ZTC1000 100 Ton Camion Grue Mobile Truck Crane for Sale

ZTC1000 100 Ton Camion Grue Mobile Truck Crane for Sale

Категория: >>>
Поставщик: Newindu Construction Engineering (shanghai) Co. Ltd.Newindu Ltd.

Цена:13 000,00-16 000,00 $*

Количество:

В избранное

Описание и отзывы

Характеристики

Contact

Sales manager

Piper Zhu

Mobile:+86-18656692068(Whatsapp/Wechat)
E-mail:piper@newindu.com

High Quality 25ton Truck Crane QY25KD QY25K

In Stock popular sale

Products Description

Leading lifting and driving performances

1. Five main U-type booms. The boom length is 10.6m-41.0m with strong lifting performance, leading ahead of products with the same tonnages in the same industry.

2. The new power system platform centers on 9L high-power engine of Shanghai Diesel Engine Co., Ltd, 9-gear overgear gearbox of Shanxi Gear Auto Drive Group Co., Ltd and large-ration double reduction axes of Meritor Axle Co., Ltd. It is of superior driving performances and the maximum gradeability reaches to 41%.

New-structure special hydraulic-pressure radiator with high reliability under high temperature conditions

1. New-structure special hydraulic-pressure radiator, the radiator power (18KW) would be increased and heat dispersion performance would be promoted by 15%;

2. The layout of fuel hole position is reasonable and speed of hydraulic oil is uniform. The pressure loss is lowered by 33%,
guaranteeing heat dispersion performance of products. Meanwhile, the reliability of continuous operation under high temperature conditions would be substantially promoted.

New molding, humanized design and comfortable manipulation

1. New operating house, wheel house and machine shed. Novel appearances, fine lines of the complete machine appearance that shows
international trends;

2. The rearview mirror is installed in operating house, easy to for observe the working environment; front pedal and push-and-pull
pedal in left side are installed, easy access to the operating house;

3. Ladder stand is installed in two sides of the chassis, easy to get on or off the bus. In addition, tool cabinet is installed in
right rear side of the frame, easy to store tools attachment for users, fully representing the purpose of humanized design.

Specification

Main Technical Parameter Table under Driving Status
Category	Item			Unit	Parameter
Dimension Parameter	Overall length			mm	12680
		Overall width			mm	2500
		Overall height			mm	3400
		Wheel base			mm	4425+1350
		Wheel track			mm	2074/1834/1834
Weight Parameter	Total mass under driving status			kg	32800
		Axle load	Front axle	kg	7300
		Axle load		Back axle	kg	25500
Kinetic Parameter	Engine type				SC9DF290Q4
		Engine power rating			kw/(r/min)	213/2200
		Rated torque of engine			N.m/(r/min)	1200/1400
Running Parameter	Maximum travel speed			km/h	90
		Minimum diameter of turning circle			m	22
		Minimum ground clearance			mm	275
		Approach angle			°	11
		Departure angle			°	12
		Braking length (the speed is 30km/h)			m	≤10
		Maximum gradeability			%	41
		Fuel consumption per hundred kilometers			L	≤32
Noise Parameter	Car exterior noise when speeding up			dB(A)	88
Noise Parameter		Noise around the driver’s ear			dB(A)	90
