | |||
Max.Input Power | 4000W | 6000W | ||
Max.Solar Charging Current | 100A | |||
Max.Charging Current(PV+Grid) | 100A | |||
Max.Input Current | 15A | 20A | ||
Min. Startup Voltage | 125V | |||
Inverter Mode Specifications | ||||
Output Voltage Waveform | Pure sine wave | |||
Nominal Output Voltage | 230Vac±5% | |||
Nominal Output Frequency(Hz) | 50±0.3Hz/60Hz±0.3Hz(Adjustable) | |||
Parallel Unit | - | 12 | ||
Peak Efficiency | 93% | |||
Over-Load Protection (SMPS load) | 5s@≥150% load;10s@105%~150%load | |||
Surge Rating | 2* rated power for 5s | |||
Capable of Starting Electric | Yes | |||
Output Short Circuit Protection | Yes | |||
General Specifications | ||||
Operating Temperature | 0℃~55℃ | |||
Range Storage Temperature | -15℃~60℃ | |||
Net Weight(KG) | 9.1KG | 11.2KG | ||
Gross Weight(KG) | 10.8KG | 13.2KG | ||
Product Size (D*W*H) | 395x295x129mm | 415x320x129mm | ||
Package Dimension (D*W*H) | 492x392x222mm | 514x419x222mm | ||
To become a distributor or agent of Felicitysolar, please contact us！！！
We can ship from over 25 overseas warehouses in the United States, the European Union, Nigeria, South Africa, the Philippines,Myanmar, Dubai, Mali... and provide fast transportation services. If you need it, please click here to contact us directly.
100% genuine high quality A-grade solar inverter with factory QR code on it. Not fake or used or bad quality inverter!!!
Many customers have used Felicitysolar batteries and received good feedback:
Felicity solar is the best supplier for you:
*A professional supplier of solar energy products, headquartered in Guangzhou, China, with a history of 16 years, including 24V and 48V lithium batteries, 12V strong acid batteries, 2v OPZV batteries, solar inverters, controllers, street lights, and solar panels.
*OEM/ODM services are acceptable. We can customize products according to your requirements, ensuring 100% of the quality you expect.
*Provide fast transportation services. There are over 25 warehouses in China, United States, the European Union, Nigeria, South Africa, the Philippines, Myanmar, Dubai, Mali, and more.
*High quality local after-sales service. If there is a problem with the product, we have professional after-sales technical engineers in 25 countries, including United States, the European Union, Nigeria, South Africa, the Philippines, Myanmar, Dubai, Mali, to help you solve it.
*Alibaba TUV Verified Supplier. Felicitysolar is a professional supplier of gold products certified by Alibaba TUV in 2009
If you are interested in our products or services, please come to contact us immediately！
*A professional supplier of solar energy products, headquartered in Guangzhou, China, with a history of 16 years, including 24V and 48V lithium batteries, 12V strong acid batteries, 2v OPZV batteries, solar inverters, controllers, street lights, and solar panels.
*OEM/ODM services are acceptable. We can customize products according to your requirements, ensuring 100% of the quality you expect.
*Provide fast transportation services. There are over 25 warehouses in China, United States, the European Union, Nigeria, South Africa, the Philippines, Myanmar, Dubai, Mali, and more.
*High quality local after-sales service. If there is a problem with the product, we have professional after-sales technical engineers in 25 countries, including United States, the European Union, Nigeria, South Africa, the Philippines, Myanmar, Dubai, Mali, to help you solve it.
*Alibaba TUV Verified Supplier. Felicitysolar is a professional supplier of gold products certified by Alibaba TUV in 2009
If you are interested in our products or services, please come to contact us immediately！
